S P E C I F I C A T I O N S S U B J E C T T O C H A N G E W I T H O U T N O T I C E . D S 0 9 0 7 0 6
CAMERA GLOVE
VA-601-6 c g - 6
MATERIALS

Neoprene foam laminated between two
layers of elastic cloth

Clear PU UV protected windows

Nylon hook & loop material

Silent action YKK® zippers

Fastex-ITW® nylon or acetal buckles
KATA's new camera glove is custom fitted to your camera
so that it fits like a gloveî€:

Protection against cold, dirt, bumps and scratches

Attractive design

Improved product engineering: overlapping closure design

Accommodates batteries in several sizes

Designed not to interfere with camera operation
 î€ î€ systemPull to open!

Advanced materials:
The gloves are made of a specially engineered lamination:
A External layer of nylon elastic knit, which enables
ventilation and is not abrasive to your skin.
B Middle layer of shock resistant advanced closed cell
neoprene perforated foam, prevents overheating of your
camera.
C Internal knit layer protects the camera body.
This non-fray lamination enables you to cut open additional
slots to fit your exact working configuration.
KATA. A SIMPLE CASE
OF BET TER DESIGN.
Development & production by Ltd.KATA
POB 45078 Jerusalem , Israel 91450
Tel: + 972-2-5911000
Fax: + 972-2-5400504
www.kata-bags.com
Info: technical@kata-bags.com
Sales: video@kata-bags.com
Tw o o pti o n al
connecting points
of Rain Hood
pouch
Detachable pouch
holds emergency
Rain Hood
for PANASONIC AJ D400/D700/D800
D610WA, D910WA, PD900WA
for BTS LDK-700PHILIPS
for HITACHI Z-V1A
Free access to all
bottom areas
Hook & loop adjustment
ensures a snug fit on a wide
range of batteries, and protects
the battery well
Clea r vinyl acces s
window for LCD display
and control panel
Easily zips open giving
access to playback
controls
Flexible viewfinder glove
allows full rotation.
Zipper access to buttons
Back buckle
Front
buckle
Front fitting
point
Back fitting
point
Quick and easy
access to battery
Speaker
cut-out
Easy access to control
panel and alarm & monitor
bu tto ns by f ol d in g th e
overlapping flaps inward
Pull to open!
Pull in this direction
to open
Clear vinyl
window
The  î€ system allows openingPull to open!
in one fast movement, quick closing with hook
& loop or tight closing by zipper
Hook & loop
quick closing
1
2
3
4
6
5
7
8
9
10
13
14
16
15
19
12
18
17
11
includes Rain hood and flexible VF cover
SPARE PARTS (If lost or damaged)

VA-601-1-RH Rain Hood with pouch

VA-601-1-VF Flexible Viewfinder Cover
A
B
C
S P E C I F I C A T I O N S S U B J E C T T O C H A N G E W I T H O U T N O T I C E . D S 0 9 0 7 0 6
CAMERA GLOVE
VA-601-6 c g - 6
Please note Kata new CG-11 is to be introduced for Panasonic camcorders:
AJ-DP800 (P2 Series), AJ-HDC20, AJ-HDC27 (VARICAM)
AJ-SDX900, AJ-HDX400, AJ-SDC915, AJ-SDC615
If you purchased this CG-6 for any of these models, please contact us with
your details, and we will be glad to replace it with the new CG-11!
KATA. A SIMPLE CASE
OF BET TER DESIGN.
Development & production by Ltd.KATA
POB 45078 Jerusalem , Israel 91450
Tel: + 972-2-5911000
Fax: + 972-2-5400504
www.kata-bags.com
Info: technical@kata-bags.com
Sales: video@kata-bags.com
Overlapping
flaps
Two optional connecting
points for Rain Hood pouch
Free access to all
bottom areas
Rain Hood
pouch
Right hook
strap
Vinyl window
Main zipper
Viewfinder glove
Back buckle
Front
buckle
Emergency
Rain Hood
Back fitting
point
Closing pullers
Left hook
strap
Pull to open!
Speaker
cut-out
Vinyl window
Pull in this direction
to open
Hook & loop
quick closing
4. Setup card - For access to setup card slot open
main zipper (No.1) and buckles (No.3, No.5).
5. For access to covered buttons, fold overlapping flaps
inwards (No.14).
6. VIEW FINDER GLOVE
Open buckle and zipper and pull over VF.
If necessary, cut out a window to expose the Tally light.
7. Rain hood
Emergency Rain Hood (No.20)
in pouch (No.4).
The Rain Hood pouch has two
optional connecting
points: back and front (No.7)
1. Dressing the camera
Open the main zipper (No.1) and buckles (No.3, No.5).
Put the camera in the glove.
Stretch the bottom part to fit around points (No.17) and (No.19)
(important!)
Pull up and close zipper (No.1).
Close buckles (No.3) and (No.5).
(If you use a mic attached to the body, cut a slot in the Neoprene
according to line marked inside, before dressing the camera).
2. Adjustment to battery
First close left hook strap, (No. 12) then adjust back part to your
battery with right hook strap (No.11)
Use the left hook strap for changing battery (No.12)
Note:
do not open right hook strap (No.11) each time you change the battery.
3. Changing tape - system.Pull to open!
For changing tape pull strap (No.2) in a diagonal direction (No.18),
opening the whole zipper in one movement.
The hook & loop (No.16) enables quick temporary closing.
Use zippers (No.15) for tight closing.
GENERAL INSTRUCTIONS
1
3
4
6
7
5
2
8910
14
13 12
16 15
18
17
20
Front fitting
point
19
11
includes Rain hood and flexible VF cover
for PANASONIC AJ D400/D700/D800
D610WA, D910WA, PD900WA
for PHILIPS BTS LDK-700
for HITACHI Z-V1A
