Seite 1/74
2007-2015 Microchip Technology Inc. DS70000195G-page 1
HIGHLIGHTS
This section of the manual contains the following major topics:
1.0 Introduction ....................................................................................................................... 2
2.0 I
2
C Bus Characteristics..................................................................................................... 4
3.0 Control and Status Registers ............................................................................................ 8
4.0 Enabling I
2
C Operation ................................................................................................... 18
5.0 Communicating as a Master in a Single Master Environment ........................................ 20
6.0 Communicating as a Master in a Multi-Master Environment .......................................... 34
7.0 Communicating as a Slave ............................................................................................. 37
8.0 Connection Considerations for I
2
C Bus .......................................................................... 61
9.0 Operation in Power-Saving Modes ................................................................................. 63
10.0 Peripheral Module Disable (PMDx) Registers ................................................................ 63
11.0 Effects of a Reset............................................................................................................ 63
12.0 Constant-Current Source ................................................................................................ 64
13.0 Register Maps................................................................................................................. 66
14.0 Design Tips ..................................................................................................................... 67
15.0 Related Application Notes............................................................................................... 68
16.0 Revision History .............................................................................................................. 69
Inter-Integrated Circuit (I2C)
dsPIC33/PIC24 Family Reference Manual
DS70000195G-page 2 2007-2015 Microchip Technology Inc.
This document supersedes the following PIC24 and dsPIC
®
DSC Family Reference Manual sections:
1.0 INTRODUCTION
The Inter-Integrated Circuit (I
2
C) module is a serial interface useful for communicating with other
peripheral or microcontroller (MCU) devices. The external peripheral devices may be serial
EEPROMs, display drivers, Analog-to-Digital Converters (ADC) and so on.
The I
2
C module can operate as any one of the following in the I
2
C system:
Slave device
Master device in a single master system (slave may be active)
Master or slave device in a multi-master system (bus collision detection and arbitration are
available)
The I
2
C module contains an independent I
2
C master logic and a I
2
C slave logic, which generates
interrupts based on their events. In the multi-master systems, the user software is simply
partitioned into the master controller and the slave controller.
When the I
2
C master logic is active, the slave logic also remains active, detecting the state of the
bus and potentially receiving messages from itself in a single master system or from the other
masters in a multi-master system. No messages are lost during the multi-master bus arbitration.
In a multi-master system, the bus collision conflicts with the other masters in the system when
detected, and the module provides a method to terminate and then restart the message.
The I
2
C module contains a Baud Rate Generator (BRG). The I
2
C BRG does not consume other
timer resources in the device. Figure 1-1 illustrates the I
2
C module block diagram.
Key features of the I
2
C module include the following:
Independent master and slave logic
Multi-master support which prevents message losses in arbitration
Detects 7-bit and 10-bit device addresses with configurable address masking in Slave mode
Detects general call addresses as defined in the I
2
C protocol
Bus Repeater mode, allowing the module to accept all messages as a slave, irrespective of
the address
Automatic SCLx clock stretching provides delays for the processor to respond to a slave
data request
Supports 100 kHz and 400 kHz bus specifications
Supports the Intelligent Platform Management Interface (IPMI) standard
Supports SDAx hold time for SMBus (300 nS or 150 nS) in Slave mode
Note: This family reference manual section is meant to serve as a complement to device
data sheets. Depending on the device variant, this manual section may not apply to
all PIC24 and dsPIC33 devices.
Please consult the note at the beginning of the “Inter-Integrated Circuit (I
2
C)”
chapter in the current device data sheet to check whether this document supports
the device you are using.
Device data sheets and family reference manual sections are available for
download from the Microchip Worldwide Web site at:
http://www.microchip.com
DS Number Section Number Title
DS70195 19 dsPIC33F/PIC24H Family Reference Manual
DS70330 19 dsPIC33E/PIC24E Family Reference Manual
DS39702 24 PIC24F Family Reference Manual
DS70235 19 PIC24H Family Reference Manual
DS70068 21 dsPIC30F Family Reference Manual
Note:
For more information, refer to the SDAHT bit description in the specific device data sheet.
2007-2015 Microchip Technology Inc. DS70000195G-page 3
Inter-Integrated Circuit (I
2
C)
Figure 1-1: I
2
C Block Diagram
I2CxRCV
Internal
Data Bus
SCLx
SDAx
Shift
Match Detect
Clock
Address Match
Clock
Stretching
I2CxTRN
LSB
Shift Clock
BRG
Reload
Control
T
CY
or T
CY
/2
(1)
Acknowledge
Generation
I2CxCONH
I2CxSTAT
Control Logic
Read
LSB
Write
Read
I2CxBRG
I2CxRSR
Write
Read
Write
Read
Write
Read
Write
Read
Write
Read
Down Counter
I2CxCONL
Write
Read
Note 1: Refer to the specific device data sheet for the clock rate.
I2CxADD
Start and Stop
Bit Detect
Start and Stop
Bit Generation
Collision
Detect
I2CxMSK
