How to recycle your equipment

The symbol shown here and on the

product means that the product is

classed as electrical or electronic

equipment, so DO NOT put it in

your normal rubbish bin.

It’s all part of the Waste Electrical and

Electronic Equipment (WEEE) Directive to

recycle products in the best way – to be

kinder to the planet, get rid of dangerous

things more safely and bury less rubbish

in the ground.

You should contact your retailer or

supplier for advice on how to dispose

of this product in an environmentally

friendly way.

Radio Equipment Directive

Declaration of Conformity

Hereby, British Telecommunications plc

declares that the radio equipment type BT

Video Baby Monitor 4000 (092661) is in

compliance with Directive 2014/53/EU.

The item code for the Baby

unit power supply is 089009

(BLJ06W050600P1-B) and the Parent

unit is 089010 (BLJ06W050100P1-B).

The full text of the EU declaration of

conformity is available at the following

internet address: bt.com/producthelp

Radio transmission information

Frequency

range

2415.375-2471.625 MHz

Max power 81.28mW (19.1dBm)

General information

Welcome

Thanks for buying a BT Baby Monitor. You’ll soon

be able to relax knowing you can watch and listen

for your baby’s every breath, gurgle and wriggle.

But rst things rst. To get set up, just follow the steps

opposite. If you need any help, go to bt.com/producthelp

or give us a call on 0808 100 6554*.

Getting set up

Registered Oce: 81 Newgate Street, London EC1A 7AJ. Registered in England No. 1800000

Designed and produced by The Art & Design Partnership (ADP). Printed in China / Issue 1 / ADP10-17

Important safety notices

1. Your baby monitor is designed as just an aid.

It isn’t a substitute for responsible and proper

adult supervision.

2. Make sure all cables and units are out of your baby’s

reach – at least one metre away. Keep the power cord

out of baby’s reach by looping any extra length and

securing it.

3. Never cover either unit, put them in moist places or

inside the cot, bed or playpen.

4. If you travel abroad, check the voltage on your unit’s

plugs match the local power output.

5. Do not take the product apart. You can’t change

the battery installed in the Parent unit. If you need

repairs, get in touch with our helpdesk.

1 Match the picture on top of the power supply with the

image below, connect it to the Parent unit, plug it into

the power socket and switch on.

2 Leave to charge for .12 hours

Tip

The rst time you use the Parent unit, or if you haven’t

used it for a long time, it’ll take 12 hours to fully charge.

The battery life on a single charge lasts for 4 hours.

We recommend you keep the cable plugged into the

mains power socket if you’re going to use for longer than

this or throughout the night.

When the battery gets very low, it’ll take about 30

minutes to charge enough for you to use it for a

short time. To charge the Parent unit in the shortest

amount of time, turn it o while it’s charging.

3 Place the Baby unit near a power socket in the room

where you’re going to be monitoring your baby most of

the time. It should also be at least one metre away from

your baby.

4 Match the picture on top of the power supply with the

image below, connect it to the Baby unit, plug it into the

power socket and switch on.

5 Slide the

Oﬀ

button on the side of the Baby unit

up to turn it on.

Information

The item code for the Baby unit power supply is 089009

and the Parent unit is 089010.

Link

Troubleshooting

My Parent/Baby unit isn’t working. What should I do?

Check that:

1 power cables are plugged in and switched on at the

wallsocket

2 the Baby unit is plugged in and the Parent unit battery

is fully charged (for 12 hours)

3 both units are turned on

4 the Parent unit isn’t too far from the Baby unit (large

obstructions or other electrical devices might aect the

signal between the Parent and Baby unit).

5 unplugging the power cables, waiting about 15 seconds,

and then plugging them back in can help.

My Parent/Baby unit is making a high-pitched noise.

Whatshould I do?

The units might be too close together. Make sure they’re

at least one metre apart, even when you’re using the

button.

Why is my Parent unit beeping?

The Parent unit beeps when:

• the Baby unit is turned o

• the units are too far apart – try moving them closer

together (but not closer than one metre)

• the battery in the Parent unit isn’t charged – try charging

it for 12 hours

• Other electronic items, like TVs and mobile phones, are

causing interference – try moving the Baby unit away

from things like that.

Why is the Parent unit not making any sounds even

though there’s noise coming from my baby’s room?

• the Parent unit might not be fully charged – make sure

it’s charged (for 12 hours).

• the speaker volume might be switched o.

• the Parent unit might be out of range of the Baby unit –

try moving it closer (but not closer than one metre).

• large obstructions or other electrical devices might

be aecting the signal between the Parent and Baby

units). Try moving the Baby unit away from obstructions,

including electrical appliances like TVs or mobile phones.

6 After the Parent unit has charged for 12 hours you can

switch it on.

Before you do, move the Parent unit at least one metre

from the Baby unit. Any closer and you might get audio

feedback sounds.

Press the button and hold for 2 seconds to turn the

Parent unit on.

The Parent and Baby unit are automatically linked so

they are now ready to use.

What’s the range?

The maximum range between your Parent and Baby

units is about 250 metres outdoors and about 50 metres

indoors. Thick walls and doors reduce the units’ range

and aect how they link to each other.

Guarantee

Your Video Baby Monitor 4000 is

guaranteed for a period of 24 months

from the date of purchase.

Subject to the terms listed below, the

guarantee will provide for the repair of,

or at BT’s or its agent’s discretion the

option to replace the Video Baby Monitor

4000, or any component thereof, which

is identied as faulty or below standard,

or as a result of inferior workmanship or

materials. Products over 28 days old from

the date of purchase may be replaced

with a refurbished or repaired product.

The conditions of this guarantee are:

• The guarantee shall only apply to

defects that occur within the 24 month

guarantee period.

• Proof of purchase is required.

• The equipment is returned to BT or its

agent as instructed.

This guarantee does not cover any faults

or defects caused by accidents, misuse,

fair wear and tear, neglect, tampering

with the equipment, or any attempt at

adjustment or repair other than through

approved agents.

This guarantee does not aect your

statutory rights.

To nd out what to do, if your monitor is

in or outside of the 24 month guarantee,

go to bt.com/producthelp

Mic

Talk

Need some help?

Frequently asked questions are available online.

bt.com/producthelp

If you cannot nd the answer to your question online,

call our free Helpline. Our dedicated advisors are more

likely to be able to help you than the retailer where you

bought your baby monitor.

0808 100 6554*

This user guide is also available in other formats: large

print, Braille and audio CD. Call the helpline for a copy.

* Calls made from within the UK mainland network are free.

Mobile and international call costs may vary.

Video Baby Monitor 4000

User Guide

Mic

Talk

Set a reminder

You can set an alert to remind you of something you need to do, for

example when your baby’s next feed is due. You can set it for 2, 4 or

6 hours.

1. Press

, then press to display .

2. Press or to select the reminder time ( , or ), 2H 4H 6H

then press OK to save. The will be displayed on the top right

of the screen.

3. To cancel the alert, select .

Set the screen to turn on and o automatically

You can set the screen to turn on by pressing any button. On this

setting, the screen will turn o automatically when no button is

pressed during 1, 3 or 5 minutes.

1. Press

, then press to display .

2. Press and to select , or minutes and press 1 3 5

3. To turn the screen back on at any time, press any button. If you want

to set the screen on all the time, set the screen setting . to o

Turn sound activated screen mode on or o

When set to On, the screen will turn on if noise is detected from the

Baby unit. If it’s set to O, the screen will stay o even if noise is

detected. To use this feature, you need to set the standby mode rst

to 1, 3 or 5 minutes as described above.

1. Press

, then press to display .

2. Press or to select (for On) or (for O) and press OK .

3. To turn the screen back on at any time, press the .

Temperature sensor

The reading from the temperature sensor will be displayed at the top

of the Parent unit screen.

To change the temperature display from C to F:

1. Press , then press to display and press .

2. Press or to select or , then press .°C °F

Other screen icon descriptions

Get to know your Baby unit

Get to know your Parent unit

Sound level

display

LED lights

show the level

of sound being

detected from

the Baby unit.

Press and hold to turn

the unit on and o.

Press once to switch

to standby mode.

Press to

open/exit the

main menu.

Press and hold to

talk to your baby.

Speaker

Microphone

Press to move

left or right in the

menu or to increase

or decrease the

brightness level.

Press to scroll up

or down when

you’re in the menu.

Press to increase

or decrease the

speaker volume.

Power socket

Press to select an

option in the menu.

Using the Parent unit

Turn on and o

Press and hold for 2 seconds to turn on and o.

Using the menu

• Press

to open the main menu. Scroll through the menu options

across the bottom of the screen using

and . When the menu option you want is highlighted, use

or to scroll through the sub menus and press OK to select.

• Press

to exit the menu and return to the main monitoring screen.

Monitoring volume and mute

There are 8 volume settings. The default is 4.

1. In monitor mode, press or to change the volume.

2. Press OK to conrm.

3. To turn the sound o completely, turn the volume down

to 0. will be displayed on top of the screen.

Screen brightness

There are 8 brightness levels. The default is 4.

1. In monitor mode, press or to select the brightness level.

2. Press

to conrm.

Lullabies

There are 5 lullabies to choose from or you can play all 5 in sequence.

1. Press

, is displayed.

2. Press or to choose the lullaby 1-5 or press to play all ve,

then press OK .

3. Press or to select the volume from 1-3 and press

to save.

4. To stop the lullaby playing, select .

Talk to your baby

To give your baby some words of comfort, press and hold down Talk

on the Parent unit and speak into the Parent unit’s microphone.

The icon will be displayed at the bottom right corner. Release the

button when you’ve nished speaking.

Zoom in and out

To enter zoom mode, press

, then press to display ,

then press or to select the zoom level and press OK to

exit menu.

Charging/

battery light

Blue when mains

power adapter

is on, red when

battery low.

Power on light

Green when Parent

unit turned on.

(Remains green for one

minute while charging,

after the Parent unit

is turned o).

Stand

Using the Baby unit

Turn on and o

1. Slide the

Oﬀ

button on the side of the Baby unit up to turn

on and down to turn o.

Night vision

So that you can see your baby at night, the Baby unit automatically

uses the light from its infrared LED lights to capture images in a dark

room. Because of that, it can only show images in black and white.

The icon will be displayed at the top of the screen.

Signal strength

Baby unit switched on

Camera identication

number e.g. Camera 1

Sound on

Mute

Battery status (Full battery shown,

scrolling when charging)

Oﬀ

Link

OnOﬀ

Power on/o

Slide button up to

turn on and slide

down to turn o.

Temperature

sensor

Manual pan and tilt

Gently move

the camera to

adjust the angle.

Camera

Power socket

Link button

The units are pre-linked.

(Link button used if re-link ever required).

Add camera Delete camera View camera

Produktspezifikationen

Marke:	Metabo
Kategorie:	Schleifmaschine
Modell:	GVB 18 LTX BL 11-28

Brauchst du Hilfe?

Wenn Sie Hilfe mit Metabo GVB 18 LTX BL 11-28 benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten

Ihren Namen*

Deine E-Mail*

Schreiben Sie hier Ihre Frage

Bedienungsanleitung Schleifmaschine Metabo

Metabo WP820-115 Bedienungsanleitung

8 Oktober 2024

Metabo W 24-180 MVT Bedienungsanleitung

9 September 2024

Metabo DSD 250 Bedienungsanleitung

6 September 2024

Metabo BS 175 Bedienungsanleitung

6 September 2024

Metabo G 13SC2 Bedienungsanleitung

30 August 2024

Metabo G13BYEQ2 Bedienungsanleitung

28 August 2024

Metabo GVB 18 LTX BL 11-28 Compact Bedienungsanleitung

28 August 2024

Metabo GVB 18 LTX BL 11-28 Bedienungsanleitung

27 August 2024

Metabo DS 125 Bedienungsanleitung

26 August 2024

Metabo DSD 200 Bedienungsanleitung

25 August 2024

Bedienungsanleitung Schleifmaschine

Neueste Bedienungsanleitung für -Kategorien-

Makita GA9060R Bedienungsanleitung

15 Oktober 2024

Hitachi G 13SR Bedienungsanleitung

14 Oktober 2024

Makita DGA700Z Bedienungsanleitung

13 Oktober 2024

DeWalt DW887N Bedienungsanleitung

7 Oktober 2024

Milwaukee 0725-21 Bedienungsanleitung

5 Oktober 2024

Makita GA013GD101 Bedienungsanleitung

3 Oktober 2024

Milwaukee 2784-20 Bedienungsanleitung

3 Oktober 2024

Ryobi RAG800-115 Bedienungsanleitung

2 Oktober 2024

Makita GA022GD202 Bedienungsanleitung

2 Oktober 2024

Hilti GDG 6-A22 Bedienungsanleitung

30 September 2024
