Seite 1/2
marvelrefrigeration.com | 800.223.3900
Performance
Dynamic Cooling Technology
delivers the industry’s best
temperature stability and rapid cool down, tested and proven
to cool nearly 2x faster than competitors
Thermal-efcient cabinet ensures optimum preservation
and energy efciency while maximizing capacity
Now even quieter operation thanks to exclusive design
enhancements to buffer and minimize sound
Storage Capabilities
5.1 cu. ft. capacity, stores (115) 12-oz cans
MaxStore smooth-glide clear bin organizes loose, bulky items;
capable of storing 15 lbs of produce, 4 wine bottles or 22 cans
Tall item storage: half-width interior shelf and extra door storage
allows for high-clearance vertical storage
Also includes (1) cantilevered, fully adjustable white steel-framed
glass shelf and (1) xed steel-framed glass shelf
Touchpad Controls
Multifunction Marvel Intuit
Integrated Controls allow you to select a
precise cabinet temperature from 3F to 42° F
Vacation mode conserves energy during times when unit
is not in use
Aesthetics
Pristine white interior easily wipes clean
Efcient arctic white LED lighting illuminates interior
for better viewing
Easy-to-install panel overlay option features soft-close integrated
hinge for a truly ush t with cabinetry
Finish options: stainless steel, black or overlay (panel ready)
Additional Convenience
Close Door Assist System gently and automatically draws door to a
close, ensuring door is never accidentally left ajar
Black toe kick adjustable to 4” with leveling legs
1-year parts and labor warranty, 5-year sealed system parts warranty
24” Marvel All Refrigerator
with MaxStore Bin
Model # ML24RA
23 7/8" W
33 3/4" H
25 5/8” D
including
handle
Ordering Options
Solid Stainless Steel Door, Right Hinge,
Stainless Designer Handle ML24RAS2RS
Solid Stainless Steel Door, Left Hinge,
Stainless Designer Handle ML24RAS2LS
Solid Smooth Black Door, Right Hinge,
Black Designer Handle ML24RAS2RB
Solid Smooth Black Door, Left Hinge,
Black Designer Handle ML24RAS2LB
Panel-Ready Solid Overlay Door,
Integrated Right Hinge* ML24RAP3RP
Panel-Ready Solid Overlay Door,
Integrated Left Hinge* ML24RAP3LP
*Easy installation! No panel kit required. Consult your cabinet maker for overlay
panel and handle options.
Built in the USA
Stainless Steel Solid Overlay
(Panel Ready)*
Black
Finish Options
marvelrefrigeration.com | 800.223.3900
Left Hand Hinged Door
24" (61 cm) wide appliance
Right Hand Hinged Door
24" (61 cm) wide appliance
233⁄ "4
(60.3 cm)
1" (2.5 cm) diameter
x 1 " (6 mm) deep4
4 places
47⁄ "8
(12.4 cm)
13⁄ "16
(3 cm)
14"
(35.6 cm)
1⁄ " (6 mm)4
radius is
permissible
31
8"
(7.9 cm)
13⁄ "4
(4.4 cm)
2"
(5.1 cm)
311⁄ "16
(9.4 cm)
11⁄ "2
(3.8 cm)
typical
1⁄ "4
(6 mm)
Deep
1
11⁄ "16
(4.3 cm)
Hinge side of door
Top of door
Clearance for hinge
at top and bottom
Clearance for hinge
at top and bottom
Clearance for
screw head,
4 places
Left Hand Hinged Door
24" (61 cm) wide appliance
233⁄ "4
(60.3 cm)
1" (2.5 cm) diameter
x 1 " (6 mm) deep4
4 places
47⁄ "8
(12.4 cm)
13
16
"
(3 cm)
14"
(35.6 cm)
1⁄ " (6 mm)4
radius is
permissible
3
1⁄ "8
(7.9 cm)
13⁄ "4
(4.4 cm)
2"
(5.1 cm)
3
11 ⁄ "16
(9.4 cm)
1
1⁄ "2
(3.8 cm)
typical
1⁄ "4
(6 mm)
Deep
111⁄ "16
(4.3 cm)
Hinge side of door
Top of door
Clearance for
screw head,
4 places
Right Hand Hinged Door
24" (61 cm) wide appliance
This side
facing interior
This side
facing interior
15⁄ "32
(2.9 cm)
15⁄ "32
(2.9 cm)
3011⁄ "32
(77.1 cm)
3011
⁄ "32
(77.1 cm)
Panel Overlay Dimensions
Rough-In Dimensions
A. Rough-In Width 24”
B. Rough-In Height
Solid Door 34” to 35”
Overlay Door 34 1/4” to
35 1/4”
C. Rough-In Depth 24”
Product Dimensions
D. Width 23 7/8
E. Height
Solid Door 33 3/4” to
34 3/4”
Overlay Door 34” to 35”
F. Depth 21 1/2
G. Depth to Front of Door
Solid Door 23 23/32”
Overlay Door
22 7/8”
Without
Handle
H. Depth to Handle 25 21/32” (Stainless Steel)
I. Depth with door at 90˚
Solid Door 46 13/32”
Overlay Door 46 1/2”
Product Features
Interior Cabinet Finish Black
Capacity Up to 115 12-oz cans
Shelving System Cantilever
Shelf Fronts White Steel-Framed
Other Storage MaxStore Bin,
Door Storage
Interior Lighting White LED
Toe Grill Finish Black
Hinge Classic Hinge
Handle
Slim Designer Handle
(Panel Overlay Does
Not Include Handle)
Control Type Intuit
Temperature Range 34° to 42° F
Lock No
Electrical Requirements 120V / 60Hz / 15A
Length of Power Cord 6’
Shipping Weight 160 lbs
Finishes Stainless Steel, Overlay, Black
Vacation Mode Yes
Agency Approvals CSA, ENERGY STAR
"A"
"B"
"C"
"D"
"E"
"F"
"I""G"
"H"
Product Dimensions
For comprehensive installation instructions, please visit
www.marvelrefrigeration.com to access the owner’s guide.
