DSR4
Four Channel Digital Slot Receiver
DSR4-A1B1, DSR4-B1C1, DSR4-941, DSR4-961
INSTRUCTION MANUAL
Rio Rancho, NM, USA
www.lectrosonics.com
Fill in for your records:
Serial Number:
Purchase Date:
• Four independent channels, compact
design
• Two diversity options for maximum
exibility
• 24 bit/48 kHz digital for awless audio
• AES 256-bit, CTR mode encryption, with
4 dierent key policies available
• High IP3 performance of +15 dBm for
tough RF environments
• Analog and AES3 digital audio outputs
• External DC powering options and USB
input for rmware updates and data
transfer
scan for our DSR4
Deep Dive product videos
DSR4
LECTROSONICS, INC.
2
FCC Notice
NOTE: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined
by turning the equipment o and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that
to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Changes or modications to this equipment not expressly approved by
Lectrosonics, Inc. could void the user’s authority to operate it.
Installation & Operating Instructions
The following checklist includes the minimum required settings to start using the receiver:
• Install either a battery sled, camera slot adapter or other power source via EXT BOTTOM PLATE.
• Connect power to the receiver.
• Set the COMPAT (compatibility) mode for the transmitters to be used.
• Find clear operating frequencies for one or both receivers using SmartTune or manual scanning.
• Set transmitters on the matching frequencies, manually or by using IR sync.
• Verify transmitters are set to the same compatibility mode as the receiver (see transmitter manual).
• Adjust transmitter input gain to match voice level and mic position (see transmitter manual).
• Adjust receiver output level as needed for the camera or mixer input level desired.
Four Channel Digital Receiver
Rio Rancho, NM 3
Antenna Mounting and Orientation 14 ..........................
Firmware Update Instructions...................................16
Wireless Designer and Drivers 16 ..................................
Antenna/Block Reference Table................................17
Diagnostics 18 .................................................................
Multi-channel System Checkout 18 ...........................
Supplied Parts and Accessories 19 ...............................
Optional Parts and Accessories................................19
20Aligning Specialty Adapters ................................
IR Reector: Purpose and Installation 22 .....................
Specications and Features 23 ......................................
Troubleshooting 24 ..........................................................
Service and Repair 25 .....................................................
Returning Units for Repair 25 .....................................
Table of Contents
DSR4 Block Diagram 4 ....................................................
General Technical Description 5 ....................................
Installation & Operating Instructions 6 ..........................
Front Panel Controls and Functions 6 ...........................
MENU/SELECT Button...............................................6
PWR/BACK Button.....................................................6
Up/Down Arrow Buttons 6 ............................................
Antenna Port...............................................................6
TA5M Connector and Pins 6 .........................................
Antenna Port (2)..........................................................6
IR (infared) Port 6 ..........................................................
USB Port 6 .....................................................................
Main Window Display 7 ...................................................
Navigating the Menus 7 ..................................................
Menu Item Descriptions 7 ...............................................
RF Setup Menu ..........................................................7
Smart Tune 7 .................................................................
DSR4 LCD Menu Map 8 ..................................................
Smart Tune (continued) 10 ............................................
Frequency 10 .................................................................
Tuning Groups 10 ..........................................................
Named Group Entries (Party Dialing) 10 ......................
Scan 10 ..........................................................................
Group Edit 11 ...............................................................
Vector Pairs 11 .............................................................
Pilot Bypass..............................................................11
TXInfo........................................................................11
Audio Setup Menu 11 ......................................................
Audio Level 11 ..............................................................
Test Tone 12 ..................................................................
Output Type 12 .............................................................
SmartNR 12 ..................................................................
Talkback 12 ...................................................................
Polarity 12 .....................................................................
Compat Modes Menu 12 .................................................
IR & Keys Menu 12 ..........................................................
Send Frequency 12 ......................................................
Send All 12 ....................................................................
Get Frequency 12 .........................................................
Get All 12 ......................................................................
Group Sync 12 ..............................................................
Encryption Key Management 12 .................................
Encryption Keys 13 ......................................................
Send Key 13 .................................................................
Settings Menu 13 .............................................................
Lock/Unlock 13 ...........................................................
Backlight 13 .................................................................
RX On/Off 13 ...............................................................
TX Batt Type 13 ...........................................................
TX Batt Timer..........................................................13
TX Batt Icon 13 ............................................................
AutoOn 13 ....................................................................
Locale 13 .....................................................................
Default 14 ....................................................................
About 14 ......................................................................
IMPORTANT WARNING
The DSR4 is a high current receiver that
should not be used in a slot-mount camera
without double checking available current
from the camera.Many, if not most, slot
mount cameras are designed for lower
current receivers and are current limited/
fuse protected.The DSR4 draws up to
700mA at 7VDC. DO NOT drop it in the
camera to “see what happens.” Consult
with your camera manufacturer FIRST
before attempting to use this receiver in-
slot. 
The DSR4 is intended for use in slot
devices which can supply enough current
safely and without damage to fuses or
poly-fused circuits.
Lectrosonics will not be responsible
for damages that may result from
using this receiver in a slot mount that
cannot supply adequate current.
