HD Wi-Fi Camera
Quick Start Guide
lorex.com
Camera
ATTENTION:
A REGULATED UL / CSA APPROVED power supply is REQUIRED for use
with this camera (included). Use of a non-regulated, non-conforming power
supply can damage this product and voids the warranty.
Power Accessories Mounting Kit
Bracket
W261AQ_QSG_EN_R2
Problem Solution
Cannot set up
camera
• Ensure your mobile device and the camera are
within range of your Wi-Fi router.
• Ensure the LED indicator on the camera is
ashing green before beginning setup.
No picture / signal • Ensure the LED indicator on the camera is
glowing steady green. See ‘LED Behavior’
section for details if otherwise.
• Ensure the camera is properly connected to
power using the included USB power adapter.
• Try repositioning the camera, router, or both to
improve signal strength.
Picture is not clear • Check the camera lens for dirt, dust,
spiderwebs. Clean the lens with a soft, clean
cloth.
• Remove the vinyl cover on the camera lens.
No audio • Ensure audio function on camera is turned on.
• Ensure audio is turned up on viewing device.
Person detection not
working
• Ensure you have enabled Person Detection in
the Device Settings screen of the Lorex Home
app. See ‘Overview of Lorex Home App’ for
details.
Camera stuck
downwards
• Turn off in Device Settings on Privacy Mode
the Lorex Home app. See ‘Overview of Lorex
Home App’ for details.
×3
×3
W261AQ Series
A
B
C
E
G
F
Package Contents
Need Help?
Visit us online for up-to-date software
and complete instruction manuals
Click on the tabDownloads
4
Visit lorex.com
Search for the model
number of your product
Click on your product
in the search results
3
2
1
Resources
Copyright © 2019 Lorex Corporation
As our products are subject to continuous improvement, Lorex reserves the right to
modify product design, specications and prices, without notice and without incurring
any obligation. E&OE. All rights reserved.
LED Behavior
Troubleshooting
See table below for denitions of camera’s LED behaviors:
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS SUBJECT TO THE
FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT
MAY CAUSE UNDESIRED OPERATION.
Behavior Meaning
(steady) Operating correctly.
(ashing) Ready for connection.
(ashing rapidly) Mobile device is attempting to connect to the camera.
(steady)
Device malfunction. Try resetting the camera (see
‘Camera Overview’ for details) and repeating the
setup.
(ashing)
Network connection failed. Try resetting the camera
(see ‘Camera Overview’ for details) and repeating the
setup.
(ashing rapidly) microSD error. Try removing and re-inserting the
included microSD card, or try a different card.
(alternating) Firmware upgrade in progress.
D
Camera Overview
Status LED
Microphone
Reset: Press and hold until
the chime sounds to reset
the camera.
microSD slot: microSD card
pre-inserted (expandable up
to 256GB, microSD class 10
or higher).
Speaker
Ethernet: For service only.
Power: Connect the included
USB power adapter.
A
B
C
D
E
F
G
• Read this guide carefully and keep it for future reference.
• Follow all instructions for safe use and handling of the product.
• Use the camera within given temperature, humidity and voltage levels noted in
the camera’s specications.
• Do not disassemble the camera.
• Do not point the camera directly at the sun or a source of intense light.
• Periodic cleaning may be required. Use a damp cloth only. Do not use any
harsh, chemical-based cleaners.
• The camera is rated for indoor use
only. Do not mount the camera
outdoors.
• This camera includes an Auto
Mechanical IR Cut Filter. When the
camera changes between Day/
Night viewing modes, an audible
clicking noise may be heard from
the camera. This clicking is normal,
and indicates that the camera lter
is working.
• Audio recording without consent is
illegal in certain jurisdictions. Lorex
Corporation assumes no liability for
use of its products that does not
conform with local laws.
Safety Precautions
Disclaimers
FCC Notice
3.4” / 86mm
4.2”
107mm
Dimensions
W261AQ_QSG_EN_R2
Back to
previous
screen
Device
settings
Device name
Pause / Play FullscreenViewing
modes
Mute /
Unmute
Streaming
quality*
Play back
recorded
video
Snapshot Manual
recording
2-way
audio: tap
to speak,
tap again
to disable
STEP 2B: Ceiling Mounting (Optional)
The camera is ready at this point to be placed on any surface and begin
monitoring if you would like to keep the placement of your camera exible.
You also have the option to mount the camera to an indoor ceiling using
the included mounting accessories.
* Change the streaming quality to SD (Standard Denition) to conserve
bandwidth while watching live video. This will not impact the quality of
recorded video.
** Enable on the Device Settings screen to have Smart Tracking (beta)
the camera follow and adjust to one moving object in the scene. Tracking
varies depending on the speed of motion.
To mount the camera:
1. Mark the camera’s mounting
position using the included
mounting template.
2. Drill holes where marked on the
mounting template.
accessories.
NOTE: Insert the optional
plastic mounting anchors if
needed.
3. Remove the mounting plate
from the camera base and
position the holes over the
mounting points.
4. Attach the mounting plate
to the mounting surface
using the included mounting
screws.
5. Twist the camera base onto
the mounting plate to secure
it to the mounting surface.
Adjust the camera’s position
as needed.
Plastic
anchors
Mounting
surface
Mounting
screws
Mounting
plate
Overview of Lorex Home App
Overview of the live viewing screen and controls in the Lorex
Home app. For complete instructions on using the app, see the
Lorex Home app manual on your product page at lorex.com.
Pan-Tilt
controls**
• Place the camera as close to your Wi-Fi router or access point as
possible.
• Reduce the number of obstructive materials between the camera and
the router or access point. Concrete, brick, metal and wood are the most
common materials in your house that can cause poor signal strength.
To ensure the best possible wireless performance, it is recommended to
keep the following installation tips in mind when choosing a location for
the camera:
• Other electronic devices such as microwaves, TVs, cordless phones,
and baby monitors can cause signal interference. It is recommended to
install the camera as far away from these devices as possible.
STEP 2A: Installation Tips
Connect to the camera using the free Lorex Home app on your iPhone® or
Android™ phone.
1. Connect the camera cable to the included USB adapter and plug into a
nearby outlet.
2. Download and install the free app from Lorex Home
the App Store or Google Play Store.
3. Tap the Lorex Home icon to launch the app. Tap Sign
up, then follow the on screen prompts to create an
account. Record your account details below:
STEP 1: Connecting to Lorex Home
To connect your camera to Lorex Home:
4. Once the status LED on the camera is ashing green and the startup
chime sounds, tap .+
5. Scan the QR code on the bottom of the camera using your mobile
device’s camera.
NOTE: If your mobile device cannot scan the QR code, tap Manually
enter Device ID.
6. Create a secure password for the camera. Record your camera
password below:
Email:
Account Password:
Camera Password:.
7. Select your Wi-Fi network from the list, then enter the password to
connect your camera to the Internet.
8. Once the status LED on the camera is solid green, tap to add the Next
camera to your Lorex Home account.
9. Set a name for the camera and congure date & time preferences,
then tap Complete to nish the setup.
6. If you are installing the camera on a ceiling, use the Image Rotation
feature on the Device Settings screen of the Lorex Home app
to ip the camera image (see ‘Overview of Lorex Home App’ for
details).
