INSTRUCTION MANUAL
MANUAL DE INSTRUCCIONES
Cordless Portable Vacuum Cleaner
Aspiradora Inalámbrica Portátil
XCV11
ADCV11
IMPORTANT: Read Before Using.
IMPORTANTE: Lea antes de usar.
2 ENGLISH
ENGLISH (Original instructions)
SPECIFICATIONS
Model: XCV11 ADCV11
Maximum air volume at the end
of hose
Normal (1) 1.3 m3/min (46 cu.ft/min)
High (2) 1.6 m3/min (57 cu.ft/min)
Maximum air volume at turbine 2.4 m
3/min (85 cu.ft/min)
Vacuum Normal (1) 42 hPa
High (2) 67 hPa
Recoverable capacity 7.5 L (2.0 gal.)Dust
Water * 4.5 L (1.2 gal.)
Dimensions (L x W x H) 418 mm x 251 mm x 278 mm
(16-1/2″ x 9-7/8″ x 11″)
Rated voltage D.C. 18 V
Net weight 4.2 - 4.6 kg (9.4 - 10.1 lbs)
• Due to our continuing program of research and development, the specications herein are subject to change
without notice.
• Specications may di󰀨er from country to country.
• The weight includes accessories (Hose, Wide nozzle, Sash nozzle) and battery cartridge(s). The lightest and
heaviest combination weight of the appliance and battery cartridge(s) are shown in the table.
* The capacity of water depends on the condition of use.
Applicable battery cartridge and charger
Battery cartridge
BL1815N / BL1820B / BL1830 / BL1830B / BL1840B / BL1850B / BL1860B
Charger
DC18RC / DC18RD / DC18RE / DC18SD / DC18SE / DC18SF / DC18SH
• Some of the battery cartridges and chargers listed above may not be available depending on your region of
residence.
WARNING: Only use the battery cartridges and chargers listed above. Use of any other battery cartridges
and chargers may cause injury and/or îš¿re.
SAFETY WARNINGS
IMPORTANT SAFETY
INSTRUCTIONS
When using an electrical appliance,
basic precautions should always be fol-
lowed, including the following:
READ ALL
INSTRUCTIONS
BEFORE USING
THIS APPLIANCE.
WARNING
To reduce the risk of îš¿re, electric shock
or injury:
1.
Do not leave appliance when battery
îš¿tted. Remove battery from appliance
when not in use and before servicing.
2. Do not allow to be used as a toy.
Close attention is necessary when
used by or near children.
3. Use only as described in this man-
ual. Use only manufacturer's recom-
mended attachments.
4. Do not use with damaged battery.
If appliance is not working as it
should, has been dropped, dam-
aged, left outdoors, or dropped into
water, return it to a service center.
3 ENGLISH
5. Do not handle battery or appliance
with wet hands.
6. Do not put any object into open-
ings. Do not use with any opening
blocked; keep free of dust, lint, hair,
and anything that may reduce air
ow.
7. Keep hair, loose clothing, îš¿ngers,
and all parts of body away from
openings and moving parts.
8. Turn o󰀨 all controls before removing
the battery cartridge.
9. Use extra care when cleaning on
stairs.
10. Do not use to pick up ammable or
combustible liquids, such as gaso-
line, or use in areas where they may
be present.
11. Use only the charger supplied by
the manufacturer to recharge.
12. Do not pick up anything that is burn-
ing or smoking, such as cigarettes,
matches, or hot ashes.
13. Do not use without îš¿lters in
place. Replace a damaged îš¿lter
immediately.
14. Do not charge the battery outdoors.
15. Do not expose to rain. Store
indoors.
16. Do not use the cleaner as a stool or
work bench. The machine may fall
down and may result in personal
injury.
17. Do not vacuum the following:
• Flammable liquid (kerosene,
gasoline, solvents such as ben-
zine, thinner, etc.)
• Hot substances that are burn-
ing or smoking (cigarettes,
matches, incense sticks, can-
dles, hot ashes), sparks and
metal dust generated by cutting
or grinding metal, etc.
• Flammable material (toner,
paint, spray, etc.)
• Foam like carpet cleaning agent,
etc. (they may cause explosion
or îš¿re)
• Explosive or pyrophoric sub-
stances (nitroglycerin, alumi-
num, magnesium, titanium, zinc,
red phosphorus, yellow phos-
phorus, celluloid, etc. and their
dust, gas or steam)
• Sharp objects (glass, cutlery,
wood splinter, metal, stone, nail,
razor, push pin, etc.)
•
Solidifying and conductive îš¿ne
powder (metal or carbon powder)
• Dehumidier
• Large amount of powder (our,
îš¿re extinguisher powder, etc.)
• Substances that cause toxic
symptoms
• Aggressive chemicals (acid,
leach, etc.)
• Liquid or damp garbage, includ-
ing vomit and excreta
• Asbestos
• Pesticides
Such action may cause îš¿re, injury
and/or property damage.
To reduce your exposure to these
chemicals, always wear approved
respiratory protection such as dust
masks that are specially designed
to îš¿lter out microscopic particles.
Direct the exhaust air away from
your face and body.
NOTE: Read the OSHA regulation
on silica dust to understand the
requirements needed to reduce
exposure to silica dust at the job-
site. Speciîš¿c rules apply to the drill-
ing, demolition cutting and grinding
materials that contain silica. All
OSHA requirements regarding
reducing silica dust can be found at
the OSHA website: www.osha.gov.
Battery tool use and care
1. Prevent unintentional starting.
Ensure the switch is in the o󰀨-po-
sition before connecting to battery
pack, picking up or carrying the
appliance. Carrying the appliance with
your îš¿nger on the switch or energiz-
ing appliance that have the switch on
invites accidents.
