Seite 1/3

GB-5GB-4

SAFETY FIRST!

IMPORTANT SAFETY INSTRUCTIONS

READ CAREFULLY AND KEEP FOR FUTURE REFERENCE

Please follow all the safety precautions listed below for safety

and to reduce the risk of injury or electrical shock.

• Thisapplianceisintendedforindoor,domesticuseonly.

• Alwaysensurethatyourpowersupplyvoltagematchesthis

appliance’sratinglabel.

• Donotkinkorwrapthemainscableandplugaround

the appliance.

• Alwayspositiontheappliancewiththemainspluginan

accessiblepositionandavoidtheuseofanextensioncables

astheymayoverheatandcreateapotentialrerisk.

• Donotusetheapplianceinwardrobesornearfabricsor

clothing.Donotstandtheapplianceondeeppilecarpets.

• Donotusetheapplianceinareaswherepetrol,paintsor

otherammablesubstancesareusedorstored.

• Donotuseinverydustyareasasdustmayaccumulateon

theheatingelementsandcauseoverheating.

• Ensurethattheunitisusedonastableandlevelsurface.

Iftheoorsurfaceisuneventhereisariskthattheappliance

couldtipover.Also,excessivevibrationandnoisemayoccur.

Iftheapplianceshouldbeaccidentallytippedover,please

immediatelydisconnectfromthepowersupply.

• Donotuseifthereareanyvisiblesignsofdamagetothe

appliance.

• Donotoperatewithwethandsorspillliquidsontothe

appliance,themainscableorplug.

• Neverleavetheapplianceunattendedwhileinoperation.

• Donotplaceanypartofyourbodyneartheairinletand

outlettoavoidpersonalinjury,electricshockorre.

• Avoidobstructingtheairinletandtheairoutlet.

• Childrenshouldbesupervisedtoensurethattheydonot

playwiththeappliance.Donotplacetheapplianceinplaces

that are easy to reach by children.

• Alwaysunplugtheappliancewhennotinuse.

• Donotrepairtheapplianceyourself,butratherconsultan

authorisedexpert.

• Forsafetyreasonsabrokenordamagedmainscablemay

onlybereplacedbythemanufacturerorasimilarlyqualied

person.

• Donotoperatetheapplianceindirectsunlight,nearheat

sources,humidenvironmentsorinplacesnearwaterorother

liquidssuchasbathrooms,showerorswimmingpool.

• Thisapplianceisnotintendedforusebypersons(including

children)withreducedphysical,sensoryormentalcapabilities,or

lackofexperienceandknowledge,unlesstheyhavebeengiven

supervisionorinstructionsconcerningtheuseoftheapplianceby

a person responsible for their safety.

• Theheatermustnotbelocatedimmediatelybelowamains

socket.Donotusetheappliancewithaprogrammer,timerorany

otherdevicethatswitchestheapplianceonautomatically.Are

riskexistsiftheapplianceiscoveredorpositionedincorrectly.

Ceramic Tower Heater

Instruction Manual

L18CTHB12

Thank You for purchasing your new Logik Ceramic Tower Heater.

We recommend that you spend some time reading this instruction

manual in order to fully understand all the operational features it offers.

Read all the safety instructions carefully before use and keep this

instruction manual for future reference.

IB-L18CTHB12_130606V2

DSGRetailLimited(RegisteredinEnglandNo.504877)

MaylandsAvenue,HemelHempstead,HertfordshireHP27TG.UK

Thissymbolontheproductorintheinstructionsmeansthatyourelectrical

andelectronicequipmentshouldbedisposedattheendofitslifeseparately

fromyourhouseholdwaste.Thereareseparatecollectionsystemsfor

recyclingintheEU.

Formoreinformation,pleasecontactthelocalauthorityoryourretailer

where you purchased the product.

Forgeneralinformationaboutthisappliance

andhandyhintsandtips,pleasevisit

www.knowhow.com/knowledgebank 0844 5611234 or call .

VisitPartmaster.co.uktodayfortheeasiestwaytobuyelectricalsparesandaccessories.

Withover1millionsparesandaccessoriesavailablewecandeliverdirecttoyourdoorthe

verynextday.Visitwww.partmaster.co.ukorcall08448003456(UKcustomersonly).

CallschargedatNationalRate.

WARNING:Inordertoavoidoverheating,

donotcovertheappliance.

SPECIFICATIONS

Mainssupply: 220-240V~50Hz

Powerconsumption: 1800W

Specicationsandfeaturesmaychangewithoutpriornotice.

UNPACKING

Removeallpackagingfromtheunit.Retainthepackaging.Ifyoudisposeofit,

pleasedosoaccordingtoanylocalregulations.

Thefollowingitemsareincluded:

Ifitemsaremissingordamaged,pleasecontactPartmaster(UKonly).

Tel:08448003456forassistance.

RemoteControl

TIMER

TEMP

MODE

OSC

TheMainUnit

DO NOT COVER

OSC

TEMP

TIMER

MODE

PRODUCT OVERVIEW

CONTROL PANEL

LED DISPLAY

REMOTE CONTROL

OPERATION

1. Positiontheheateruprightontheoorawayfromcurtains,furnitureorwall

coveringsbeforepluggingyourheaterintothemainssocket.

2. Connecttheheatertothemainssocket.Besurethemainsplugtstightlyinthe

mainssocket.Aloosetwillcauseoverheatinganddamagethemainsplug.

3. SwitchontheheaterusingthePower Switchattherearoftheheater.Theunit

will beep and the Power LEDwilllightupred.Thedefaultpowerlevelishigh.

Usethe buttontoadjustthepowerleveltoloworhigh.Mode

4. InAutoTemperatureMaintenanceMode,oncetheunit’stemperaturesensor

detectsthattheroomtemperatureis2°Cabovethedesiredtemperature,theheater

willswitchoautomatically.After4minutes,iftheroomtemperaturefallsbelow

thedesiredtemperature,theunitwillturnonagaintomaintainthetemperature.

Rear

DO NOT COVER

OSC

TEMP

TIMER

MODE

Front

LEDDisplay

AirOutlet

Base

MainsCable

ControlPanel PowerSwitch

AirInlet

Recessed

Handle

GB-3GB-2GB-1

OSC

TIMER

TEMP

MODE

TimerButton

PowerSelection

Button

Rotation

On/OButton

ON/OFF Button

Temperature

Increase/Decrease

Button

DO NOT COVER

AutoTemperature

Maintenance

Indicator

LowPowerLevel

Indicator

Max.Power

LevelIndicator PowerLED

SetTemperature

Indicator

BatteryCompartmentCover

Rotation

On/OButton

PowerSelection

Button

2xAAABatteries

(notincluded)

Timer

Button

ON/OFF

Button

TemperatureIncrease/

DecreaseButton

Press: Description:To:

Starttheheater. HeaterwillbeepandtheLEDDisplaywillshow

theroomtemperatureandPowerLevelset.

Stoptheheater. HeaterwillbeepandtheLEDDisplaywillwinkout.

MODE SetheatertoMax.PowerLevel. PowerLevelindicatorwilllightupredandshow .

MODE SetheatertoLowPowerLevel. PowerLevelindicatorwilllightuporangeand .

TEMP SetheatertoAutoTemperature

Maintenance Mode.

LEDDisplaywillshowthetemperatureand

willlightupred.

Press: Description:To:

OSC Rotatetheheater. LEDDisplaywillshowthetemperature

andPowerLevel.

TIMER Setthetimerfortheheater. LEDDisplaywillshowthefollowingtimer

sequence:

1h>2h>3h>4h>5h>6h>7h>8h>0h

TEMP Increasethetemperature

(max.32˚C)

Temperaturewillincreaseby1degree.

TEMP Lowerthetemperature

(min.4˚C)

Temperaturewilldecreaseby1degree.

6. Tofullyswitchotheheater,turnothePower Switch at the rear and

unplugtheunitfromthemainssocket.

SAFETY PROTECTIVE DEVICE

Overheat Protection System

Thepowertotheheaterwillautomaticallycutoifthetemperatureofthe

heaterexceedsacertainlimit.Iftheheateroverheats,itwillstopoperating.

Switchtheheateroandallowittocoolforatleast30mins.Theheaterwill

thenresumeoperatingasnormal.

CLEANING

Yourheatershouldbecleanedregularlytostopdirtanddustbuildingup

whichwillaectitsperformance.Ensuretheairinletandtheairoutletarenot

blocked.Thiscanbedonewithavacuumcleaner,usingthebrushattachment.

HINTS & TIPS

My heater does not work when I turn it on

1. Checkthatyourheaterispluggedinandthepoweristurnedonatthe

mainssocket.

2. Theheatermaybeoverheating.Switchitoandallowittocooldownfor

atleast30mins,thenswitchitonagain.

3. TurnthePower Switch to the “High Temp” position.

4. TryreplacingtheBSIorASTSapproved13AmpBS1362fuseintheplug.

5. Iftheheaterstilldoesn’twork,donottrytorepairtheheateryourself.

If your heater’s power is automatically cut o follow the steps below:

1. Unplugyourheaterandallowittocooldownforatleast30mins.

2. Inspectyourheater.

3. Plug-intheheaterandswitchitonagain.Ifitcutsoagain,movethe

heatertoabetterventilatedlocation.

4. Ifthereisanysignofphysicaldamage(e.g.melting,orburningofthe

case),donotattempttouseyourheater.Pleaseleaveallmaintenance

worktoqualiedpersonnel.

Itisnormalfortheheatertoemitsomesmellwhenitisturnedon

forthersttimeorwhenturnedonafternotbeingusedforalong

time.Thissmellwilldisappearwhentheheaterhasbeenturned

on for a short while.

Theheatercannotbeswitchedonwhenithasoverheated.Allowit

tocooldownforatleast30minsandthenswitchitonagain.

Ensureyouunplugyourheaterfromthemainssocketandwait

fortheheatertocooldowncompletelybeforecleaning.
