 2022 Microchip Technology Inc. and its subsidiaries Product Brief DS40002424A-page 1
mXT2113TD-ATMK/
mXT2113TD-ABMK 1.0
Description
The mXT2113TD-ATMK/mXT2113TD-ABMK 1.0 uses a unique charge-transfer acquisition engine to implement Microchip’s
patented capacitive sensing method. Coupled with a state-of-the-art CPU, the entire touchscreen sensing solution can measure,
classify and track a number of individual finger touches with a high degree of accuracy in the shortest response time.
Automotive Applications
Microchip/Panasonic Knob Technology
• Detect and report the detent (click position) of specific
capacitive mechanical rotary encoders (knobs)
mounted on the touch panel
• Support for up to 4 Knob instances with different size
and number of detents (64 detents maximum)
• Position and size of each knob is individually
configurable. No specific touch pattern required
• Report relative detent position as well as the direction
of rotation
• Configurable suppression area around the knob to
suppress accidental touches from fingers holding the
knob
• Optional push/release function
• Design guidance, tools and other services available
from Microchip and Panasonic
maXTouch® Adaptive Sensing Technology
Keys
Touch Sensor Technology
• Discrete/out-cell support including glass and PET film-
based sensors
• On-cell/touch-on display support including TFT, LCD
(ITPS, IPS) and OLED
• Synchronization with display refresh timing capability
• Support for standard (for example, Diamond) and
proprietary sensor patterns (review of designs by
Microchip or a Microchip-qualified touch sensor
module partner is recommended)
Front Panel Material and Design
• Support for non-rectangular sensor designs (for
example, circular, rounded or with cutouts)
Touch Performance
• Moisture/Water Compensation
- No false touch with condensation
• P2P mutual capacitance measurements supported for
extra sensitive multi-touch sensing
• Noise suppression technology to combat ambient and
power-line noise
• Burst Frequency
- Flexible and dynamic Tx burst frequency selection
to reduce EMC disturbance
- Controlled Tx burst frequency drift over process
and temperature range
• AEC-Q100 Qualified
• CISPR 25 compliant
• Up to 33 X (transmit) lines and 64 Y (receive) lines for
use by a touchscreen and/or 2 key arrays
• A maximum of 2112 nodes can be allocated to the
touch sensor
• Touchscreen size of 16.9 inches (2:1 aspect ratio),
assuming a sensor electrode pitch of 6 mm. The
achievable touchscreen size depends on the knob
requirements
• Multiple touch support with up to 16 concurrent
touches tracked in real time depending on the number
of knobs implemented
• Up to 32 nodes can be allocated as mutual
capacitance sensor keys in addition to the
touchscreen, defined as 2 key arrays (subject to
availability of X and Y lines and other configurations)
• Adjacent Key Suppression (AKS) technology is
supported for false key touch prevention
• Works with PET or glass (dependent on sensor size,
touch size, configuration, stack-up, and dimension and
number of detents of the knob)
• Configuration and stack-up to be approved by
Microchip or a Microchip-qualified touch sensor
module partner
- Up to 240 VPP between 1 Hz and 1 kHz sinusoidal
waveform (no touches)
- Up to 20 VPP between 1 kHz and 1 MHz
sinusoidal waveform
maXTouch 2112-node Touchscreen Controller
Product Brief
mXT2113TD-ATMK/mXT2113TD-ABMK 1.0
DS40002424A-page 2 Product Brief  2022 Microchip Technology Inc. and its subsidiaries
• Scan Speed
- Typical report rate for 10 touches 120 Hz (subject to configuration)
- Initial touch latency <20 ms for first touch from idle (subject to configuration)
- Panasonic Knob rotation speed maximum 80 rpm
- Configurable for power and speed optimization
• Touch panel failure detection
- Automatic touch sensor diagnostics during run time to support the implementation of safety critical features
- Diagnostics reported using dedicated output pin or by standard Object Protocol messages
- Configurable test limits
Enhanced Algorithms
• Dedicated drift calibration algorithm for the knob locations
• Lens bending algorithms to remove display noise
• Touch suppression algorithms to remove unintentional large touches
• Palm Recovery Algorithm for quick restoration to normal state
Data Store
• 60-byte CRC-checksummed data area for use as a run-time Product Data Store Area
• Up to 64 bytes of user’s custom data (not CRC checksummed)
Power Saving
• Programmable timeout for automatic transition from Active to Idle state
• Pipelined analog sensing detection and digital processing to optimize system power efficiency
Application Interfaces
Power Supply
Package
• 144-lead LQFP 20 × 20 × 1.4 mm, 0.5 mm pitch
Operating Temperature
Design Services
• Review of device configuration, stack-up and sensor patterns
• Specific design and tuning tools available as maXTouch Studio plug-ins
• Client interface for main communication with the device. Can be one of:
- I2C interface, with support for Standard mode (up to 100 kHz), Fast mode (up to 400 kHz),
Fast-mode Plus (up to 1 MHz)
- SPI interface (up to 8 MHz)
• Interrupt to indicate when a message is available
• Additional SPI Debug Interface to read the raw data for tuning and debugging purposes
• Digital (Vdd) 3.3V nominal
• Digital I/O (VddIO) 3.3V nominal
• Analog (AVdd) 3.3V nominal
• High voltage external X line drive (XVdd) up to 8.5V
• ATMXT2113TD-ATMK: –40C to +85C (Grade 3)
• ATMXT2113TD-ABMK: –40C to +105C (Grade 2)
mXT2113TD-ATMK/mXT2113TD-ABMK 1.0
 2022 Microchip Technology Inc. and its subsidiaries Product Brief DS40002424A-page 3
PIN CONFIGURATION
144-lead LQFP
15
83
16
82
17
81
18
80
19
79
20
78
21
77
22
76
75
97
144
37
38
39
51
143
40
129
130
52
44
125
56
43
126
55
42
127
54
41
128
53
50
49
45
124
57
46
123
58
47
122
59
131
139
140
141
142
132
133
138
137
136
135
134
48
11
87
12
86
13
85
14
84
1
2
96
3
95
4
94
5
93
6
92
7
91
8
90
9
89
10
88
23
24
25
74
73
60
61
121
120
26
27
28
29
30
31
32
33
34
35
36
62
63
67
66
65
64
68
69
70
71
72
108
98
107
106
105
104
103
102
101
100
99
118
119
114
115
116
117
113
112
111
110
109
NC
NC
NC
X31
X30
X29
X28
X27
X26
X25
X24
X23
X22
X21
X20
X19
X18
XVDD
GND
X17
X16
X15
X14
X13
X12
X11
X10
X9
X8
X7
X6
X5
X4
X3
X2
X1
X0
NC
NC
Y61
Y62
Y63
DS0
AVDD
VDDIO
RESET
SCL/SCK
SDA/MOSI
VDDIO
GPIO0
/SS
ADDSEL/MISO
GPIO1
COMMSEL
GPIO2
CHG
GPIO3
GPIO4
GPIO5
DBG_SS/GPIO6
HSYNC
VSYNC
GND
VDDCORE
VDD
DBG_CLK
DBG_DATA
VDDIO
TEST
AVDD
Y32
Y31
Y30
Y29
NC
XVDD
VREGBOOST
AVDD
Y0
Y1
Y2
Y3
Y4
Y5
Y6
Y7
Y8
Y9
Y10
Y11
Y12
Y13
Y14
Y15
Y16
Y17
GND
AVDD
Y18
Y19
Y20
Y21
Y22
Y23
Y24
Y25
Y26
Y27
Y28
NC
NC
X32
XVDD
VDDCORE
AVDD
Y33
Y34
Y35
Y36
Y37
Y38
Y39
Y40
Y41
Y42
Y43
Y44
Y45
Y46
Y47
Y48
Y49
Y50
GND
AVDD
Y51
Y52
Y53
Y54
Y55
Y56
Y57
Y58
Y59
Y60
Top view
mXT2113TD-ATMK/mXT2113TD-ABMK
