2017-2019 Microchip Technology Inc. DS20005721C-page 1
HV2803/HV2903/HV2904
Features
32-Channel, High-Voltage Analog Switch
No High-Voltage Supplies Required
32-Channel, Single-Pole, Single-Throw (SPST)
Individual Switching or Bank Switching
3.3V CMOS Input Logic Level
66 MHz Data Shift Clock Frequency
Silicon-on-Insulator (SOI) High-Voltage
Technology for High Performance
Standby mode for Low-Power Dissipation
Low-Parasitic Capacitance
DC to 50 MHz Analog Small-Signal Frequency
200 kHz to 50 MHz Large-Signal Frequency
-70 dB Typical Off Isolation at 5.0 MHz
Excellent Noise Immunity
Cascadable Serial Data Register with Latches
Integrated Bleed Resistors on the Outputs (both
sides for HV2903, one side for HV2904)
Applications
Medical Ultrasound Imaging
Nondestructive Testing (NDT) Metal Flaw
Detection
Piezoelectric Transducer Drivers
Inkjet Printer Heads
Optical MEMS Modules
General Description
The HV2803/HV2903/HV2904 devices are low harmonic
distortion, low charge injection, 32-channel, high-voltage
analog switches without high-voltage supplies. They are
intended for use in applications requiring high-voltage
switching controlled by low-voltage control signals, such
as medical ultrasound imaging, driving piezoelectric
transducers and printers.
The HV2903 device has integrated bleed resistors at
both sides of the switches; the HV2904 device has
bleed resistors at one side only, while the HV2803
device has no bleed resistors. The bleed resistor
eliminates voltage build-up on capacitive loads, such
as piezoelectric transducers.
The HV2803/HV2903/HV2904 devices have two
modes of operation determined by the MODE pin input.
MODE input high enables an individual Switching
mode of 32-channel SPST switches and MODE input
low enables a Bank Switching mode of 16-Pole
Double-Throw (16PDT) switches to support bank
switching for probe selection.
The devices require only ±6V or ±5V low-voltage
supplies and no high-voltage supplies. However, all the
analog switches can transmit ±100V high-voltage pulses.
Package Type
1 2 3 4 5 6 7 8 9 10 11 12 13
A
B
C
D
E
F
G
H
P
J
K
L
M
14
N
HV2803/HV2903/HV2904
12 x 12 x 1.20 mm TFBGA
(Top View*)
* See Section 2.0 “Package Pin Configuration
and Function Description”.
No High-Voltage Bias, Low Harmonic Distortion,
32-Channel, High-Voltage Analog Switch
HV2803/HV2903/HV2904
DS20005721C-page 2 2017-2019 Microchip Technology Inc.
Block Diagram
Level
Shifters
VDD
VSS
Output
Switches SW0A
SW0B
SW1A
SW1B
SW2A
SW2B
SW30A
SW30B
SW31A
SW31B
Bleed
Resistors
RGND
HV2903 has bleed resistor at SWxA and SWxB
HV2904 has bleed resistor at SWxA only
GND
VLL
CLR
LE/EN
CLK
DIN/AB
DOUT
32-Bit
Shift
Register
and
Latches
(Mode = H,
Individual
Switching Logic)
Logic
Control
and
Latches
(Mode = L,
Bank Switching
Logic)
EN
A/B
MODE
STBY
2017-2019 Microchip Technology Inc. DS20005721C-page 3
HV2803/HV2903/HV2904
1.0 ELECTRICAL CHARACTERISTICS
Absolute Maximum Ratings†
Logic Supply Voltage (VLL)......................................................................................................................... -0.5V to +6.6V
Positive Supply Voltage (VDD).................................................................................................................... -0.5V to +6.6V
Negative Supply Voltage (VSS) .................................................................................................................. +0.5V to -6.6V
Logic Input Voltage (VIN).....................................................................................................................-0.5V to V
LL + 0.3V
DGND to GND ........................................................................................................................................... -0.3V to +0.3V
Analog Signal Range (V
SIG)......................................................................................................................-110V to +110V
Peak Analog Signal Current/Channel (I
PK) ...................................................................................................................3A
Notice: Stresses above those listed under “Maximum Ratings” may cause permanent damage to the device. This is
a stress rating only and functional operation of the device at those or any other conditions above those indicated in the
operational sections of this specification is not intended. Exposure to maximum rating conditions for extended periods
may affect device reliability.
RECOMMENDED OPERATING CONDITIONS( , , )123
Parameters Sym. Min. Typ. Max. Units Conditions
Logic Supply Voltage VLL 3 3.6 V
Positive Supply Voltage VDD 4.5 6.3 V
Negative Supply Voltage VSS -6.3 -4.5 V
High-Level Input Voltage VIH 0.9 VLL — VLL V
Low-Level Input Voltage V
IL 0 0.1 VLL V
Analog Signal Voltage Peak-to-Peak VSIG -100 100 V
Note 1: Power-up sequence is VSS, VDD and then VLL. Power-down sequence is the reverse of power-up.
2: VSIG must be VSS VSIG VDD or floating during power-up/down transition.
3: Rise and fall times of power supplies, VLL, VDD and VSS, should be greater than 1.0 ms.
DC ELECTRICAL CHARACTERISTICS
Unless otherwise specified, V
DD = 6.0V, VSS = -6.0V, VLL = 3.3V, TAMB = +25°C. Boldface specifications apply over the
full operating temperature range.
Parameters Sym. Min. Typ. Max. Units Conditions
Small-Signal Switch
On-Resistance
RONS — 10 15 ISIG = 5 mA
— 10.4 VDD = +5V, VSS = -5V, ISIG = 5 mA
( )Note 1
— 10 15 ISIG = 200 mA
Small-Signal Switch
On-Resistance Matching
ΔRONS — 5 20 % ISIG = 5 mA
Large-Signal Switch
On-Resistance
RONL — 9 VSIG = 90V, ISIG = 1A (Note 1)
Value of Output Bleed Resistor
(HV2903/HV2904 only)
RINT 20 35 50 kOutput switch to R
GND, IRINT = 0.1 mA
Switch Off Leakage per SW ISOL — — 3µA At 49 µs with VSIG = +100V,
50 μs pulse (see Figure 3-1)
— — 3µA At 49 μs with VSIG = -100V,
50 μs pulse (see Figure 3-1)
Note 1: Specification is obtained by characterization and is not 100% tested.
2: Design guidance only.
