Seite 1/48
W 6VM • W 6V4 • W 6VA4
W 6VB3 • W 8VB2
Model Screw Driver
Modèle Visseuse
Modelo Atornillador
DOUBLE INSULATION
DOUBLE ISOLATION
AISLAMIENTO DOBLE
MODE D’EMPLOI ET INSTRUCTIONS DE SECURITE
AVERTISSEMENT
Une utilisation incorrecte et dangereuse de cet outil motorisé peut entraîner la
mort ou de sérieuses blessures corporelles!
Ce mode d’emploi contient d’importantes informations à propos de la sécurité de
ce produit. Prière de lire et de comprendre ce mode d’emploi avant d’utiliser l’outil
motorisé. Garder ce mode d’emploi à la disponibilité des autres utilisateurs avant
qu’ils utilisent l’outil motorisé.
INSTRUCTION MANUAL AND SAFETY INSTRUCTIONS
WARNING
Improper and unsafe use of this power tool can result in death or serious bodily
injury!
This manual contains important information about product safety. Please read
and understand this manual before operating the power tool. Please keep this
manual available for others before they use the power tool.
MANUAL DE INSTRUCCIONES E INSTRUCCIONES DE SEGURIDAD
ADVERTENCIA
¡La utilización inapropiada e insegura de esta herramienta eléctrica puede resultar
en lesiones serias o en la muerte!
Este manual contiene información importante sobre la seguridad del producto.
Lea y comprenda este manual antes de utilizar la herramienta eléctrica. Guarde
este manual para que puedan leerlo otras personas antes de que utilicen la
herramienta eléctrica.
W6VM • W6V4 • W6VA4 W6VB3 • W8VB2
2
CONTENTS
English
Page
IMPORTANT SAFETY INFORMATION .........
3
MEANINGS OF SIGNAL WORDS .......... 3
SAFETY ................................................... 3
GENERAL POWER TOOL
SAFETY WARNINGS ....................... 3
SPECIFIC SAFETY RULES AND SYMBOLS ...
4
DOUBLE INSULATION FOR SAFER
OPERATION ..................................... 5
FUNCTIONAL DESCRIPTION ................ 7
NAME OF PARTS ................................ 7
SPECIFICATIONS ................................ 7
Page
ASSEMBLY AND OPERATION .............. 8
APPLICATIONS ................................... 8
PRIOR TO OPERATION ....................... 8
HOW TO USE THE SCREW DRIVER...
10
MOUNTING AND DISMOUNTING
THE HEX-SOCKET OR BIT ........... 11
MAINTENANCE AND INSPECTION .... 12
ACCESSORIES ...................................... 13
STANDARD ACCESSORIES ............. 13
OPTIONAL ACCESSORIES ............... 14
PART LIST ............................................. 40
TABLE DES MATIERES
Français
Page
INFORMATIONS IMPORTANTES DE SÉCURITÉ ...
15
SIGNIFICATION DES MOTS D’AVERTISSEMENT....
15
SECURITE ............................................. 15
AVERTISSEMENTS DE SÉCURITÉ GÉNÉRAUX
CONCERNANT LES OUTILS ÉLECTRIQUES .......
15
REGLES DE SECURITE SPECIFIQUES ET SYMBOLES ....
17
DOUBLE ISOLATION POUR UN
FONCTIONNEMENT PLUS SUR ...
18
DESCRIPTION FONCTIONNELLE ........ 19
NOM DES PARTIES .......................... 19
SPECIFICATIONS .............................. 19
Page
ASSEMBLAGE ET FONCTIONNEMENT ....
20
APPLICATIONS ................................. 20
AVANT L’UTILISATION .................... 20
COMMENT UTILISER LA VISSEUSE
.. 22
MONTAGE ET DEMONTAGE DU MANCHON
SIX PANS OU DE LA MECHE
.................
23
ENTRETIEN ET INSPECTION ............... 24
ACCESSOIRES ...................................... 25
ACCESSOIRES STANDARD ............. 25
ACCESSOIRES SUR OPTION ........... 26
LISTE DES PIECES ............................... 40
ÍNDICE
Español Página
INFORMACIÓN IMPORTANTE SOBRE SEGURIDAD ...
27
SIGNIFICADO DE LAS PALABRAS DE SEÑALIZACIÓN ....
27
SEGURIDAD ......................................... 27
ADVERTENCIAS DE SEGURIDAD GENERAL
DE LA HERRAMIENTA ELÉCTRICA ...........
27
NORMAS Y SÍMBOLOS ESPECÍFICOS DE SEGURIDAD
..... 29
AISLAMIENTO DOBLE PARA OFRECER UNA
OPERACIÓN MÁS SEGURA
................... 30
DESCRIPCIÓN FUNCIONAL ................ 31
NOMENCLATURA ............................. 31
ESPECIFICACIONES .......................... 31
Página
MONTAJE Y OPERACIÓN ................... 32
APLICACIONES ................................. 32
ANTES DE LA OPERACIÓN .............. 32
COMO USAR EL DESTORNILLADOR
... 34
MONTAJE Y DESMONTAJE DEL PORTATORNILLOS
HEXAGONAL O DE LA BROCA
................... 36
MANTENIMIENTO E INSPECCIÓN ..... 37
ACCESORIOS ....................................... 38
ACCESORIOS ESTÁNDAR ............... 38
ACCESORIOS OPCIONALES ............ 39
LISTA DE PIEZAS ................................. 40
3
English
IMPORTANT SAFETY INFORMATION
Read and understand all of the safety precautions, warnings and operating instructions in the Instruction Manual
before operating or maintaining this power tool.
Most accidents that result from power tool operation and maintenance are caused by the failure to observe basic
safety rules or precautions. An accident can often be avoided by recognizing a potentially hazardous situation
before it occurs, and by observing appropriate safety procedures.
Basic safety precautions are outlined in the “SAFETY” section of this Instruction Manual and in the sections which
contain the operation and maintenance instructions.
Hazards that must be avoided to prevent bodily injury or machine damage are identified by WARNINGS on the
power tool and in this Instruction Manual.
NEVER use this power tool in a manner that has not been specifically recommended by .metabo HPT
MEANINGS OF SIGNAL WORDS
WARNING indicates a potentially hazardous situations which, if ignored, could result in death or serious injury.
CAUTION indicates a potentially hazardous situations which, if not avoided, may result in minor or moderate
injury, or may cause machine damage.
NOTE emphasizes essential information.
SAFETY
GENERAL POWER TOOL SAFETY WARNINGS
WARNING:
Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery-operated
(cordless) power tool.
1) Work area safety
a) Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust.
Power tools create sparks which may ignite
the dust or fumes.
c) Keep children and bystanders away while
operating a power tool.
Distractions can cause you to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet.
Never modify the plug in any way.
Do not use any adapter plugs with earthed
(grounded) power tools.
Unmodified plugs and matching outlets will
reduce risk of electric shock.
b) Avoid body contact with earthed or grounded
surfaces such as pipes, radiators, ranges and
refrigerators.
There is an increased risk of electric shock if
your body is earthed or grounded.
c) Do not expose power tools to rain or wet
conditions.
Water entering a power tool will increase the
risk of electric shock.
d) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges
or moving parts.
Damaged or entangled cords increase the risk
of electric shock.
e) When operating a power tool outdoors, use
an extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces
the risk of electric shock.
f) If operating a power tool in a damp location
is unavoidable, use a residual current device
(RCD) protected supply.
Use of an RCD reduces the risk of electric shock.
3) Personal safety
a) Stay alert, watch what you are doing and use
common sense when operating a power tool.
Do not use a power tool while you are tired
or under the influence of drugs, alcohol or
medication.
