Seite 1/5
1
Table of Contents
1) Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
2) Specications . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
3) Package Contents . . . . . . . . . . . . . . . . . . . . . . . . 2
4) Unit Layout & Description . . . . . . . . . . . . . . . . . . . 3
5) Connection andOperation . . . . . . . . . . . . . . . . . . . 3
6) ConnectionDiagram. . . . . . . . . . . . . . . . . . . . . . . 4
7) Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Notice
KanexPro™ reserves the right to make changes in the hardware, packaging and any accompanying docu-
mentation without prior written notice.
1x4 VGA Extender over CAT5/6 with Audio up to 1,000ft. (300m)
e KanexPro 1x4 VGA extender over CAT5e/6 cable is designed for routing and distributing four
high-resolution VGA signals and stereo audio over remote distances up to 1,000ft. (300m). Each receiver
set features a separate gain and peaking rotary switch used in adjusting brightness and skew over long
distances. e 15-pin HD connectors are convenient and cost-eective for all input/ output connec-
tions supporting full bandwidth. Fully compatible with VGA to WUXGA graphics cardresolution
and HDTV’s to projectors. In addition, each output performs a separate buering to maintain signal
integrity and reject noise interference.
Features:
• Extendfourindependenthigh-resolutionVGAsignalswithaudiooverCat5E/6cablesupto
1,000 feet (300m)
•AdjustGAINandPEAKlevelstoadaptforvariablelengthsofUTPcableonthereceiverside
•SupportsmaximumresolutionsuptoWUXGA(1920x1200@60Hz)
•Stereoaudiothrough3.5mmjack
•Dualoutputfortransmitter:VGAforlocaldisplayand4xCat5e/6
•EDIDCompliant
•Rackorunder-deskmountable
•5VDCexternalpowersupplyincluded
TM
2
Interface: Transmitter(TX)
Input: VGA x1/3.5mm Stereo x1
Output: Cat 5e/6 x4/VGA Output (Local) x1/3.5mm Stereo x1
Receiver(Rx)
Input: Cat 5e/6 x1
Output: VGA x1/3.5mm Stereo x1
Operating Frequency: VerticalFrequencyRange60/75/85Hz
Resolutions (PC):
640x480 800x600 1024x768
1280x720 1280x768 1280x960
1280x1024 1600x900 1600x1200
1920x1080 19200x1200
Power Supply: Transmitter:5VDC@2A,10W
 Receiver:5VDC@2A,5W
Environmental: Operating Temperature: 0°C to +70°C
 OperatingHumidity:10%to85%RH(nocondensation)
 StorageTemperature:-10°Cto+80°C
 StorageHumidity:5%to90%RH(nocondensation)
Regulatory Approvals Converter: FCC, CE, UL
Regulatory Approvals Power Supply: FCC, CE, UL
Dimensions: VGA Transmitter: 5.75”x2.75”x1” (146x70x25.5mm)
 Receiver:3.25”x1.4”x0.8”(82.6x35.6x20mm)
Weight: VGA Transmitter: 0.7lbs (320g)
Receiver:0.25lbs(115g)
Warranty: 1 Year limited
1)VGA UTP Extender Transmitter x1
2)VGAUTPExtenderReceiverx4
3)5VDC@2A/5WPowerSupplyx4
4)5VDC@2A/10WPowerSupplyx1
4)Mounting Kit x1
3
1) Power LED
a. LED will be active when unit is powered on
2) Video/Audio Input
a. Connect to VGA source (TV, Monitor, Projector, etc) using a VGA 15 pin Male to Male cable for video and
3.5mm Stereo Male to Male cable for audio.
3) Video/Audio Out
a. Connect to VGA display (TV, Monitor, Projector, etc) using a VGA 15 pin Male to Male cable for video
and 3.5mm Stereo Male to Male cable for audio.
4) Cat5e/6 Output
a. ConnecttotheCat5e/6(UTP)inputontheReceiverunit.
5) DC/5V Connector
a. Connect the 5V Switch Splitter power supply to this port
Transmitter
Front
Power VGA Input VGA Output
Output 4 Output 3 Output 2 Output 1
Back
23
1
4 5
Receiver
InputPower
VGA Output
Back
Front
1) Video/Audio Output
a. Connect to VGA display (TV, Monitor, Projector, etc) using a VGA 15 pin Male to Male cable for video
and 3.5mm Stereo Male to Male cable for audio.
2) Power LED
a. LED will be active when unit is powered on
3) Cat5e/6(UTP)input
a. Connect to the Cat5e/6 output on the Transmitter
4) DC/5V Connector
a. Connect the 5V Switch Splitter power supply to this port
5) Gain
a. Rotarydialusedforadjustingthebrightnessonthedisplays
6) Peak
a. Rotarydialusedforadjustingtheskewforlongcableruns
34
1 2
GAIN PEAK
Side
56
