Martin Pantograph
Installation Instructions
The Martin Pantograph is specifically designed for hanging Martin luminaires from
ceilings or other load-bearing structural elements. It may be used to suspend a
fixture weighing up to 22 kg (48 lbs), and provides a drop from the ceiling to the
attachment point of 12 to 62 cm (4.75 - 24.4 in.).
Warning: Never place your hands between the folding side plates when
the pantograph is unlocked!
IN S T A L L A T I O N R E Q U I R E M E N T S
F O R T H E F I X T U R E
The Pantograph attaches to the fixture mounting bracket, if applicable, or to the
Omega clamp attachment bracket that is included with Martin moving-head
fixtures. The Pantograph cross-plate to which the fixture fastens may be reversed if
necessary.
The fastening hardware shall be metric grade 8.8 or better. Use M12 hardware to
fasten the Pantograph to the Omega bracket and to most mounting brackets. (Small
fixtures may require M10 hardware.) A typical installation requires an M12 x 45
mm hex cap screw, M12 washer, and M12 lock nut. An additional hex nut may be
placed between the Pantograph and the Omega bracket to provide clearance for the
quarter-turn locks.
F O R T H E P A N T O G R A P H
The Pantograph fastens to the ceiling or other load-bearing structure with four sets
of 8 mm (5/16 in.) hardware. The fasteners are inserted through 42.5 mm washers
(included) and then through the 24 mm holes in the base to allow room for precise
alignment. Additional fasteners may be inserted through the 8.5 mm holes in the
Pantograph base.
The specific fastener type and length varies according to substrate. It is the
installers responsibility to determine a suitable fastening method.
P/N 35000539, Rev. A © 2001 Martin Professional A/S, Denmark
F O R S E C O N D A R Y A T T A C H M E N T
Secondary attachment by means of a safety cable is highly recommended and may
be required by local codes. The safety cable shall be rated to bear 10 times the
combined weight of the fixture and Pantograph, which weighs 5 kg (11 lbs).
IN S T A L L A T I O N PROCEDURE
1 Establish the location for the Pantograph. Drill or prepare four anchoring points
centered on the 24 mm mounting holes in the Pantograph base. The small holes may
be used instead if they are more convenient. (See dimension drawing.)
2 Remove the mounting or Omega bracket from the fixture and bolt it to the Pantograph
with a suitable bolt, washer, and lock nut. (See “Installation requirements”, above.)
3 Slightly loosen the bolts on each side, if necessary, and fully extend the Pantograph.
Lock the position by tightening both wing nuts against the collar to protect yourself
from being pinched by the folding arms.
4 Position the Pantograph on the ceiling and fasten through the 24 mm holes in the
base.
5 Install the fixture on the Pantograph using the fixture mounting bracket or an Omega
bracket.
When using an Omega bracket, note that the fasteners must be turned a full
quarter turn to lock.
6 Raise the Pantograph to the desired position. Tighten the wing nuts.
7 Test the fit of the ceiling panel, if applicable, and adjust the Pantograph position and
extension as necessary.
8 All fasteners must be tight for a safe and satisfactory installation. Tighten the
mounting bracket, Pantograph base, and wing nuts. Tighten the 9 hex bolts on one
side of the Pantograph and the 4 hex bolts on the other side.
9 Install a safety cable to the ceiling (not the Pantograph) and the fixture.
10 Install the ceiling panel.
MI N I M A C I N S T A L L A T I O N E X A M P L E
Fasten the Pantograph to the
ceiling using the large holes
and washers.
Fasten the fixture to the
Pantograph with locking M12
hardware. Turn the locks a full
quarter turn.
Check the fit, adjust as
required, and tighten
everything.
