2013-08-30
CS500PLC4N100
MANUAL (p. 2)
4 port HomePlug 500Mbps
ANLEITUNG (S. 7)
4-Port HomePlug 500 Mbit/s
MODE D’EMPLOI (p. 13)
HomePlug 4 ports 500 Mbps
GEBRUIKSAANWIJZING (p. 19)
4-poorts HomePlug 500 Mbps
MANUALE (p. 25)
HomePlug da 4 porte 500 Mbps
MANUAL DE USO (p. 31)
HomePlug 500 Mbps de 4 puertos
HASZNÁLATI ÚTMUTATÓ (o. 37.)
4 portos HomePlug 500 Mbit/s
KÄYTTÖOHJE (s. 43)
4-porttinen HomePlug 500 Mbps
BRUKSANVISNING (s. 49)
HomePlug 500 Mbps med 4 portar
NÁVOD K POUŽITÍ (s. 55)
Zařízení HomePlug, 4 porty, 500 Mb/s
MANUAL DE UTILIZARE (p. 61)
HomePlug 500 Mbps cu 4 porturi
ΕΓΧΕΙΡΙΔΙΟ XPHΣ ΣH (σελ. 67)
HomePlug 500 Mbps 4 θυρών
BRUGERVEJLEDNING (s. 73)
4-ports HomePlug 500 Mb/s
VEILEDNING (s. 79)
4 ports HomePlug 500 Mbps
ИНСТРУКЦИЯ (стр. 85)
4-х портовое устройство HomePlug
500 Мбайт/ с
2
ENGLISH
4 port HomePlug 500Mbps
Chapter 1: HomePlug Power Line Installation
1.1 System Diagram
Add high-speed Internet access to any room in your home with this HomePlug AV Ethernet Bridge.
You can play HD movies, music, online multi-player games and much more. The best part of this
CS500PLC4N100 is that it has 4 built-in ports. Therefore, up to 4 network-enabled devices nearby can
be networked at the same time.
Note: This HomePlug AV 4-Port Ethernet Bridge needs to pair with at least one other HomePlug AV
compatible device in order to create a working system.
1.2 Casing details
Casing details / Status lights
The front of the device contains 3 types of status lights (see below)
Power
Light on: Power is on
Light off: Power is off
PLC link
The PLC (Power Line) link light will
indicate the overall speed of your network
with 3 colors.
Red: Minimum connection speed / weak
signal with speed less than 50 Mbps
Orange: Normal signal with standard
network speed between 50 – 100 Mbps
Green: Excellent signal strength with
optimal network speed of 100 Mbps+
Off: No connection / No activity
Modem / Router
Ethernet connection
CS500PLC4N100
Ethernet cable
Power line
CS500PLC4N100
Power
Ethernet connection
Ethernet link light
3
Ethernet link 1, 2, 3, 4
Solid green: 10/100/1000Mbps port linked
Blinking: 10/100/1000Mbps port
transmitting or receiving
Off: Ethernet link not active
Bottom details
The bottom casing contains 4 Ethernet ports
Left casing details
Security button
This button is designed to generate an
individual HomePlug network group in a
multi-node environment. Please refer to
the “Individual HomePlug Network Setup”
section below for more details.
Reset button
This button is used to clear ALL data and
restore ALL settings to the factory default
values.
Note: The HomePlug must be plugged in
to be restored to its all factory settings.
Using a small object like a paper clip, you
can press and hold the reset button for
about 3 seconds until the status light
begins to flash. Then, the device is in
factory default mode again.
1.3 Initial setup
The CS500PLC4N100 is a Plug-and-Play device. You can easily use the device without any
complicated configurations and settings. You can also use the device to connect network devices like
computers and game consoles directly. You can also connect devices like Blu-Ray Disc™ player to a
router or modem for internet access.
Connect the HomePlug AV Ethernet Bridge to a computer or modem / router:
1. Plug one end of the Ethernet cable into an Ethernet port on the bottom of the HomePlug.
2. Plug the HomePlug into an AC wall power outlet near the device you want to connect to.
Reset button
Security button
