Digital and Mixed-Signal
Rad-Hard ASICs
Aerospace and Defense
www.microchip.com
www.microchip.com
2
Long-Term Commitment to the Space Industry
With nearly 30 years of experience in the space industry, Atmel was recognized for delivering
leading-edge and highly integrated technology and solutions. In 2016, Atmel was acquired by
Microchip Technology Inc., a leading provider of microcontroller and analog semiconductors,
providing low-risk product development, lower total system cost and faster time to market for thousands of diverse customer
applications worldwide. Microchip is committed to continuing to support the space industry, delivering the same solutions and
services customers expect for Atmel î©›ight heritage Rad-Hard parts.
Fully designed, assembled, tested and qualiî©šed in Europe, Microchip's offering of rad-hard digital Application-Speciî©šc Integrated
Circuits (ASICs) is one of the most attractive and competitive on the market for the most critical applications. In order to meet the
needs of next-generation satellites and launchers, our ASIC platforms include:
• ATMX150RHA: improve integration with adaptable technology: a mixed-signal strategy with logic, Analog, 5V compatibility,
embedded Non-Voltatile Memory (NVM) option, high-voltage option and qualiî©šed IPs.
• AT65RHA: improve integration and computing power with thinner technology and high-speed links, reduction of power
consumption, offering a high level of system integration and increased computing power. The device is designed in 65 nm
technology, with up to 50 Mgates and more embedded features such as very high-speed serial links.
Questions? Email the Hotline at aerospace@nto.atmel.com.
ASIC Overview
ATC18RHA ATMX150RHA AT65RHA
Process Bulk CMOS SOI CMOS Bulk CMOS
Feature Size (µm) 0.18 0.15 0.065
Library Digital DigitalMixed-Signal
Gates (equivalent NAND2) 7M 22M 50M
Maximum Toggle Frequency 7.5 GHz 7.5 GHz 30 GHz
Gate Delay @25°C (ps) 40 40 15
Signal I/Os >400 >700 >1,000
Flip-Chip I/O Available N N Y
5V and HV (25/45/65V) Option N Y N
Speciî©…c I/Os LVDS, PCl LVDS, PCI, HSSL HSSL, LVDS, PCl
Supply Voltage Core – I/Os 1.8–3.3/2.5V 1.8–2.5/3.3/5V 1.2–1.8/2.5/3.3V
Power Consumption
(nW/gate/MHz) @20% Duty Cycle <10 <10 <0.5
Analog IPs PLL ADC, DAC, PLL, BG, MUX, COMP... PLL, Temp Sense
RAM Compiler Y Y Y
NVM N Y N
Rad Hardness
Functional TID (krads(Si)) 300 300 300
Latch Up (MeV/mg/cm2) ° ° °>95 @125 C* >95 @125 C>60 @125 C
Availability Now Now Now
Qualiî©…cation ESCC QML, QML-Q, QML-V,
QML-V RHA 2016 2017
Package
Qualiî©šed wire-bonding hermetic offer
• CQFP up to 352
• CLGA/CCGA 329, 472, 625
Qualiî©šed wire-bonding hermetic offer
• CQFP up to 352
• CLGA/CCGA 329, 472, 625 and 896 with
European Columns
• Dedicated package development on request
Flip Chip
hermetric offer
Space Heritage
Digital and Mixed-Signal Rad-Hard ASICs 3
Beneî·Ÿts of Microchip's Rad-Hard ASICs
• A qualied supply chain from design to qualied parts
• Digital and mixed-signal ASICs
• Multiple quality assurance levels: QML-Q/QML-V/ESCC
• Robust design library of cells and macros
• The ASIC platform is supported by a combination of
state-of-art third-party and proprietary design tools
from: Synopsys, Mentor and Cadence. The tools
from these suppliers collectively form the reference
tool î©›ows for both the front and back end.
• Robust design ow
• Guaranteed radiation performance
• Radiation hardening assurance
• SEL > 95 MeV/mg/cm²
• Congurable RAM compiler, NVM option
• Specic I/Os including HSSL, LVDS, PCI
• Large portfolio of space-qualied packages including
CQFP and CLGA/CCGA, as well as custom packages
FPGA Retargeting to ASIC
Retargeting an Field-Programmable Gate Array (FPGA) to an ASIC means beneî©šting from the technical advantages of ASICs, such
as faster and smaller chips with lower power consumption. It also offers improved reliability and radiation performance. Microchip
offers an FPGA retargeting service to reduce your cost and design resources.
• From RTL code to QML-certied ASIC
• Pin-to-pin compatibility with existing package
• Optimized replacement cost
• Low NRE cost due to SMPW management
• Lower power consumption
• Full European solution
ATMX150RHA
The ATMX150RHA is a mixed-signal ASIC offering high-
performance and high-density solutions for space applica-
tions. Covering solutions with up to 22 million routable gates,
SRAM/DPRAM generators and 32 KB NVM blocks as well
as a set of pre-qualiî©šed analog IPs, such as PLL, Analog-to-
Digital Converters (ADCs), and Digital-to-Analog Converters
(DACs). Regulators and more are under development.
Analog Function Main Characteristics
Voltage Regulator
Linear 1.8V 50 mA
Linear 1.8V 200 mA
Voltage Reference/
Monitoring
Bandgap reference
Temperature sensor
Clock Synthesizer
PLL 40–50 MHz
RC oscillator 4/8/10/12 MHz
RC oscillator 10 MHz
Signal Conditioning
12-bit ADC
12-bit DAC
Analog multiplexer
Space Multi-Project Wafer (SMPW)
To reduce ASIC development costs, a Space Multi Projects
Wafer (SMPW) service is used. These quarterly SMPWs are
also used to embark, at low cost, customer analog test chips
intended for evaluating analog-sensitive areas from the î©šnal
ASIC. Microchip offers probe/packaging/assembly/test
services as well as qualiî©šcation services (reliability, TID,
SEE, etc.).
RTAX/ SX RT
Checklist
and CodeRTL
Feasibility
Analysis
DSR
Meeting
Retargeting
to ASIC
DR
Meeting
Prototypes
Customer
Validation
Microchip
Customer
Digital and Mixed-Signal Rad-Hard ASICs
