KN-HDMICON10
2
COMPONENT TO HDMI CONVERTER
6
WANDLER VON COMPONENT IN HDMI
10
CONVERTISSEUR COMPOSANTE VERS
HDMI
14
COMPONENT NAAR HDMI OMZETTER
18
CONVERTITORE DA COMPONENT A
HDMI
22
COMPONENTE DEL CONVERSOR HDMI
26
KOMPONENS → HDMI JELÁTALAKÍTÓ
30
MUUNTAJA: KOMPONENTTI → HDMI
34
KOMPONENT TILL HDMI KONVERTER
38
PŘEVODNÍK KOMPONENTNÍHO
SIGNÁLU NA HDMI
42
CONVERTOR DE SEMNAL COMPOZIT
LA SEMNAL HDMI
2
ENGLISH
Introduction:
The Component video(YPbPr) converter allows older analogue devices to be integrated
seamlessly into the modern home theatre. This adapter connects Component video home
theater devices to HDMI compliant digital monitors. This adapter also takes digital audio and
encodes it onto the HDMI signal for the full HDMI video and audio effect. With the Component
+ Digital Audio to HDMI Adapter legacy home theater devices can be easily connected to any
HDMI display for the full digital video and audio experience.
Features:
• Allows you to connect YPbPr HDTV sources to an HDMI display
• Encodes digital audio onto the video signal for HDMI video and audio
• Supports HDTV/YPbPr
• Supports HDTV resolution up to 1080p
• HDMI compliant
Specifi cations:
Signal Inputs/Output
Input Video Signal 1.2 volts p-p
Input DDC Signal 5 volts p-p (TTL)
HDMI Connector type A (19 pin) female
Video Connector 3 RCA Component
Audio Connector SPDIF
Output Video HDMI
Video format supported
VGA 640x480, 800x600, 1024x768, 1920x1200
DTV/HDTV 480i/576i/480p/576p/720p/1080i/1080P
Operating Frequency
Frequency Up to 1.65 Gbps/165 MHz
Resolutions (HDTV)
Interlaced(50&60Hz) 480i, 576i, 1080i
Progressive(50&60Hz) 480p, 576p, 720p, 1080p
Environmental
Operating Temperature 0 °C to +70 °C
Operating Humidity 10% to 85 % RH (no condensation)
Storage Temperature -10 °C to +80 °C
Storage Humidity 5% to 90 % RH (no condensation)
Power Requirement
External Power Supply 5V DC@2A
Power Consumption 5 watts (max)
Regulatory Approvals
Converter Unit FCC, CE, UL
Power Supply UL, CE, FCC
3
Connections:
Front view:
Rear view:
1) Component video Input
2) SPDIF audio input
3) Power indication LED
4) Output HDMI port
5) Power adapter connection
