There is 5 major parts in the package: AP2001x1,AD-100x1,
CT-880x1,SB-220x2,Connect Cable x3.
1.Monitor 1~3 connect to A/V parallel outputs 1~3 .
2.Connecting CT-880 wire controller to control Port 1.
3.Connecting SB-200 A/V switch controllers to Port 2 /3.
4.Monitor 1~3 can be select A/V source independently by
opposite controller.
5.Functions operation of Audio processor are controlled by CT-880.
