Seite 1/2
4K HDMI 100M KVM Extender
âš« Introduction
The 4K HDMI KVM Extender is a tool for extending your HDMI/PC signal over long distance to 3 compatible
displays. It distributes your signal via CAT6 cable at 100M, and enables IR pass through to control local source -
device from remote or far end display,specially you can use mouse and keyboard to control it.-
âš« Features
1. Support HDMI1.4 and HDCP1.4.
2. Transmitters Supports local HDMI loop out.
3. Receivers supports 2 HDMI output.
4. Supports extend HDMI,IR,USB 2.0 signal up to 100m
5. Both the TX and RX support 3.5MM audio output.
6. Support mouse and keyboard extension.
âš« Specifications
Frequency Bandwidth 2.97Gbps
HDMI Transmitter Input/Output Ports 1x HDMI port/1 x PC/1 x Network port
1x IR Transmitter/1 x HDMI port/1 x 3.5mm audio
HDMI Receiver Input/Output Ports 1 x HDMI port/1 x Network port
1x IR Receiver/2 x HDMI port/1 x 3.5mm audio
Length of CAT6 cable between Rx and TX 100 meters
HDMI Input 4k@30Hz/1080p/720p/576p/576i/480p/480i
HDMI Output 4k@30Hz/1080p/720p/576p/576i/480p/480i
Power Supply DC 5 V 2 A
ESD Protection Human Body Model: ± 8kV (air gap discharge)-
± 4kV (contact discharge)
Operating Temperature 0°C ~ 40°C / 32°F ~ 104°F
Storage Temperature 20°C ~ 60°C / 4°F ~ 140°F - -
Relative Humidity 20 ~ 90% RH (Non condensing)-
Power Consumption (Max) 20W
Dimension (L x W x H) 130x100x22(mm)
CE marking is a certification mark that indicates conformity with health, safety, and environmental protection standards for
products sold within the European Economic Area (EEA).The CE marking is also found on products sold outside the EEA that
have been manufactured to EEA standards. This makes the CE marking recognizable worldwide even to people who are not
familiar with the European Economic Area.
WEEE is waste electrical and electronic equipment. It is end-of-life electrical and electronic equipment and covers virtually
everything with a plug or battery. ... The EC introduced the WEEE Directive in 2002 to address the environmental impacts
of unwanted electrical and electronic equipment at end-of-life disposal.
HVE- 0811
User Manual
P k gac a e
HDMI Extender Transmitter * PC 1
HDMI Extender Receiver * PC 1
IR Transmitter * PC 1
IR Receiver * PC 1
5 2 2V A DC Power Supply adapter * PCS
Operation Manual * PC 1
USB cable * PC 1
âš« Operation controls and Functions
Transmitter
1.HDMI OUT: HDMI local loop out 3. PC IN:USB Input port . IR: IR out 5
2 6 .HDMI IN: HDMI Input port. 4. : 3.5mm audio out . CAT OUT:Cat 6 cable connection port
7. Power LED: This red LED illuminate when the Transmitter is powered
8. DC 5V:Plug the DC 5V power supply into the unit.
Receiver
1.OUT A: HDMI out 1 :Keybord USB Input port : 3.5mm audio out 3. 5.
2.OUT B: HDMI out 2 Mouse USB Input port . IR: IR .
4.
4.
4.
4. 4. : 6in
7.CAT IN:Cat 6 cable connection port
8. Power LED: This red LED illuminate when the Transmitter is powered
9. DC 5V:Plug the DC 5V power supply into the unit.
âš« Application Example
