Seite 1/8
NITROGEN
INFUSION MODULE
I N S T A L L AT I O N , U S E & M A I N T E N A N C E G U I D E
JT-NIM
SAFETY FIRST!
READ INSTRUCTIONS COMPLETELY
Before getting started please read this
user manual and at all times follow
the important safety instructions.
v1.3 Certied by the
National Sanitation Foundation
2 | NITROGEN INFUSION MODULE INSTALLATION, USE & MAINTENANCE GUIDE MICROMATIC.COM / (866) 327-4159
PART LIST OVERVIEW .....................................................................................3
INSTALLATION OVERVIEW .......................................................................... 4-5
ROUTINE MAINTENANCE & CLEANING ....................................................... 6-7
WARRANTY INFORMATION .............................................................................8
TABLE OF CONTENTS
MICROMATIC.COM (866) 327-4159 NITROGEN INFUSION MODULE INSTALLATION, USE & MAINTENANCE GUIDE/ | 3
ITEM QTY PART NUMBER DESCRIPTION
1 1 JESF-4 (Included w/ Tower) FAUCET STOUT SS/POL w/ Stainless Steel
Spout
2 1 4332 (Part of D5N-ARF) (Included w/ Tower) Coupling Nut
3 1 D6P3C (Part of D5N-ARF) (Included w/ Tower) Chrome Outside Flange
4 1 D7P (Part of D5N-ARF) (Included w/ Tower) Inside Tower Flange ABS
5 1 D8 (Part of D5N-ARF) (Included w/ Tower) Tower Shank Nut
6 1 4329-JE (Part of D5N-ARF) (Included w/ Tower) Spin Stop Shank
7 1 105SL (Included w/ Tower) Clamp-Stepless for 1/4" I.D. POLY
8 1 548GENX (Included w/ Tower) Clamp-Stepless for 1/4" I.D. POLY
91 PI201612S (Included with JT-NIM) John Guest Fitting 3/8" O.D. to 1/2" O.D.
10 1 01752322C (Included with JT-NIM) Accumulator
11 1 JT-NIM Nitrogen Infusfusion Module
12 1 548GENX (Included with JT-NIM) 1/4" GENX Tubing
13 1 ADMF0606-200 filter (Included with JT-NIM) Inline Filter/Strainer
ITEM QTY PART NUMBER DESCRIPTION
14 1 548GENX (Included with JT-NIM) 1/4" GENX Tubing
15 1 105SL Clamp-Stepless for 1/4" I.D. Poly
16 1 HBF100L (For use with Corney Keg) Corney Keg Ball Lock Liquid Connection (Black)
17 1 HBF100G (For use with Corney Keg) Corney Keg Ball Lock Gas Connection (Grey)
18 1 7485SS (For use with Beverage Tank™) DISP HEAD MF-D ALL SS (GRAY
HANDLE) SS304 PROBE
19 1 759 (For use with Beverage Tank™) Neoprene Coupling Washer
20 1 526BS-304 (For use with Beverage Tank™) 1/4" Stainless Steel Tail Piece
21 1 874 (for use with Beverage Tank™) Coupling Hex Nut Chrome Plated Brass
22 1 170SL Clamp Stepless for 5/16" Vinyl
23 1 553B1200 (Included with JT-NIM) 5/16" Blue Vinyl Gas Tubing
24 1 553B1200 (Included with JT-NIM) 5/16" Blue Vinyl Gas Tubing
25 1 170SL Clamp Stepless for 5/16 Vinyl Gas Hose
26 1 842N Gas Regulator High Pressure Nitrogen Primary
PART LIST OVERVIEW
