Seite 1/2
marvelrefrigeration.com | 800.223.3900
Performance
Dynamic Cooling Technology
delivers the industry’s best
temperature stability and rapid cool down, tested and proven
to cool nearly 2x faster than competitors
Now even quieter operation thanks to exclusive design
enhancements to buffer and minimize sound
Storage Capabilities
4.6 cu. ft. capacity, stores (118) 12-oz cans
(1) full-width and (1) half-width cantilevered, fully adjustable white
steel-framed glass shelves and (1) xed white steel-framed glass
shelf
Tall item storage: half-width interior shelf allows for high-clearance
vertical storage
MaxStore smooth-glide clear bin organizes loose, bulky items;
capable of storing 15 lbs of produce, 4 wine bottles or 22 cans
Touchpad Controls
Multifunction Marvel Intuit
Integrated Controls allow you to select a
precise cabinet temperature from 3F to 42° F
Vacation mode conserves energy during times when unit
is not in use
Aesthetics
Pristine white interior easily wipes clean and efcient arctic white
LED lighting illuminates interior for better viewing
Easy-to-install panel overlay option features soft-close integrated
hinge for a truly ush t with cabinetry
Finish options: stainless steel, black or overlay (panel ready)
Additional Convenience
Low prole, ADA-compliant height allows for universal installation
applications
Close Door Assist System gently and automatically draws door to a
close, ensuring door is never accidentally left ajar
Black toe kick adjustable to 4” with leveling legs
1-year parts and labor warranty, 5-year sealed system parts warranty
24 Marvel Low Prole All
Refrigerator with MaxStoreBin
Model # MA24RA
Ordering Options
Solid Stainless Steel Door with Lock, Right Hinge,
Stainless Designer Handle MA24RAS2RS
Solid Stainless Steel Door with Lock, Left Hinge,
Stainless Designer Handle MA24RAS2LS
Solid Smooth Black Door with Lock, Right Hinge, Black
Designer Handle MA24RAS2RB
Solid Smooth Black Door with Lock, Left Hinge, Black
Designer Handle MA24RAS2LB
Panel-Ready Solid Overlay Door with Lock, Integrated
Right Hinge (Handle Not Included)* MA24RAP3RP
Panel-Ready Solid Overlay Door with Lock, Integrated
Left Hinge (Handle Not Included)* MA24RAP3LP
*Easy installation! No panel kit required. Consult your cabinet maker for overlay
panel and handle options.
Built in the USA
ADA
Height
ADA
Height
23 7/8" W
31" H
25 5/8” D
including
handle
Solid Overlay
(Panel Ready)*
BlackStainless Steel
Finish Options
marvelrefrigeration.com | 800.223.3900
Rough-In Dimensions
A. Rough-In Width 24”
B. Rough-In Height 31 5/8” to 32 5/8
C. Rough-In Depth 24”
Product Dimensions
D. Width 23 7/8”
E. Height 31 1/8” to 32 1/8
F. Depth 21 1/2”
G. Depth to Front of Door
Solid Door 23 23/32”
Overlay Door
22 7/8”
Without
Handle
H. Depth to Handle 25 21/32” (Stainless Steel)
I. Depth with door at 90˚
Solid Door 46 13/32”
Overlay Door 46 1/2
Product Features
Interior Cabinet Finish White
Capacity Up to 118 12-oz cans
Shelving System Cantilever
Shelf Fronts White Steel Framed
Other Storage MaxStore Bin,
Door Storage
Interior Lighting White LED
Toe Grill Finish Black
Hinge Classic Hinge
Handle
Slim Designer Handle
(Panel Overlay Does
Not Include Handle)
Control Type Intuit
Temperature Range 34° to 42° F
Lock No
Electrical Requirements 120V / 60Hz / 15A
Length of Power Cord 6’
Shipping Weight 160 lbs
Finishes Stainless Steel, Overlay, Black
Vacation Mode Yes
Agency Approvals CSA, ENERGY STAR
"A"
"B"
"C"
"D"
"E"
"F"
"I""G"
"H"
Product Dimensions
For comprehensive installation instructions, please visit
www.marvelrefrigeration.com to access the owner’s guide.
Left Hand Hinged Door
24" (61 cm) wide appliance
Right Hand Hinged Door
24" (61 cm) wide appliance
233⁄ "4
(60.3 cm)
1" (2.5 cm) diameter
x 1⁄ " (6 mm) deep4
4 places
47⁄ "8
(12.4 cm)
13⁄ "16
(3 cm)
14"
(35.6 cm)
1⁄ " (6 mm)4
radius is
permissible
31
8"
(7.9 cm)
13⁄ "4
(4.4 cm)
2"
(5.1 cm)
311
⁄ "16
(9.4 cm)
11⁄ "2
(3.8 cm)
typical
1⁄ "4
(6 mm)
Deep
1
11
⁄ "16
(4.3 cm)
Hinge side of door
Top of door
Clearance for hinge
at top and bottom
Clearance for hinge
at top and bottom
Clearance for
screw head,
4 places
Left Hand Hinged Door
24" (61 cm) wide appliance
233⁄ "4
(60.3 cm)
1" (2.5 cm) diameter
x 1⁄ " (6 mm) deep4
4 places
47⁄ "8
(12.4 cm)
13
16
"
(3 cm)
14"
(35.6 cm)
1⁄ " (6 mm)4
radius is
permissible
3
1⁄ "8
(7.9 cm)
13⁄ "4
(4.4 cm)
2"
(5.1 cm)
3
11⁄ "16
(9.4 cm)
11⁄ "2
(3.8 cm)
typical
1⁄ "4
(6 mm)
Deep
111
⁄ "16
(4.3 cm)
Hinge side of door
Top of door
Clearance for
screw head,
4 places
Right Hand Hinged Door
24" (61 cm) wide appliance
This side
facing interior
This side
facing interior
15⁄ "32
(2.9 cm)
15⁄ "32
(2.9 cm)
3011
⁄ "32
(77.1 cm)
3011
⁄ "32
(77.1 cm)
Panel Overlay Dimensions
27
23
/32
(70.56 cm)
27
23/32
(70.56 cm)
