Mamas & Papas Bop Bedienungsanleitung
Mamas & Papas
Stuhl
Bop
Lesen Sie kostenlos die 📖 deutsche Bedienungsanleitung für Mamas & Papas Bop (2 Seiten) in der Kategorie Stuhl. Dieser Bedienungsanleitung war für 8 Personen hilfreich und wurde von 2 Benutzern mit durchschnittlich 4.5 Sternen bewertet
Seite 1/2
x1 <15m
/mamasandpapasuk
/mamasandpapasusa
/mamasandpapasmaltaregion
/mamasandpapasmagyarorszag
@mamasandpapas /user/mamasandpapasglobal mamasandpapasblog.com /mamasandpapas
mamasandpapas.com
mamasandpapas.ca
mamaspapas.kr
+44 (0)845 268 2000
1-800-490-0331
1-800-667-4111
1300 663 034
HD5 0RH, UK
Bop Hi-Lo
BHHC_0365_0114_V1
© Mamas & Papas Ltd. 2014
LOT
IMPORTANT! KEEP FOR FUTURE REFERENCE
WARNING:
• Do not leave the child unattended.
• Ensure that the harness is correctly fitted and adjusted when the child is in the highchair.
• Do not use the high chair unless all components are correctly fitted and adjusted.
• Be aware of the risk of open fire and other sources of strong heat, such as electric bar fires, gas fires etc. in the
vicinity of the high chair.
• IMPORTANT: Ensure the tray is secured in position at all times when the child is in the highchair
• This highchair is only suitable for children who can sit up unaided.
• Do not to use the high chair if any part is broken, torn or missing.
• The highchair can be cleaned using warm water and a mild soap. Never use bleach or abrasive cleaners.
• The highchair is suitable from 6 months to 3 years.
10. Press the catch on the top of the tray support
inwards and lift the tray upwards off the
highchair.
13. Slot the harness buckles through the slots
inthe seat, then slot them through the slots in the
seat pad. Remove the harness.
14. Remove the lower parts of the legs by pressing
the pin inwards and removing the leg from the
slot.
11. Turn the locking button anti-clockwise and
rotate the support upwards until it comes free of
the chair.
12. Push the pin (1) towards the footrest to release
the lock and pull the footrest out of the housing.
1. Attach the two front legs to the seat. Slot the ends of the legs into the housings on the seat. Push the
pins in the tops of the legs in and slide into the housings (1), ensure the ends of the bars on the seat
are inserted into the housings on the legs (2). Ensure the pins are protruding through the holes in the
housings after fitting.(3)
2. Slot the two back legs into the rear housing on the seat. Push the pins on the legs inwards and fully
insert into the housing. Ensure the pins are protruding through the holes in the housings after fitting.
3. Slot the feet onto the ends of the legs. Ensure the feet are slotted onto the correct legs. The base of
the feet are marked with two letters, see diagram for the correct fitting.
4. Slot the end of the footrest into the housing on the underside of the seat. Push the leg rest in until it
locks into the housing.
5. Attach the tray support to the front of the seat. Slot the tabs on the back of the support into slots in
the seat (1). Rotate the support down until the front locks onto the seat (2).
6. Slot the hooks on the ends of the tray into the slots in the sides of the seat (1). Ensure the feet on the
ends of the tray are resting on the buttons on the seat under the tray (2). Push the tray down until it
locks onto the tray support (3).
7. Slot the buckes on the ends of the harness straps through the slots in the seat pad. Place the seat
pad in the seat and slot the buckles through the slots in the seat.
8. Slot the tabs on the waist straps into the buckle (1). To adjust the harness, slide the straps through the
adjusters to the required lengths (2).
9. To open the harness, push the locking tabs inwards (1) and slide the two waist strap tabs out of the
buckle (2).
Produktspezifikationen
| Marke: | Mamas & Papas |
| Kategorie: | Stuhl |
| Modell: | Bop |
