O W N E R ’ S M A N U A L

POWER

PHONES 4 PHONES 3 PHONES 2 PHONES 1

INPUT 1 2 3 4 +12V DC

HM-4 4-Way Headphone Ampliﬁer

Important Safety Instructions

.

Read these instructions.

Keep these instructions.

Heed all warnings.

Follow all instructions.

Do not use this apparatus near water.

Clean only with a dry cloth.

Do not block any ventilation openings. Install in accordance

with the manufacturer’s instructions.

Do not install near any heat sources such as radiators, heat

registers, stoves, or other apparatus (including ampliﬁers)

that produce heat.

Only use attachments/accessories speciﬁed by the

manufacturer.

10.

Refer all servicing to qualiﬁed service personnel. Servicing is

required when the apparatus has been damaged in any way, such

as power-supply cord or plug is damaged, liquid has been spilled

or objects have fallen into the apparatus, the apparatus has been

exposed to rain or moisture, does not operate normally, or has

been dropped.

11.

This apparatus shall not be exposed to dripping or splashing, and

no object ﬁlled with liquids, such as vases or beer glasses, shall

be placed on the apparatus.

12.

This device complies with Part 5 of the FCC Rules. Operation is

subject to the following two conditions: () this device may not

cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause

undesired operation.

NOTE:

This equipment has been tested and found to comply

with the limits for a Class B digital device, pursuant to part

15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a

residential installation. This equipment generates, uses, and

can radiate radio frequency energy and, if not installed and

used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no

guarantee that interference will not occur in a particular

installation.

If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the

equipment o and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment

and the receiver.

• Connect the equipment into an outlet on a circuit

dierent from that to which the receiver is connected.

• Consult the dealer or an experienced radio / TV

technician for help.

CAUTION:

Changes or modiﬁcations to this device not expressly

approved by LOUD Audio LLC could void the user's authority to

operate the equipment under FCC rules.

WARNING — To reduce the risk of ﬁre or electric shock,

do not expose this apparatus to rain or moisture.

3.

This device complies with FCC radiation exposure limits set

forth for an uncontrolled environment. This device should be

installed and operated with minimum distance 20cm between

the radiator & your body.

4.

This apparatus does not exceed the Class A/Class B

(whichever is applicable) limits for radio noise emissions

from digital apparatus as set out in the radio interference

regulations of the Canadian Department of Communications.

ATTENTION

— Le présent appareil numérique n’émet pas de bruits

radioélectriques dépassant las limites applicables aux

appareils numériques de class A/de class B (selon le cas)

prescrites dans le réglement sur le brouillage radioélectrique

édicté par les ministere des communications du Canada.

5.

This device complies with Industry Canada licence-exempt RSS

standard(s).

Operation is subject to the following two conditions:

() this device may not cause interference, and

(2) this device must accept any interference, including

interference that may cause undesired operation of the device.

Le présent appareil est conforme aux CNR d’Industrie

Canada applicables aux appareils radio exempts de licence.

L’exploitation est autorisée aux deux conditions suivantes:

() l’appareil ne doit pas produire de brouillage, et

(2) l’utilisateur de l’appareil doit accepter tout brouillage

radioélectrique subi, même si le brouillage est susceptible d’en

compromettre le fonctionnement.

6.

Exposure to extremely high noise levels may cause permanent

hearing loss. Individuals vary considerably in susceptibility to

noise-induced hearing loss, but nearly everyone will lose some

hearing if exposed to suciently intense noise for a period of

time. The U.S. Government’s Occupational Safety and Health

Administration (OSHA) has speciﬁed the permissible noise

level exposures shown in the following chart.

According to OSHA, any exposure in excess of these

permissible limits could result in some hearing loss. To

ensure against potentially dangerous exposure to high sound

pressure levels, it is recommended that all persons exposed

to equipment capable of producing high sound pressure levels

use hearing protectors while the equipment is in operation.

Ear plugs or protectors in the ear canals or over the ears must

be worn when operating the equipment in order to prevent

permanent hearing loss if exposure is in excess of the limits set

forth here:

Duration, per

day in hours Sound Level dBA,

Slow Response Typical Example

8 90 Duo in small club

6 92

4 95 Subway Train

3 97

2 100 Very loud classical music

1.5 102

1 105 Ryan screaming at Troy about deadlines

0.5 110

0.25 or less 115 Loudest parts at a rock concert

Correct disposal of this product: This symbol indicates that this product should not be disposed of with your household waste, according to the WEEE

directive (2012/19/EU) and your national law. This product should be handed over to an authorized collection site for recycling waste electrical and

electronic equipment (EEE). Improper handling of this type of waste could have a possible negative impact on the environment and human health due

to potentially hazardous substances that are generally associated with EEE. At the same time, your cooperation in the correct disposal of this product

will contribute to the eective usage of natural resources. For more information about where you can drop o your waste equipment for recycling, please

contact your local city oce, waste authority, or your household waste disposal service.

Owner’s Manual

Contents

Part No. SW1226 Rev. A 01/18

Introduction

The ultra-compact HM-4 4-Way Headphone Ampliﬁer

features a 1/4" stereo input and four 1/4" headphone outputs

with individual level controls. Perfect for studios or even at

home when up to four people want to listen together.

Getting Started

The following steps will help you set up the HM-4

4-Way Headphone Ampliﬁer quickly.

1. Turn down all level knobs on all connected gear.

2. Connect a cable from the output jack of the mixer,

computer or other audio device to the input jack

of the HM-4.

3. Connect stereo headphones to the headphone output

jack(s) of the HM-4.

4. Push the AC adapter securely into the HM-4’s connector

and plug the other end into an AC outlet. The HM-4 may

accept the appropriate voltage as indicated near the

connector. The HM-4 will turn on automatically when

connected.

5. Be sure that the volume of the input is the same as it

would be during normal use.

6. Slowly raise the phones knob(s) to a comfortable listening

level.

Things to Remember

• Never listen to loud music for prolonged periods.

Please see the Safety Instructions on page 2 for

information on hearing protection.

• Save the shipping boxes and packing materials!

You may need them someday. Besides, your hamster

will love playing in them and jumping out at you

unexpectedly. Remember to pretend like you

are surprised!

• Save your sales receipt in a safe place.

Features

• Share a single stereo source with up to four pairs

of headphones

• Individual level control for each output

• Powered via the included power supply

• Built-Like-A-Tank™ construction

How to Use This Manual

Afer this introduction, a getting started guide will help you

get things set up fast. The hookup diagram shows a typical

setup.

This icon marks information that is critically

important or unique to the HM-4. For your

own good, read and remember them.

Like us

Watch our dang videos

Important Safety Instructions 2 ........................................

Contents 3 ...........................................................................

Features 3 ............................................................................

How To Use This Manual 3 .................................................

Introduction 3 .....................................................................

Getting Started 3 ................................................................

Things To Remember 3 .......................................................

Hookup Diagram 4 ..............................................................

HM-4: Front and Rear Panel Features 5 ...........................

1. Power Connector and LED 5 ....................................

2. 1/4" Line Input 5 .......................................................

3. 1/4" Headphone Output Jacks 5 .............................

4. Phones Level Knobs 5 .............................................

Appendix A: Service Information 6 ....................................

Appendix B: Technical Information 7 ................................

HM-4 Dimensions 7 .....................................................

HM-4 Block Diagram 8 ................................................

Limited Warranty 9 .............................................................
