Wireless tabletop presentation solution
QuickPresent air
QuickPresent air Lite
Ref no. 7488 000 400, 7488 000 405
Installation and user manual
GB
10.2019
2
Safety instructions
Please read this manual carefully and keep it for later reference.
• When connected to the mains, Kindermann QuickPresent air may only be operated at safety extra-low voltage
via the corresponding power pack.
• Store and use the product only in dry, dust-free, enclosed rooms in a building.
• The product is not suited for being used in open spaces.
• The product must not be dropped, thrown or subjected to mechanical shocks.
• Install the device in a suciently ventilated place.
• Do not use liquids or diluting agents for cleaning. Use a clean and dry cloth for cleaning the device.
(Disconnect the device from the mains before cleaning!)
• If the device is not used for a longer period of time, the power supply must be disconnected.
• Do not charge the battery for a longer time if the device is not used*.
• After a longer storage time and prior to first commissioning, it may be necessary to charge and discharge
the batteries repeatedly until they achieve their full capacity*.
• Batteries provide optimum power when operated at a room temperature of 20 °C ± 5 °C *.
• The supplied battery cannot be replaced by the user. Please contact the Kindermann service
for any queries regarding the battery*.
• The use of unsuitable accessories may cause damage or malfunction.
Intended use
Kindermann QuickPresent air is a HDMI-based selector switch for video and audio signals.
Any use other than that described in this manual is not permitted.
Please observe the safety instructions.
1. Overview
Kindermann QuickPresent air is a state-of-the-art tabletop presentation solution in a design enclosure for switching
up to three personal HDMI laptops plus one further mobile device (iOS, Android tablet, smartphone)
and displaying their contents on a central display or projector.
The HDMI sources are connected via three smooth-running cable retractors.
The video signal is transmitted from the meeting table to the display device via
virtually zero-latency wireless technology. No driver installation is required.
The incorporated battery* ensures up to 7 hours of operation
without having to connect QuickPresent air to the mains.
Intuitive operation via five illuminated buttons ensures the easy
and reliable selection of an image source for presentation.
The current version of the manual can be downloaded on the website at https://www.kindermann.de.
* The scope of supply for QuickPresent Air Lite does not include batteries
3
Table of contents
1. Overview .........................................................................................................................................................................................................................2
Scope of supply 41.1 .....................................................................................................................................................................................................
Functional diagram 51.2 ...............................................................................................................................................................................................
2. Device description 6 ............................................................................................................................................................................................................
QuickPresent air / Lite (transmitter): Ports and buttons 62.1 ........................................................................................................................
2.1.1 LOGO backlight 7 ..........................................................................................................................................................................................
2.1.2 Button backlight 8 .........................................................................................................................................................................................
2.1.3 Device configuration via DIP switch (5) 9 ..............................................................................................................................................
60 GHz HDMI receiver: Ports and button 102.2 ....................................................................................................................................................
Setting the receiver 102.3 ............................................................................................................................................................................................
3. QuickPresent air - quick start guide 11 ..........................................................................................................................................................................
Pairing the base station with a 60 GHz receiver 123.1 .........................................................................................................................................
How to connect mobile devices (Android and iOS) 123.2 ..................................................................................................................................
How to connect mobile devices (Windows) 133.3 ................................................................................................................................................
4. Operation with battery power* 14 ...................................................................................................................................................................................
5. Firmware update for WIFI receiver 15 ............................................................................................................................................................................
6. Care and maintenance 16 ..................................................................................................................................................................................................
6.1. Replacing/removing the battery* 16 ........................................................................................................................................................
6.2 Replacing cable HDMI retractors 17 .........................................................................................................................................................
7. Technical data of QuickPresent air / Lite 18 ................................................................................................................................................................
8. Resolutions and frame rates, video and audio formats 19 - 22 ..............................................................................................................................
9. Troubleshooting ..............................................................................................................................................................................................................23
* The scope of supply for QuickPresent Air Lite does not include batteries
