2018 Microchip Technology Inc. DS20006081A-page 1
MIC2874
Features
Up to 1.2A Flash LED Driving Current
Highly Efficient Synchronous Boost Driver
Control through Single-Wire Serial Interface or
External Control Pin
Input Voltage Range: 2.7V to 5.5V
True Load Disconnect
Configurable Safety Time-Out Protection
Output Overvoltage Protection (OVP)
LED Short Detection and Protection
1 µA Shutdown Current
Available in 9-Bump 1.30 mm x 1.30 mm WLCSP
Package
Applications
Camera Phones/Mobile Handsets
Cell Phones/Smartphones
LED Light for Image Capture/Auto-Focus/
White Balance
Handset Video Light (Torch Light)
Digital Cameras
Portable Applications
General Description
The MIC2874 is a high-current, high-efficiency Flash
LED driver. The LED driver current is generated by an
integrated inductive boost converter with a 4 MHz switch-
ing frequency, which allows for the use of a very small
inductor and output capacitor. These features make the
MIC2874 an ideal solution for high-resolution camera
phone LED Flash light driver applications.
MIC2874 operates in either Flash or Torch mode that can
be controlled through the single-wire serial interface
and/or external control pin. A robust single-wire serial
interface allows the host processor to control the LED
current and brightness. The MIC2874 is available in a
9-bump 1.30 mm x 1.30 mm WLCSP package.
1.2A High-Brightness Flash LED Driver with
Single-Wire Serial Interface
MIC2874
DS20006081A-page 2 2018 Microchip Technology Inc.
Package Type
Typical Application Schematic
LED
A
B
C
DC OUT
LGND SWFEN
AGND V
IN
PGND
1 2 3
MIC2874
9-Bump 1.30 mm x 1.30 mm WLCSP (CS)
(Top View)
Note: WLCSP Bump A1 identifier = “”.
DC
LED
FEN
VIN SW OUT
V
BAT
AGND
FLASH ENABLE
SINGLE-WIRE SERIAL I/F
PGND
LGND
2018 Microchip Technology Inc. DS20006081A-page 3
MIC2874
Functional Block Diagram
SW
SYSTEM
CONTROL
LOGIC +
ANTI-CROSS
CONDUCTION
DC
FEN
VIN
AGND
LED
OUT
PGND
LGND
SINGLE-
WIRE
SERIAL
INTERFACE
LED SCP
UVLO
BODY
SWITCH
OTP
155°C/
140°C
LBVD
SAFETY
TIMER
DIE TEMP
2.53V/
2.35V
OUT
LED 1.7V
VIN
AGND
PGND
Z Z
4 MHz
OSCILLATOR
V/I
OUT
SAFETY
TIMER
SAFETY
TIMER
DECODER
4-BIT
