26cc-2 Cycle Grass Trimmer NPTGSS2617A

Bordeadora con motor de 2 tiempos de 26 cc NPTGSS2617A

Read all safety rules and instructions carefully before operating this tool.

601 Regent Park Court Greenville, SC 29607, SC 29650 1-866-384-8432

AVISO:

Utilice solo gasolina sin plomo que contenga máximo 10% de etanol. No utilice combustible E15 o E85 con esta bordeadora. Esto

violará la ley federal, dañará la bordeadora y anulará su garantía.

NOTICE:

Only use unleaded gasoline containing up to 10% ethanol. Do not use E15 or E85 fuel in this trimmer. It will violate the federal law,

damage the trimmer and void your warranty.

Lea todas las reglas e instrucciones de seguridad cuidadosamente antes de utilizar esta herramienta.

601 Regent Park Court Greenville, SC 29607, SC 29650 1-866-384-8432

EN p. 2

ES p. 41

Operator’s Manual / Manual Del Operador

CONTENTS

PRODUCT SPECIFICATIONS

GENERAL SAFETY RULES

SYMBOLS

KNOW YOUR GRASS TRIMMER

ASSEMBLY

BATTERY PACK AND CHARGER

OPERATION

MAINTENANCE

ENVIRONMENTALLY SAFE BATTERY DISPOSAL

TROUBLESHOOTING

WARRANTY

EXPLODED VIEW

PARTS LIST

EXPLODED VIEW 26CC 2-CYCLE ENGINE

PARTS LIST 26CC 2-CYCLE ENGINE

NOTES

Section Page

3-6

7-8

9-10

11-13

14-15

16-22

23-30

32-33

39-40

Engine Size

Engine Displacement

Power / Speed

Idle Speed

Max Torque / Speed

Fuel Tank Capacity

Fuel / Oil Ratio

Line Diameter

Cutting Width

Net Weight

Battery Model No.

Battery Type

Charger Model No.

Charger Input

Charger Output

Charging Period (Battery Fully Discharged)

2-Stroke / Full Crank

26cc

0.72 kW / 7500 RPM

3000 RPM

0.9 Nm / 6000 RPM

400ml

40 : 1

0.08" - 0.1" (2.0 mm - 2.54 mm)

17" (432 mm)

13 lbs (5.9 kg)

07LB2001-S

7.2V Lithium-Ion, 2.0 Ah

YLS0042-T084045

100-240V ~ 50/60Hz 0.3A Max

8.4V 450 mA

4-6 Hours

PRODUCT SPECIFICATIONS

26cc-2 CYCLE GRASS TRIMMER

CONTENTS

GENERAL SAFETY RULES

WARNING

READ ALL INSTRUCTIONS AND SAVE THESE INSTRUCTIONS.

Read the Operator’s Manual and follow all warnings and safety instructions. Failure to do so

can result in serious injury to the operator and/or bystanders.

■ This grass trimmer is designed for cutting grass, soft vegetation.

■ The grass trimmer is intended for residential, or similar landscape use and is not recommended

for use in agricultural or forest environments.

■ This grass trimmer is not suitable for cutting or chopping, otherwise, there is a risk of injury. For

example:

- Hedges, shrubs and bushes,

- Flowers,

- In terms of composting.

■ Never allow children or persons unfamiliar with these instructions to use the trimmer.

■ Do not operate the trimmer inside a closed environment, such as a room or building; breathing

carbon monoxide from exhaust fumes can kill.

■ Clear the work area before each use. Remove all objects such as rocks, broken glass, nails,

wire, or string, which can be thrown or become entangled in the cutting attachment.

■ Clear the area of children, bystanders and pets. At a minimum, keep all children, bystanders

and pets outside a 50 ft (15 m) radius; outside the 50 ft (15 m) zone, there is still a risk of injury

from thrown objects.

■ Bystanders should be encouraged to wear eye protection. If you are approached, stop the

engine and cutting attachment.

■ Always wear eye protection with side shields marked to comply with ANSI Z87.1 along with

hearing protection when operating this trimmer. Failure to do so could result in objects being

thrown into your eyes and other possible serious injuries.

■ Always wear heavy, long pants, boots, gloves, and a long-sleeve shirt. Do not wear loose

clothing, jewelry, short pants, sandals, or go barefoot. Secure hair so it is above shoulder level.

■ Do not operate this trimmer when you are tired, ill, upset, or under the influence of alcohol,

drugs, or medication.

■ Inspect the trimmer before each use. Replace damaged parts. Check for fuel leaks. Make sure

all fasteners are in place and secure.

■ Replace cutting attachment parts that are cracked, chipped, or damaged in any way. Make sure

the cutting attachment is properly installed and securely fastened. Be sure the cutting

attachment shield is properly attached, securely fastened and in the position recommended by

the manufacturer.

■ Use only a flexible, nonmetallic line recommended by the manufacturer. Never use, for

example, wire or wire-rope, which can break off and become a dangerous projectile.

■ Only use the grass trimmer in daylight or good artificial light.
