FOR PROPER AND SAFE USE
WARNING
OPERATING TEMPERATURE AND CONDITIONS
This camera is designed for use from -10 to 40°C (14 to
104°F).
Never leave your camera where it may be subjected to extreme
temperatures such as inside the glove compartment of a car.
At colder temperatures, the data panel response time will be
slow. At higher temperatures, the display may temporarily
darken, but will restore when the temperature normalizes.
Never subject the camera to extreme humidity.
To prevent condensation from forming, place the camera in a sealed plastic bag
when bringing it from the cold exterior into a warm building. Allow it to come to
room temperature before removing it from the bag.
When photographing in cold weather, keep the camera and spare batteries inside
your coat to keep them warm when you are not shooting. Cold batteries will regain
some of their charge when they warm up.
FILM CASSETTE WARNING
The film used in Advanced Photo System cameras stores some data magnetically.
Do not place the film cassette on or near anything that creates a magnetic field, such
as a television or stereo speakers.
CAMERA ERROR
If the camera will not function with fresh batteries, remove the batteries, wait a few
minutes, then reinsert the batteries. If normal operation does not resume, or the
camera malfunctions repeatedly, contact an authorized Minolta Service Facility.
THIS CAMERA IS SPLASHPROOF AND CAN BE USED IN LIGHT RAIN OR SNOW.
Do not place the camera under running water or immerse.
Please Note:
1. When using the camera outdoors in heavy rain, keep the camera protected from
the rain. Do not leave the camera in the rain.
2. The interior of the camera is not water resistant.
- Dry the camera before opening the film or battery chambers.
- When inserting or removing film or batteries, keep your hands dry.
3. Do not load film or replace batteries in places where water, blowing sand, or dust
can enter the camera.
4. This camera is not sandproof, do not place the camera directly
on the ground.
5. Do not expose the camera to salt water or liquids containing
sugar.
6. Close the film and battery chamber covers tightly. Clean the
rubber seals before closing covers.
7. If the rubber seals appear cracked or damaged, contact an authorized Minolta
Service Facility to have them replaced.
8. Do not subject the camera to shock or impact.
EINSTRUCTION MANUAL
© 1996 Minolta Co., Ltd. under the Berne Convention and
Universal Copyright Convention
Read and understand all warnings and cautions before using this product.
Batteries may become hot or explode due to improper use.
Use only the batteries specified in this instruction manual.
Do not install the batteries with the polarity (+/–) reversed.
Do not subject batteries to fire or high temperatures.
Do not attempt to recharge, short, or disassemble.
Tape over lithium battery contacts before disposal. Follow local codes for
battery disposal.
Use caution, accidents may occur when using this product near young children.
Keep batteries or things that could be swallowed away from young children.
Contact a doctor immediately if an object is swallowed.
Immediately remove the batteries and discontinue use if...
the camera is dropped or subjected to an impact in which the interior is
exposed.
the product emits a strange smell, heat, or smoke.
Do not disassemble. Electric shock may occur if a high voltage circuit inside the
camera is touched. Take your camera to a Minolta Service Facility when repairs
are required.
Attaching
Insert the strap tab into the strap port until it
“clicks.
Removing
Press the strap release and pull the tab out of
the strap port.
ATTACHING AND REMOVING THE STRAP
9222-2281-11 T-B801
Minolta Co., Ltd. 3-13, 2-Chome, Azuchi-Machi, Chuo-Ku, Osaka 541-8556, Japan
Minolta GmbH Kurt-Fischer-Strasse 50, D-22923 Ahrensburg, Germany
Minolta France S.A. 365 Route de Saint-Germain, F-78420 Carrieres-Sur-Seine, France
Minolta (UK) Limited Rooksley Park, Precedent Drive, Rooksley, Milton Keynes, MK13 8HF, England
Minolta Austria Ges. m.b.H. Amalienstrasse 59-61, A-1131 Wien, Austria
Minolta Camera Benelux B.V. Zonnebaan 39, P.O. Box 6000, NL-3600 HA Maarssen, The Netherlands
Belgium Branch Kontichsesteenweg 38, B-2630 Aartselaar, Belgium
Minolta (Schweiz) AG Riedstrasse 6, CH-8953 Dietikon, Switzerland
Minolta Svenska AB P.O.Box 9058, Albygatan 114, S-17109 Solna, Sweden
Finland Branch Niittykatu 6 PL 37, SF-02201 Espoo, Finland
Minolta Portugal Limitada Av. do Brasil 33-A, P-1700 Lisboa, Portugal
Minolta Corporation
Head Office 101 Williams Drive, Ramsey, New Jersey 07446, U.S.A.
Los Angeles Branch 11150 Hope Street Cypress, CA 90630, U.S.A.
Minolta Canada Inc.
Head Office 369 Britannia Road East, Mississauga, Ontario L4Z 2H5, Canada
Vancouver Branch 230-3771 Jacombs Road, Richmond, B.C. V6V 2L9, Canada
Minolta Hong Kong Limited Room 208, 2/F, Eastern Center, 1065 King’s Road, Quarry Bay, Hong Kong, China
Minolta Singapore (Pte) Ltd. 10, Teban Gardens Crescent, Singapore 608923
Shanghai Minolta Optical
Products Co., Ltd. 368 Minolta Road, Songjiang, Shanghai, China
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
Changes or modifications not approved by the party responsible for compliance could void
the user's authority to operate the equipment. This equipment has been tested and found to
comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and the receiver.
Connect the equipment to an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
This Class B digital apparatus meets all requirements of the Canadian Interference-Causing
Equipment Regulations.
Thank you for purchasing a Minolta Advanced Photo System™ camera. To take part
in your active lifestyle, this camera was designed to be rugged and easy to use.
Before using your camera, familiarize yourself with the names and locations of the
camera controls and read this manual thoroughly.
*Advanced Photo System is a trademark of the five system developing companies,
including Minolta
Advantages of the Advanced Photo System
New print formats
Classic C print, wider H print, and panorama P print
formats are available with Advanced Photo System
cameras.
Easier to load
Advanced Photo System cameras use the new IX240 type film. This new film
features drop-in-loading to make loading your camera simple, the first time, every
time. Indicators on the cassette tell you and your camera if the film is unexposed,
partially exposed, exposed, or processed.
New processing
In addition to returning your prints in the format
you selected, certified photofinishers will return
your Advanced Photo System film in its original
cassette with an index print. To order reprints,
simply choose the images you want from the
index print. No more searching through negatives
to find the right frame.
NAMES OF PARTS
Camera Body
Shutter-release button
Film-chamber release
Release lock
Film chamber
Data panel
Flash*
Lens* Command switch
Strap port
Battery chamber
Viewfinder*
Viewfinder window*
Accessory port
* Do not touch
Data Panel Image Frames
H print
Flash charging indicator
Frame counter
Shutter-release button
Data panel
Flash*
Lens* Command switch
Viewfinder window*
Shutter-release button
Data panel
Flash*
Lens*
Command switch
Viewfinder window*
Battery warning
Command switch
P P print (Panorama)
H H print
C C print (Classic)
OFF Camera off
Self-timer
C print
P print
GX-1 GX-2 GX-3
Film-chamber release
Release lock
Film chamber
Strap port
Battery chamber
Viewfinder*
Accessory port Film-chamber release
Release lock
Film chamber
Strap port
Battery chamber
Viewfinder*
Accessory port
LOADING FILM
Use IX240 (Advanced Photo System) type film in this camera.
• ’Your camera s transport system loads the film and advances the film after each
exposure.
Do not open the film chamber until 0 appears or all indicators blink in the data panel.
Install the battery before loading the film, or the film will not advance to the first frame.
We recommend you use ISO 200 film in this camera.
Visual Exposure Indicators (VEI)
The current VEI has a white indicator behind it.
VEI MEANING
UNEXPOSED
PARTIALLY EXPOSED
EXPOSED
PROCESSED
Your camera can only load unexposed film ( ).
INSTALLING THE BATTERY
1. Using a coin or similar object, turn the
battery-chamber lock to open, then open the
battery-chamber door.
2. Insert a new battery into the chamber as
indicated by the + and - marks.
3. Close the battery-chamber door and turn the
battery-chamber lock to the close position.
Clean the rubber seals and joining surfaces before
closing covers.
TAKING PICTURES
1. Turn the command switch to the desired print
format.
Hold the camera steady, making
sure your fingers do not cover
the flash. If you are taking a
vertically framed picture, turn the
camera so the flash is on top.
Battery Warning
Replace the battery.
If no display appears, replace the battery or make sure it is correctly installed.
Do not remove the battery unless the battery warning blinks or no display
appears in the data panel.
If the data panel dims after the flash fires, the battery will need to be
replaced soon.
Your camera will shut down if it is not operated for more than three minutes.
To restore power, turn the command switch to OFF, then back to P, H, C, or
.
Loading Film
1. Turn the camera upside down, then press the
release lock and turn the film-chamber
release.
The film-chamber door will unlock.
Wipe dirt or moisture off of the camera and film
cassette before opening the film chamber.
2. Open the film-chamber door and insert a new
film cassette into the film chamber.
3. Press the film-chamber door closed and turn
the film-chamber release to the lock position.
The film cassette may be damaged if the film-chamber
release is moved when the film-chamber door is open.
4. Turn the command switch to C, H, or P.
5. Press the shutter-release button.
The film will advance to the first frame.
The frame counter displays the number of exposures
remaining on the roll.
If all indicators blink in the data panel, the film has not
loaded. Remove and reload the film cassette.
2. Frame your subject(s) in the image frame for
the selected print format.
3. Press the shutter-release button to take the
picture.
Keep your subject at least 1.0m (3.3 ft.) from the
camera.
• –With ISO 200 film, the flash has a range of 1.0 3.0m
(3.3 9.8 ft.) and will fire when necessary.
• ’You can t take a flash picture when blinks in the
data panel (flash charging).
4. Turn the command switch to off when the
camera is not in use.
After the last exposure is taken,0will appear in the data panel.
When the motor stops, open the film chamber and remove the film.
Remove your film immediately after rewinding. Film left in the camera may
reload causing double exposures.
Your camera uses one 3-volt CR2 lithium battery to supply power for all camera
operations. Please read the warnings in the Safety Cautions section of this manual
as well as those supplied by the battery manufacturer.
If film is in the camera when the battery is replaced, install a new battery immediately
after removing the old battery. If the battery is not replaced immediately, your camera
may advance one frame and display - - in the frame counter for the remaining
exposures. The frame counter will return to normal operation when a new film cassette
is loaded.


Produktspezifikationen

Marke: Konica-Minolta
Kategorie: Nicht kategorisiert
Modell: Vectis GX-1

Brauchst du Hilfe?

Wenn Sie Hilfe mit Konica-Minolta Vectis GX-1 benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten




Bedienungsanleitung Nicht kategorisiert Konica-Minolta

Bedienungsanleitung Nicht kategorisiert

Neueste Bedienungsanleitung für -Kategorien-
