 2014 Microchip Technology Inc. DS20005270A-page 1
MCP19114/5
This document includes the programming
specifications for the following devices:
• MCP19114
• MCP19115
1.0 PROGRAMMING THE
MCP19114 AND MCP19115
DEVICES
The MCP19114/5 devices are programmed using a serial
method. The Serial mode will allow these devices to be
programmed while in the user’s system. These
programming specifications apply to all of the above
devices in all packages.
1.1 Hardware Requirements
This family of devices requires one power supply for
VIN, see Table 6-1. The VDD that is used to bias all
internal circuitry is internally generated and regulated
to 5V. Analog circuitry is powered from internally
generated AVDD and is regulated to 4V.
1.2 Program/Verify Mode
The Program/Verify mode for this family of devices
allows programming the user program memory, the
user ID locations, the Calibration Word and the
Configuration Word.
FIGURE 1-1: PIN DIAGRAM – 24-PIN QFN (MCP19114)
1
2
3
4
5
6 13
7
8
9
10
11
12
14
15
16
17
18
23
22
21
20
19
24
EXP-25
GPA0/AN0/TEST_OUT
GPA1/AN1/CLKPIN
GPA2/AN2/T0CKI/INT
GPA3/AN3
GPA7/SCL/ICSPCLK
GPA6/CCD/ICSPDAT
GPA5/MCLR/TEST_EN
GPB0/SDA
DESATN
DESATP/ISOUT
ISP
ISN
IP
AGND
PGND
SDRV
PDRV
VDR
GPB1/AN4/VREF2
ICOMP
IFB
VS
VIN
VDD
MCP19114
MCP19114/5 Flash Memory Programming Specification
MCP19114/5
DS20005270A-page 2  2014 Microchip Technology Inc.
TABLE 1-1: PIN DESCRIPTIONS IN PROGRAM/VERIFY MODE: MCP19114
FIGURE 1-2: PIN DIAGRAM – 28-PIN QFN (MCP19115)
Pin Name
During Programming
Function Pin Type Pin Description
GPA7 ICSPCLK I Clock Input – Schmitt Trigger Input
GPA6 ICSPDAT I/O Data Input/Output – Schmitt Trigger Input
MCLR Program/Verify mode P( )1Program Mode Select
VIN VIN P Device Power Supply Input
VDD VDD P Power Supply Output
GND VSS P Ground
Legend: I = Input, O = Output, P = Power
Note 1: In the MCP19114, the programming high voltage is internally generated. To activate the Program/Verify
mode, voltage of VIHH and a current of IIHH (see Table 6-1) need to be applied to the MCLR input.
1
2
3
4
5
6
7 15
8
9
10
11
12
13
14
16
17
18
19
20
21
26
25
24
23
22
28
27
EXP-29
GPA1/AN1/CLKPIN
GPA2/AN2/T0CKI/INT
GPB4/AN5/ICSPDAT
GPA3/AN3
GPA7/SCL
GPA6/CCD
GPA0/AN0/TEST_OUT
GPB6/AN7
GPB5/AN6/ICSPCLK
GPB1/AN4/VREF2
ICOMP
IFB
VS
VIN
VDD
VDR
PDRV
SDRV
PGND
AGND
I
P
GPA5/MCLR/TEST_EN
GPB7_CCD
GPB0/SDA
DESATN
DESAT P/ISOUT
ISP
ISN
MCP19115
 2014 Microchip Technology Inc. DS20005270A-page 3
MCP19114/5
TABLE 1-2: PIN DESCRIPTIONS IN PROGRAM/VERIFY MODE: MCP19115
Pin Name
During Programming
Function Pin Type Pin Description
GPB5 ICSPCLK I Clock Input – Schmitt Trigger Input
GPB4 ICSPDAT I/O Data Input/Output – Schmitt Trigger Input
MCLR Program/Verify mode P( )1Program Mode Select
VIN VIN P Device Power Supply Input
VDD VDD P Power Supply Output
GND VSS P Ground
Legend: I = Input, O = Output, P = Power
Note 1: In the MCP19115, the programming high voltage is internally generated. To activate the Program/Verify
mode, voltage of VIHH and a current of IIHH (see Table 6-1) need to be applied to the MCLR input.
