JT-DPM8600
Programmable lab power supplies
2. GENERAL INFORMATION
Dear customer,
thank you for choosing our product. In the following, we will show you how
to use your product.
Should you encounter any unexpected problems during use, please do not
hesitate to contact us.
1. SAFETY INSTRUCTIONS
Our product is suitable for up to 75 Volt DC. Working with voltage
over 60 V DC is re-served for trained electricians, because of the
hazard of an electric shock which may cause serious injuries or
death. Non-electricians have to use a voltage source below 60
Volt DC. !
Model
3. TECHNICAL PARAMETERS
The DPM8600 series are programmable power supplies which have a large
output power, are compact and are well structured. At the same time, it is
equipped with TTL serial communication interface or RS485 communication
interface, which provides a serial communication protocol.
I -RTUt can also be applied to modbus communication protocol and supports
further development from users. Moreover, it can provide multi-purpose
solution according to your design and testing requirements.
Also, a DPM8600 series can be equipped with wireless remote control. The
wireless controller adopts 2.4-inch LCD screen. It has many display values,
a a simple operation, built-in lithium battery which can be recharged and it
can control the power supply from up to 10 meters wirelessly. The wireless
controller can control multiple power supplies simultaneously.
This modular power supply can be applied in several aspects. It can be used
for example as an ammeter, a smartmeter, a LED driver, a voltage regulator
for solar panels or in an industrial control.
If the device is damaged or the scope of delivery incomplete, do not use it
and contact our support. Otherwise, if the device is damaged, it could cause
shorts and the device could iname.
NOTE: The following description uses the DPM8624 as an example.
The DPM8605 works similar to the DPM8624.
DPM-8605 DPM8624-485
Input voltage 10 - 75 V 10 - 75 V
Output voltage 0 - 60 V 0 - 60 V
Output current 0 - 5 A 0 - 24 A
Output power 0 - 300 W 0 - 1440 W
Communication
interface
DPM-8605 TTl serial communication interface
DPM8624-485 RS-485 communictaion interface
Voltage resolution 10 mV
Current resolution 1 mA 10 mA
Output ripple < 50 mVpp
Eî ‚iciency 92 %
Display accuracy 10 mV, 1 mA 10 mV, 1 mA
Output tolerance voltage: ± 2 % / current: ± 5 %0 0
Response time < 50 ms
Dimension 120 · 131 · 55 mm 150 · 120 · 59 mm
Applied ambient
temperature -25 - 60 °C
4. MODULE
5. DISPLAY
Power Switch
Negative input
Positive input
LED digital tube
Fan
Working status
indicator
Positive output
Negative output
Communication
interface
Function
buttons
05.00
03.00
I-SA
_ _10
I-SA
_ _11
I-SA
_ _12
2-dF
__ _N
2-dF
__ _Y
3-ON
__ _0
3-ON
__ _1
4-Fd
__ _0
4-Fd
__ _1
5-CS
__ _0
5-CS
__ _1
6-bd
0096
7-Ad
_ _01
8-CH
_ _01
-Ld-
__ _0
-SA-
__ _0
Corr
- C-°
0280
shows voltage values
shows current values
Sets upper limit of voltage and current
Activates quick response
Sets lower limit of voltage and current
Cancels the limits of voltage and current
No factory settings
Sets device to factory settings
When the device starts, it works only aî …er
activating it
It works automatically aî …er the start
Deactivates quick response
Simple communication
Communication with modbus
Possible to select 2.4, 4.8, 9.6, 19.2, 38.4,
57.6, 115.2 (Kbps) as the baud
99 communication addresses
31 communication channels from 00 to 30
(00 means no connection)
Calls parameter from a storage location
0 - 9
Saves parameters to storage location
Calibrate voltage and current
Displays temperature of the device
