P/N: 2900-301501 Rev 1 www.kramerAV.com
USER MANUAL
MODEL:
VP-427X1
4K HDBT/HDMI Receiver/Scaler
Kramer Electronics Ltd.
VP-427X1 Contents –
i
Contents
Introduction 1
Getting Started 1
Overview 2
Typical Applications 3
Dening VP-427X1 4K HDBT/HDMI Receiver/Scaler 4
Mounting VP-427X1 6
Connecting VP-427X1 7
Connecting the Output to a Balanced/Unbalanced Stereo Audio Acceptor 8
Connecting to VP-427X1 via RS-232 8
Wiring RJ-45 Connectors 8
Operating and Controlling VP-427X1 9
Using Front Panel Buttons 9
Connecting the Remote Control Switches 9
Using the OSD Menu 10
Operating via Ethernet 18
Using Embedded Web Pages 21
Loading and Saving Congurations 23
Entering Standby Mode 23
Conguring Video Input Settings 24
Selecting an Input 25
Freezing or Blanking the Video Output Signal 25
Adjusting the Output Volume 25
Viewing Device Details 26
Upgrading the Firmware 27
Conguring Network Settings 28
Performing Device Soft Factory Reset 29
Conguring Video Output Settings 29
Conguring HDCP per Input/Output 30
Managing EDID 31
Adjusting the Audio Delay and Volume 33
Conguring Automatic Switching Settings 34
Dening CEC Functionality 35
Controlling VP-427X1 via the RS-232 Terminal Block Connectors 36
Managing Authentication 44
Viewing About Page 46
Upgrading Firmware 47
USB Firmware Upgrade (USB Format FAT32) 47
Technical Specications 48
Default Communication Parameters 49
Default EDID 49
Protocol 3000 53
Understanding Protocol 3000 53
Protocol 3000 Commands 54
Result and Error Codes 62
Kramer Electronics Ltd.
VP-427X1 Introduction –
1
Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been providing a world
of unique, creative, and aordable solutions to the vast range of problems that confront the
video, audio, presentation, and broadcasting professional on a daily basis. In recent years, we
have redesigned and upgraded most of our line, making the best even better!
Getting Started
We recommend that you:
• Unpack the equipment carefully and save the original box and packaging materials for
possible future shipment.
• Review the contents of this user manual.
Go to www.kramerav.com/downloads/VP-427X1 to check for up- -date user manuals, to
application programs, and to check if rmware upgrades are available (where appropriate).
Achieving Best Performance
• Use only good quality connection cables (we recommend Kramer high-performance,
high-resolution cables) to avoid interference, deterioration in signal quality due to poor
matching, and elevated noise levels (often associated with low quality cables).
• Do not secure the cables in tight bundles or roll the slack into tight coils.
• Avoid interference from neighboring electrical appliances that may adversely inuence
signal quality.
• Position your Kramer away from moisture, excessive sunlight and dust. VP-427X1
Safety Instructions
Caution:
• This equipment is to be used only inside a building. It may only be connected to other
equipment that is installed inside a building.
• For products with relay terminals and GPI\O ports, please refer to the permitted rating
for an external connection, located next to the terminal or in the User Manual.
• There are no operator serviceable parts inside the unit.
Warning:
• Use only the power cord that is supplied with the unit.
• To ensure continuous risk protection, replace fuses only according to the rating
specied on the product label which is located on the bottom of the unit.
Recycling Kramer Products
The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC aims to reduce
the amount of WEEE sent for disposal to landll or incineration by requiring it to be collected
