Atmel-8961A-CPLD-ATF15xx-DK3-U-Development-Kit-UserGuide_072015
Introduction
The Atmel® ATF15xx-DK3-U Complex Programmable Logic Device (CPLD) Development/Programmer Kit is a
complete development system and an In-System Programming (ISP) programmer for the Atmel ATF15xx
Family of industry standard pin compatible CPLDs with Logic Doubling ® features. This kit provides designers a
very quick and easy way to develop prototypes and evaluate new designs with an ATF15xx ISP CPLD. The
ATF15xx Family of ISP CPLDs includes the Atmel ATF15xxAS, ATF15xxASL, ATF15xxASV, and
ATF15xxASVL CPLDs. With the availability of the different socket adapter boards to support most of the
package types(1) offered in the ATF15xx Family of ISP CPLDs, this kit can be used as an ISP programmer to
program the ATF15xx ISP CPLDs in most of the available package types(1) through the industry standard JTAG
interface (IEEE 1149.1).
Kit Contents
CPLD Development/Programmer Board (ATF15xx-DK3)
44-pin TQFP Socket Adapter Board (ATF15xxDK3-SAA44) (2)
ATF15xx USB-based JTAG ISP Download Cable (ATDH1150USB or ATDH1150USB-K)
Two Atmel 44-pin TQFP Sample Devices
Device Support
The ATF15xx-DK3-U CPLD Development/Programmer Kit supports the following devices in all currently
available Atmel speed grades and packages (except the 100-PQFP):
ATF1502AS/ASL
ATF1504AS/ASL
ATF1508ASV/ASVL
ATF1502ASV
ATF1504ASV/ASVL
ATF1508AS/ASL
1. The socket adapter board is not offered for the 100-pin PQFP.
2. Only the 44-pin TQFP Socket Adapter Board is included in this kit. Other socket adapter boards are sold separately. See
“Hardware Description” section for more information on socket adapter board ordering codes.
ATF15xx-DK3-U
CPLD Development/Programmer Kit
USER GUIDE
ATF15xx-DK3-U Development/Programmer Kit [USER GUIDE]
Atmel-8961A-CPLD-ATF15xx-DK3-U-Development-Kit-UserGuide_072015
2
Table of Contents
Kit Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
CPLD Development/Programmer Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Logic Doubling CPLDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
ATF15xx ISP Download Cable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
PLD Development Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Ordering Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Hardware Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
CPLD Development/Programmer Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
7-segment Displays with Selectable Jumpers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
LEDs with Selectable Jumpers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Push-button Switches with Selectable Jumpers for I/O Pins . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Push-button Switches with Selectable Jumpers for GCLR and OE1 Pins . . . . . . . . . . . . . . . . . . . . . 9
2MHz Oscillator and Clock Selection Jumper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
VCCIO and VCCINT Voltage Selection Jumpers and LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
ICCIO and ICCINT Jumpers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Voltage Regulators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Power Supply Switch and Power LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Power Supply Jack and Power Supply Header . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
JTAG ISP Connector and TDO Selection Jumper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Socket Adapter Board . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Atmel ATF15xx ISP Download Cable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Schematic Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
References and Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Atmel ProChip Designer Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Atmel WinCUPL Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Atmel ATMISP Software. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Atmel POF2JED Conversion Software. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Revision History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
3ATF15xx-DK3-U Development/Programmer Kit [USER GUIDE]
Atmel-8961A-CPLD-ATF15xx-DK3-U-Development-Kit-UserGuide_072015
Kit Features
CPLD Development/Programmer Board
10-pin JTAG-ISP Port
Regulated Power Supply Circuits for 9VDC Power Source
Selectable 5V, 3.3V, 2.5V, or 1.8V I/O Voltage Supply
Selectable 1.8V, 3.3V, or 5.0V Core Voltage Supply
44-pin TQFP Socket Adapter Board
Headers for I/O Pins of the ATF15xx Device
2MHz Crystal Oscillator
Four 7-segment LED Displays
Eight Individual LEDs
Eight Push-button Switches
Global Clear and Output Enable Push-button Switches
Current Measurement Jumpers
Logic Doubling CPLDs
ATF15xx ISP CPLD with Logic Doubling Architecture
ATF15xx ISP Download Cable
5V, 3.3V, 2.5V, or 1.8V ISP Download Cable for the Universal Serial Bus (USB) port of a PC
There are two versions of the ATF15xx USB ISP Download Cable; ATDH1150USB and
ATDH1150USB-K. They are built by two different vendors but have identical circuit design, and the
Atmel Ordering Code is ATDH1150USB. The ATDH1150USB-K is built by Kanda ( ) www.kanda.com
and it can be directly purchased from Kanda. More details are available online at
www.atmel.com/tools/ATDH1150USB.aspx.
PLD Development Software
The Atmel PLD development software tools are available online for PLD designer’s use of the ATF15xx
ISP CPLDs. Please reference the Overview document, “PLD Design Software Overview” available at:
http://www.atmel.com/images/atmel-3629-pld-design-software-overview.pdf
System Requirements
The minimum hardware and software required to program an ATF15xx ISP CPLD device designed
using the Atmel ProChip Designer Software on the CPLD Development/Programmer Board through
the Atmel ATMISP (ATF15xx CPLD ISP Software) are:
x86 or x64 Microprocessor-based Computer
Windows XP® or Windows 7
128-MByte RAM
500-MByte Free Hard Disk Space
Windows-supported Mouse
Available USB 1.1 / 2.0 / 3.0 Port
9VDC Power Supply with 500mA of Supply Current
SVGA Monitor (800 x 600 Resolution)
