Precautions
Location
Using the unit in the following locations can result in a malfunction.
• In direct sunlight
• Locations of extreme temperature or humidity
• Excessively dusty or dirty locations
• Locations of excessive vibration
• Closetomagneticelds
Power supply
Please connect the designated AC adapter to an AC outlet of the cor-
rect voltage. Do not connect it to an AC outlet of voltage other than
that for which your unit is intended.
Interference with other electrical devices
Radios and televisions placed nearby may experience reception interfer-
ence. Operate this unit at a suitable distance from radios and televisions.
Handling
To avoid breakage, do not apply excessive force to the switches or
controls.
Care
If the exterior becomes dirty, wipe it with a clean, dry cloth. Do not
use liquid cleaners such as benzene or thinner, or cleaning com-
poundsorammablepolishes.
Keep this manual
After reading this manual, please keep it for later reference.
Keeping foreign matter out of your equipment
Never set any container with liquid in it near this equipment. If liquid
getsintotheequipment,itcouldcauseabreakdown,re,orelectrical
shock.
Be careful not to let metal objects get into the equipment. If something
does slip into the equipment, unplug the AC adapter from the wall
outlet. Then contact your nearest Korg dealer or the store where the
equipment was purchased.
* -All product names and company names are the trademarks or reg
istered trademarks of their respective owners.
IMPORTANT NOTICE TO CONSUMERS
This product has been manufactured according to strict specifications
and voltage requirements that are applicable in the country in which it
is intended that this product should be used. If you have purchased this
product via the internet, through mail order, and/or via a telephone sale,
you must verify that this product is intended to be used in the country
in which you reside.
WARNING: Use of this product in any country other than that for which
it is intended could be dangerous and could invalidate the manufactur-
er’s or distributor’s warranty.
Please also retain your receipt as proof of purchase otherwise your prod-
uctmaybedisqualiedfromthemanufacturer’sordistributor’swarranty.
THE FCC REGULATION WARNING (for USA)
NOTE: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equip-
ment generates, uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning
theequipmentoandon,theuserisencouragedtotrytocorrectthe
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connecttheequipmentintoanoutletonacircuitdierentfrom
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
If items such as cables are included with this equipment, you must
use those included items.
Unauthorizedchangesormodicationtothissystemcanvoidthe
user’s authority to operate this equipment.
SUPPLIER’S DECLARATION OF CONFORMITY (for USA)
Responsible Party : KORG USA INC.
Address : 316 SOUTH SERVICE ROAD, MELVILLE, NY
Telephone : 1-631-390-6500
Equipment Type : DIGITAL PIANO
Model : B2/B2N
This device complies with Part 15 of FCC Rules. Operation is subject
to the following two conditions:
(1) This device may not cause harmful interference, and (2) this de-
vice must accept any interference received, including interference
that may cause undesired operation.
Notice regarding disposal (EU only)
When this “crossed-out wheeled bin” symbol is displayed
ontheproduct,owner’smanual,baery,orbaerypackage,
it signifies that when you wish to dispose of this product,
manual,packageorbaeryyoumustdosoinanapproved
manner. Do not discard this product, manual, package or
baeryalongwithordinaryhousehold waste.Disposingin
the correct manner will prevent harm to human health and
potential damage to the environment. Since the correct method of
disposal will depend on the applicable laws and regulations in your
locality, please contact your local administrative body for details. If
thebaerycontainsheavymetalsinexcessoftheregulatedamount,
a chemical symbol is displayed below the “crossed-out wheeled bin”
symbolonthebaeryorbaerypackage.
Specications
Keyboard B2/B2SP: NH Keyboard: 88 note (A0–C8)
B2N: NT Keyboard: 88 note (A0–C8)
Maximum polyphony
120 notes /60 notes/40 notes
Sounds 12 sounds
Connectors PHONES (Headphone/Line Out), USB (TYPE B),
AUDIO IN, PEDAL
Amp output B2/B2SP: 15 W x 2
B2N: 9 W × 2
Speakers Oval (10 cm x 5 cm) x 2
Power supply B2/B2SP: DC 15 V
B2N: DC 12 V
Power Consumption
B2/B2SP: 8 W
B2N: 6 W
Weight (excluding music stand)
B2: 11.4 kg / 25.13 lbs.
B2SP: 21 kg / 46.30 lbs.
B2N: 9.3 kg / 20.50 lbs.
Dimensions (W x D x H)
(including projections, but excluding music stand)
B2/B2N: 1312 × 336 × 117 mm/51.65 × 13.23 × 4.61"
B2SP: 1312 × 336 × 750 mm/51.65 × 13.23 × 29.53"
Included items
B2/B2N: AC adapter ( ), Music stand, Damper pedal,
Owner's Manual
B2SP: AC adapter ( ), Music stand, Stand (for use
with B2SP only) with pedal unit (supports half-
pedaling), Owner's Manual
Accessories (sold separately)
B2/B2N: Stand STB1, Pedal unit PU-2 (supports half-
pedaling)
Operating requirements (USB connection) *
Windows: Microsoft Windows 7 SP1 or later (32bit/64bit)
Mac: OS X El Capitan 10.11 or later
* Operation of the B2/B2SP/B2N is not guaranteed with all computers
that satisfy these operating requirements.
• Specificationsandappearancearesubjecttochangewithoutnotice
for improvement.
Partner mode allows you to split the keyboard into a left and right
side, and both players can play together within the same note
range. Press the power button to turn the power on while holding
down the METRONOME button. For details, download the "B2/
B2SP/B2N Partner Mode Instructions" from the Korg website
shown below. www.korg.com
www.korg.com
Thank you for purchasing the B2/B2S B2N Digital Piano.Korg P/
Published 04/2019 Printed in China
9: Auto power-off
When 30 minutes have passed without user input or demo performance,
the instrument will be automatically turned off. To disable this function,
press “Auto power-off disable.” This will be enabled when you turn on
the power (default setting). To re-enable this function once it has been
disabled, simply turn the power of the B2/B2SP/B2N off and back on
again.
Sounds, Demo Songs and MIDI Program
Change Numbers
CC0: Bank Select (MSB) for all sounds is set to 121.
CC32 PC Sound Song title/Composer
0 0 1 (German Concert Piano): Danse/C.Debussy
0 1 2 (Classic Piano): Waltzes Op.39-15/J.Brahms
1 0 3 (Italian Concert Piano): Je Te Veux/E.Satie
1 1 4 (Jazz Piano): I got Rhythm/G.Gershwin
2 0 5 (Ballad Piano): "Träumerei" Op.15-7/R.Schumann
0 4 6 (Stage E.Piano): Jam Session/Naoki Nishi
1 4 7 (60's E.Piano): Nighttrain/Michael Geisel
0 5 8 (Dig.E.Piano): In Memory/Michael Geisel
0 6 9 (Harpsichord) La Joyeuse/J.P.Rameau
0 19 10 (Pipe Organ) Toccata in D Minor/J.S.Bach
0 16 11 (Electric Organ) Improvisation/Michael Geisel
0 48 12 (Strings)
"Rhapsody on a Theme of Paganini" 18th Variation/
S.Rachmaninoff(arranged and played by Katsuhiro Oguri)
Troubleshooting
If you perceive any unexpected behavior from your Korg B2/B2SP/B2N
Digital Piano, please see if this guide addresses your concern. If not, or if
the problem persists, contact your nearest Korg distributor.
The Instrument turns off
If the power is left on for 30 minutes or more without the keyboard
being played, the auto power-off function will turn off the B2/B2SP/B2N
automatically. To use the B2/B2SP/B2N, press the power button again to
turn it on.
The Sound is interrupted
The instrument sounds in the B2/B2SP/B2N are created by recording
individual samples made from the actual instruments, processing them,
and combining them to achieve the desired sound. Depending on the
detail and complexity of the sound, one, two, or even three samples may
be combined to create each note. Nearly all of the sounds on the B2/
B2SP/B2N use two samples per note played. Due to this, the maximum
polyphony or number of notes that can sound at once (including when
the damper pedal is pressed) is 60. (Note that the Italian concert piano,
jazz piano and ballad piano sounds use three samples per note, which
brings the maximum polyphony down to 40.) However, the stage electric
piano sound has a maximum polyphony of 120 notes.
The pitch or tone of the piano sounds incorrect in some key regions
The B2/B2SP/B2N’s piano sounds replicate the sound of an actual piano
as faithfully as possible. This means that in some regions of the keyboard,
you may sense that the overtones seem stronger, or that the tone or pitch
seems wrong. This reflects the acoustic nature of the original instrument
being sampled, and is not a malfunction.
- E-1 -- E-4 -
Getting Started
The B2SP includes a stand with pedal unit, for use only with the B2SP.
Follow the steps below after putting the stand together.
1. Insert the DC plug of the supplied AC adapter into the DC IN jack on the
rear panel of the instrument..
Loop the AC adapter cord around
the cord hook to prevent the plug
from being accidentally removed
f r o m t h e D C I N j a c k . Wh e n
unhooking the cord from the hook,
do not pull on the cord or use
excessive force.
2. For the B2/B2N, connect the connector
of the supplied damper pedal to the PEDAL jack on the bottom panel of
the keyboard. For the B2SP, connect the connector of the stand's pedal unit
to the PEDAL jack on the bottom panel of the keyboard.
3. Insert the supplied AC adapter into an AC outlet.
4. Turn the B2/B2SP/B2N Digital Piano on.
Press and hold the Power button to turn the instrument on;
the Power LED will light up. For now, leave the piano on.
When you are done playing, press the Power button again
to turn the instrument off; the Power LED will go dark.
5. Set the Volume level.
While playing, adjust the Volume to an
appropriate level. The VOLUME knob
controls the output level of both the built-in
speakers and the PHONES jack.
■Installing the Music Stand
Slide the tab ends of the music stand into
the mounting holes toward back of the
instrument.
■Using headphones
For private practice, plug your headphones
into the PHONES jack located on the rear
panel. Connecting the headphones will mute
the internal speakers.
• Thisstereo1/8"PHONESjackcanalso
be used as an audio output to connect
the B2/B2SP/B2N Digital Piano to
powered speakers or other audio
devices.
To protect your hearing, do not listen to loud, high-volume sounds for a
long period of time through headphones.
■When connecting an external input device
Use an audio cable to connect the AUDIO IN jack (stereo mini plug) on the back
of the B2/B2SP/B2N with other electronic musical instruments, audio players,
etc. The input signal will be sent to the speakers and the PHONES jack of the
B2/B2SP/B2N. This input signal cannot be outputted via the USB-AUDIO port.
The volume may be loud depending on the settings of the external input
device, so adjust the volume on that device.
■When using USB-MIDI and USB-AUDIO
Connect the USB port on the back of the B2/B2SP/B2N to your computer
with a USB cable to exchange MIDI or audio data.
When connecting to your computer, The volume may be loud depending
on the settings, so adjust the volume on your computer.
When the B2/B2SP/B2N is first connected to your Windows computer,
the USB-MIDI driver pre-installed with the operating system will be
used automatically. This pre-installed USB-MIDI driver will not allow
the B2/B2SP/B2N to access multiple programs or applications at the same
time. To remedy this situation, simply download the KORG USB-MIDI
driver at www.korg.com and install the driver as instructed with the
supporting documentation.
Even if the B2/B2SP/B2N will not be used with multiple applications,
we recommend installing the KORG USB-MIDI driver, which should
provide improved operating stability.
Be carefu not to bend l
t o his area to much
when ttaching th a e
cord to th hook e .
Cord hook
B2/B2N B2SP
Softer
Loude
r
Illustration :
B2/B2SP
Feature Guide
Chorus on
Chorus off
Lower
Higher
Reverb on
Reverb off
x
100
x
10
x
1
Low
High
Beat
1. German Concert Piano
2. Classic Piano
3. Italian Concert Piano
4. Jazz Piano
5. Ballad Piano
6. Stage E.Piano
7. 60’s E.Piano
8. Dig.E.Piano
9. Harpsichord
10. Pipe Organ
11. Electric Organ
12. Strings
PC disable
PC enable
CC disable
CC enable
MIDI channel DOWN
MIDI channel UP
1 2 3 4 5 6 7 8
9 10 11 12
Local on
Local off
±0-1-3-5
-6 -4 -2 +1 +3
+2 +4 +5
Lighter
Normal
Heavier
Auto power-o disable
2： Touch 3： Transpose 4： Eect
5： Metronome
Tempo Volume 6：
Pitch
1： Sound
7： MIDI
7： MIDI
9： Auto
po ower-
8： Demo songs
Power button
VOLUME knob
Power LED
METRONOME button
SOUND button
PIANO PL buttonAY
PEDAL jack (bottom)
DC IN jack
PHONES jack
AUDIO IN jack (*)
USB port (*)
Music stand
mounting holes
Illustration : B2/B2SP
Selecting Sounds
The B2/B2SP/B2N provides 12 keyboard instrument sounds.
Press the SOUND button to cycle through the preset sounds.
Each press will advance to the next sound, in the order shown
in the illustration:
1. German Concert Piano ¬ 2. Classic Piano ¬ 3. Italian Concert
Piano ¬ ... ¬ 12. Strings
After Strings, the sound will return to German Concert Piano
and the cycle will repeat.
Press the PIANO PLAY button to return to the German
Concert Piano sound at any time.
Sounds can also be chosen directly as described in the
Advanced Features.
At power-up, the default sound is German Concert Piano.
Accessing Advanced Features
To access the Advanced Features, simply hold down both the
PIANO PLAY and SOUND buttons while pressing the correct
key on the keyboard to select the corresponding parameter. Use
the large illustration above as a guide. These parameters are
divided into 9 sections.
Do not attempt to play the piano while holding down the
PIANO PLAY and SOUND buttons, or unintended changes
may occur.
1: Choose a Sound
Each of the 12 preset sounds is assigned to a specific key, as shown above.
2: Adjust the Touch
The dynamic response of the keyboard can be adjusted to match the
performer’s playing technique. Players with a lighter touch can achieve a
wider range of expression by choosing the Lighter setting. Player’s with a
heavy touch should select the Heavier setting.
The power-on default setting is Normal.
3: Transpose to any Key
The B2/B2SP/B2N can be easily transposed in semitone steps to play in
any key. The range is up 5 semitones or down 6 semitones. Use ±0 (No
Transposition) to turn the transpose feature off.
The power-on default setting is ±0.
4: Control the Reverb and Chorus Effects
Reverb and Chorus effects add ambience and motion to the sound. Each
Preset sound has been created with the optimal effect settings, yet you can
turn each effect on or off to suit your own taste.
5: Set the Metronome
The METRONOME button on the top panel to turn the metronome on
and off; the Advanced Features provide access to the Tempo, Beat (Time
Signature), and Volume parameters.The power-on default settings are
Tempo (q ) = 120; Beat = None; Volume = 10.
Tempo
The Tempo (q ) can be set from 40 to 240 using the corresponding x100, x10,
and p2-x1 keys. Values outside this range will be ignored.
For Example: To set the Tempo to (q ) = 85, press the ×10 key eight times and
the ×1 key five times; to set the Tempo to (q ) = 140, press the ×100 key once
and the ×10 four times.
Releasing the PIANO PLAY and SOUND buttons applies the setting.
Beat (Time Signature)
The Beat function provides an accent on the first beat of the measure.
Pressing the corresponding Beat key will advance through the Beat options
in a cycle:
2/4 → 3/4 → 4/4 → 6/4 → None → 2/4 → ...
Volume
Pressing the Low key reduces the metronome volume; pressing the High
key raises it. The metronome volume range can be set from 1 to 13.
6: Fine-Tune the Pitch
This value can be adjusted in 0.5 Hz steps down to 427.5 Hz or up to
452.5 Hz by repeatedly pressing the corresponding Higher or Lower
keys. Simultaneously press the corresponding Higher and Lower
keys to return to the default A4 = 440 Hz setting.
The power-on default setting is A4 = 440 Hz (Hertz).
7: MIDI
Local On/Off
Local On: With the Local On setting, playing the B2/B2SP/B2N's
keyboard produces the sounds of the performance as well as
transmits MIDI data.
Local Off: With the Local Off setting, playing the B2/B2SP/B2N's
keyboard does not produce the sounds of the performance; MIDI
data is only transmitted.
When the power is turned on (default setting), this is set to Local On.
Program Change
PC disable: The sending and receiving of MIDI Program Change
information is disabled.
PC enable: MIDI Program Change information will be sent and
received.
When the power is turned on (default setting), this is set to PC
enable.
Control Change
CC disable: The sending and receiving of MIDI Control Change
information is disabled.
CC enable: MIDI Control Change information will be sent and
received.
When the power is turned on (default setting), this is set to CC
enable.
MIDI Channel
Specify the transmission channel for MIDI data. The channel number
will decrease with each press of the DOWN key, and increase with
each press of the UP key. The default setting is channel 1.
8: Play the Demo Songs
Each of the 12 demo songs uses one of the 12 preset sounds. Select
a song using one of the 12 corresponding keys. The song will begin
to play immediately. After the selected song has finished, the
remaining songs will play, in order, and the whole cycle will repeat
until stopped.
To stop the demo song playback, simultaneously press and release
the PIANO PLAY and SOUND buttons.
* Adjust the input volume for USB-AUDIO and AUDIO IN
on the devices that are connected to the B2/B2SP/B2N.
- E-2 - - E-3 -
Produktspezifikationen
| Marke: | Korg |
| Kategorie: | Klavier |
| Modell: | B2 |
Brauchst du Hilfe?
Wenn Sie Hilfe mit Korg B2 benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten
Bedienungsanleitung Klavier Korg
17 August 2024
16 August 2024
5 August 2024
5 August 2024
1 August 2024
31 Juli 2024
30 Juli 2024
29 Juli 2024
26 Juli 2024
23 Juli 2024
Bedienungsanleitung Klavier
- Klavier Roland
- Klavier Vox
- Klavier Yamaha
- Klavier Technics
- Klavier Max
- Klavier Casio
- Klavier Thomann
- Klavier Alesis
- Klavier Kawai
- Klavier Native Instruments
- Klavier IDance
- Klavier Medeli
- Klavier NUX
- Klavier Nord
- Klavier Kurzweil
- Klavier Viscount
- Klavier Dexibell
- Klavier Artesia
- Klavier Orla
- Klavier ECHORD
- Klavier Crumar
- Klavier CLXmusic
- Klavier Carry-on
Neueste Bedienungsanleitung für -Kategorien-
14 Oktober 2024
20 September 2024
17 September 2024
17 September 2024
16 September 2024
14 September 2024
5 September 2024
5 September 2024
4 September 2024
3 September 2024
