32-bit Microcontroller Families
Industrys Broadest and Most Innovative 32-bit MCU Portfolio
32-bit Microcontrollers
www.microchip.com/32bit
www.microchip.com/32bit
2
Building on the heritage of Microchip Technology’s world-leading 8- and 16-bit microcontrollers, the 32-bit family oers a wide
range of products from the industrys lowest-power to highest-performance MCUs coupled with novel and easy-to-use soft-
ware solutions. With a rich ecosystem of development tools, integrated development environments and third-party partners,
Microchip’s families of 32-bit microcontrollers accelerate a vast array of embedded designs ranging from secured Internet of
Things (IoT) to Functional Safety applications to general-purpose embedded control.
World-Class 32-bit Microcontrollers
Internet of Things Functional Safety
Graphics and Touch
Digital Audio
Automotive
Connected Lighting Motor Control
Security
Metering
Ultra-Low Power
5V Appliances
Wearables
PIC32MM
microApv, 37 DMIPS, 16–256 KB Flash
SAMD, SAML, SAMC
Cortex®-M0+/M23, 45 DMIPS, 8–256 KB Flash
PIC32MX1/2/5 (XLP)
MIPS M4K, 116 DMIPS, 16–512 KB Flash
SAM7, SAM3, R32AV
Legacy 32-bit
Performance
Memory Configuraon
Baseline
Mid-Range
High Performance
PIC32MX5/6/7
MIPS M4K, 105 DMIPS, 64–512 KB Flash
PIC32MX3/4
MIPS M4K, 131/150 DMIPS, 64–512 KB Flash
PIC32MK MC/GP
MIPS microApv, 198 DMIPS, 256–1024 KB Flash
PIC32MZ EF
MIPS M-Class, 415 DMIPS, 512–2048 KB Flash
SAMD5/E5, SAM4N/4S/4E/4L, SAMG
Cort -M4/M4 150 DMIPS, 128–2048 KB Flashex F,
SAMS, SAME, SAMV
Cort -M7, 600 DMIPS, 512–2048 KB Flashex
PIC32MZ DA
MIPS microApv™, 330 DMIPS, 32 MB SDRAM,
1-2 MB Flash
Broad Portfolio with Smart Peripheral Mix and Multiple Performance Options
32-bit Microcontroller Families 3
Most Comprehensive 32-bit MCU Solutions for a Wide Range of Applications
Device Family
Digital Audio/
Bluetooth®
Graphics/
Segmented
Display
Connectivity
Functional
Safety
Touch
IoT: Nodes/
Gateways
Wearables/
Sensor Hubs
Appliances
Industrial
Automation
Automotive
Motor Control
Metering
Connected
Lighting
SAMD üüüüüüüüü ü
SAML üüüüüüüüü ü
SAMC ü ü ü ü ü ü ü ü
SAMD5/E5 ü ü ü ü ü ü ü ü
SAM4S ü ü ü ü ü
SAM4L üü üüüü ü
SAM4N ü ü ü
SAM4E üüüü
SAMG ü ü ü ü
SAMS70/E70 ü ü ü ü
SAMV7x ü ü ü ü
PIC32MM ü ü ü ü ü ü
PIC32MX1/2/5
(XLP) ü ü ü ü ü ü ü ü ü
PIC32MX3/4 ü ü ü ü ü ü ü
PIC32MX5/6/7 ü ü ü ü ü ü ü ü
PIC32MK ü ü ü ü ü ü ü ü ü ü
PIC32MZEF ü ü ü ü ü ü ü ü ü ü
PIC32MZDA ü ü ü ü ü ü
Breakthrough Innovative Features and Solutions
Ultra-low power: < 25 µA/MHz in Active Mode and 100 nA in Sleep Mode
High Performance: up to 600 DMIPS performance with double-precision Hardware Floating Point and up to 2 MB dual-panel
Flash and 512 KB SRAM
Enhanced Peripheral Touch Controller (PTC): dedicated hardware peripheral for robust capacitive touch solutions facilitating
parallel acquisition, superior water tolerance and noise immunity
Functional Safety Ready portfolio supporting IEC 60730(Class B), IEC 61508 (SIL) & ISO 26262 (ASIL) safety standards
Chip-level security and Arm® TrustZone® Technology
SleepWalking: ability of the peripherals to perform a desired task while the CPU is asleep
Event system: enables inter-peripheral communication and eciently ooads the CPU
2D Graphics Processing Unit (GPU) and 3-layer Graphics Controller with up to 24-bit color
picoPower® Technology and eXtreme Low Power (XLP)
Low-Cost Controllerless Graphics (LCCG) solutions
Integrated AES and Public Key Cryptography Controller (PUKCC)
Motor control PWM and motor encoder interface
Compact packaging options: chip scale packages down to 1.9 × 2.4 mm
Advanced analog and connectivity peripherals
microMIPS™ Instruction Set Architecture (ISA) for improved code density
Dual-panel Flash options for live updates
High performance ADC with up to 25.45 Msps in 12-bit mode or 33.79 Msps in 8-bit mode
World-Class 32-bit Microcontrollers
