Seite 1/36
Conforms to ANSI Z21.88-2016 โ€ข CSA 2.33-2016
and CAN/CGA 2.17-M17
Installation and
Operation Instructions
Jรธtul GI 450 DV II
Katahdin
Direct Vent Fireplace Insert
โ€“ Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
โ€“ WHAT TO DO IF YOU SMELL GAS
โ€ข Do not try to light any appliance.
โ€ข Do not touch any electrical switch; do
not use any phone in your building.
โ€ข Immediately call your gas supplier
from a neighborโ€™s phone. Follow the gas
supplierโ€™s instructions.
โ€ข If you cannot reach your gas supplier,
call the fire department.
โ€“ Installation and service must be
performed by a qualified installer, service
agency or the gas supplier.
โ€“ In the Commonwealth of Massachusetts,
a carbon monoxide (CO) detector shall
be installed in the same room as the
appliance.
WARNING: If the information in these
instructions is not followed exactly, a fire or
explosion may result causing property damage,
personal injury or loss of life.
This appliance may be installed in an aftermarket,
permanently located, manufactured home or
mobile home, where not prohibited by local codes.
This appliance is only for use with the types of gas
indicated on the rating plate. A conversion kit is
supplied with the appliance.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
๎˜Ÿ๎˜ž๎˜๎˜œ๎˜›๎˜›๎˜š๎˜™๎˜›๎˜ž๎˜˜๎˜™๎˜—๎˜š๎˜–๎˜•๎˜™๎˜˜๎˜ž๎˜”๎˜“๎˜ž๎˜›๎˜™๎˜˜๎˜’๎˜‘๎˜™๎˜ž๎˜”๎˜๎˜™๎˜ž๎˜๎˜’๎˜›๎˜•๎˜ž๎˜๎˜œ๎˜๎˜œ๎˜›๎˜˜
๎˜Ž๎˜›๎˜“๎˜๎˜ž๎˜”๎˜๎˜™๎˜ž๎˜–๎˜Œ๎˜œ๎˜—๎˜—๎˜ž๎˜‹๎˜š๎˜™๎˜Š๎˜š๎˜•๎˜–๎˜ž๎˜œ๎˜›๎˜™๎˜œ๎˜ž๎˜š๎˜—๎˜ž๎˜‰๎˜›๎˜“๎˜‹๎˜š๎˜˜๎˜™๎˜˜๎˜ž๎˜Š๎˜š๎˜”๎˜๎˜ž๎˜”๎˜๎˜š๎˜—
๎˜œ๎˜‰๎˜‰๎˜Œ๎˜š๎˜œ๎˜•๎˜‘๎˜™๎˜ž๎˜œ๎˜•๎˜˜๎˜ž๎˜—๎˜๎˜œ๎˜Œ๎˜Œ๎˜ž๎˜๎˜™๎˜ž๎˜š๎˜•๎˜—๎˜”๎˜œ๎˜Œ๎˜Œ๎˜™๎˜˜๎˜ž๎˜Ž๎˜“๎˜›๎˜ž๎˜”๎˜๎˜™๎˜ž๎˜‰๎˜›๎˜“๎˜”๎˜™๎˜‘๎˜”๎˜š๎˜“๎˜•
๎˜“๎˜Ž๎˜ž๎˜‘๎˜๎˜š๎˜Œ๎˜˜๎˜›๎˜™๎˜•๎˜ž๎˜œ๎˜•๎˜˜๎˜ž๎˜“๎˜”๎˜๎˜™๎˜›๎˜ž๎˜œ๎˜”๎˜ˆ๎˜›๎˜š๎˜—๎˜‡๎˜ž๎˜š๎˜•๎˜˜๎˜š๎˜‹๎˜š๎˜˜๎˜’๎˜œ๎˜Œ๎˜—๎˜†
๎˜Ÿ๎˜ž๎˜๎˜œ๎˜›๎˜š๎˜™๎˜˜๎˜˜๎˜Ÿ๎˜ž๎˜๎˜œ๎˜œ
๎˜›๎˜š๎˜™๎˜˜๎˜—๎˜Ÿ๎˜–๎˜™๎˜•๎˜”๎˜˜๎˜“
๎˜—๎˜–๎˜•๎˜–๎˜”๎˜Ÿ๎˜š๎˜œ๎˜œ๎˜’๎˜ž๎˜Ÿ๎˜›๎˜‘๎˜๎˜œ๎˜๎˜•๎˜—๎˜”
๎˜๎˜’๎˜Ÿ๎˜๎˜’๎˜™๎˜›๎˜‘๎˜Ÿ๎˜Ž๎˜œ๎˜š๎˜˜๎˜˜๎˜“
๎˜“๎˜ž๎˜œ๎˜—๎˜ž๎˜๎˜œ๎˜๎˜ž๎˜’๎˜‘๎˜Ÿ๎˜œ๎˜›๎˜š๎˜™๎˜˜๎˜˜
๎˜™๎˜”๎˜๎˜๎˜œ๎˜Ÿ๎˜›๎˜’๎˜’๎˜œ๎˜—๎˜๎˜“
๎˜“๎˜™๎˜—๎˜›๎˜–๎˜”
๎˜Ÿ
2
139177-V GI 450 DVII 11/20
69.49%
Jรธtul GI 450 DV II
We recommend that
our gas products be
installed and serviced by
professionals who are
certified in the U.S. by
the National Fireplace
Instituteยฎ (NFI) as NFI
Gas Specialists.
Installation Requirements
for the Commonwealth of
Massachusetts
THIS PRODUCT MUST BE INSTALLED BY
A LICENSED MASTER OR JOURNEYMAN
PLUMBER OR GAS๎˜ŸFITTER WHEN
INSTALLED IN THE COMMONWEALTH OF
MASSACHUSETTS.
1. If there is not one already present,
on each floor level where there are
bedroom(s), a carbon monoxide
detector and alarm shall be placed in
the living area outside the bedroom(s).
The carbon monoxide detector shall
comply with NFPA 720 (2005 Edition).
2. A carbon monoxide detector shall:
a) Be located in the room that houses
the appliance or equipment;
b) Be either hard-wired or battery
powered or both; and
c) Shall comply with NFPA 720 (2002
Edition).
3. A Product-approved vent terminal
must be used, and if applicable, a
Product-approved air intake must
be used. Installation shall be in strict
compliance with the manufacturerโ€™s
instructions. A copy of the installation
instructions must remain with
the appliance or equipment at the
completion of the installation.
Massachusetts Approval Code G3-0817-12
Based on CSA P.4.1-15
Suggested Tools for Installation and Service
โ€ข External regulator (for Propane only)
โ€ข Piping which complies with local code
โ€ข Manual shut-off valve -
T-Handle required in Massachusetts
โ€ข Sediment trap - if required by code
โ€ข Tee joint
โ€ข Pipe wrench
โ€ข Pipe sealant
โ€ข 10 mm open end wrench
โ€ข 1/2โ€, 7/16โ€ open end wrench
โ€ข Phillips head screwdriver
โ€ข Flat head screwdriver
โ€ข 1/4โ€ nut driver
โ€ข Work Gloves
โ€ข Safety glasses
โ€ข Torx T-20 screwdriver
โ€ข Tin snips
THIS OWNERโ€™S MANUAL PROVIDES INFORMATION TO
ENSURE SAFE INSTALLATION AND EFFICIENT, DEPENDABLE
OPERATION OF YOUR FIREPLACE INSERT. PLEASE READ
THESE INSTRUCTIONS IN THEIR ENTIRETY AND MAKE THEM
AVAILABLE TO ANYONE USING OR SERVICING THIS GAS
INSERT.
DO NOT ATTEMPT TO ALTER OR MODIFY THE CONSTRUCTION
OF THIS APPLIANCE OR ITS COMPONENTS. ANY
MODIFICATION OR ALTERATION WILL VOID THE WARRANTY,
CERTIFICATION AND LISTING OF THIS APPLIANCE.
THIS HEATER MUST BE INSTALLED AND MAINTAINED BY A
QUALIFIED SERVICE AGENCY.
PLEASE NOTE:
Initial Break-in
It is normal for smoke and odor to occur during the initial
stages of operation, depending upon temperatures
generated over time. This โ€œcuringโ€ condition can be
alleviated by promoting fresh air circulation within the
immediate vicinity of the appliance.
Operation Sound
Please be aware that cast iron and steel components
expand and contract with temperature fluctuations that
are often accompanied by
โ€œcreakingโ€ or โ€œpingingโ€ sounds.
This is the result of natural
thermal activity.
The optional blower fan
will also generate a slight
hum at the low setting and
progressively increase with the
velocity of forced air.
3
139177-V GI 450 DVII 11/20
Table of Contents
Installation & Service Tools 2 .........
Unpacking the Fireplace 3 ................
Specifications ....................................4
General Information ........................5
Safety Information 6 ..........................
Installation
Fireplace Requirements 7 ..............
Hearth Protection 7 ..........................
Clearances 9 ........................................
Vent Guidelines 10 .............................
Masonry Fireplaces 11 ......................
Prefabricated Fireplaces 12 ...............
Vent Requirements 13 .......................
Fireplace Assembly
Gas Connection 14 .............................
Gas Pressure................................... 14
Fuel Conversion 16 .............................
High Altitude Adjustment 18 ..........
Flame Picture Adjustment 19 .........
Optional Brick Panel Kits 20 ...........
Log Set Installation 21 .......................
Wall Thermostat ...........................23
Remote Control 23 ...........................
Surround Assembly 24 ......................
Operation
Burner Controls 26 ...........................
Blower Controls ...........................27
System Check ................................27
Maintenance
Annual Cleaning 28 ...........................
Glass Replacement 28 .......................
Illustrated Part Breakdown ........ 30
Appendix A / Wiring Diagrams,
Approved Vent Manufacturers ...........32
Appendix B / Simple Surround .........33
Warranty Statement ....................34
Lighting Instructions ..................... 35
Unpacking the Fireplace
1. A Miscellaneous Hardware Kit is packed within
the firebox crate. It contains:
โ€ข Installation / Operation manual
โ€ข Fuel Conversion Kit, LP
โ€ข 3/8โ€ x 7โ€ pipe nipple
โ€ข Rock Wool
2. Remove Pallet Bracket screws - two on each side.
3. Remove the Latch Tool from the shipping pallet.
4. SAFETY BARRIER SCREEN: This appliance is equipped
with a Certified Barrier Screen that must be installed
before operating the unit. It is shipped in the installed
position and must be removed to access the firebox.
Simply lift it up and out to disengage the hooked
barrier brackets from the the slotted firebox brackets.
5. Use the Latch Release tool to remove the fireplace
glass frame in order to install the log set and
other accessories.
Locate the right and left spring latches on the
underside of the firebox floor. See fig. 1.
Release each latch by engaging the tangs of the
tool with the latch release, pulling it down and
forward.
Pull the Glass Frame away from the Firebox and
lift to disengage it from the retaining lip at the
top of the firebox. Set the glass out of the way.
6 The Log Set is packaged separately from the fire-
box. Do not unpack the log set until you are ready
to install it.
7. The Upper and Lower Grill panels and Surround
Panels require some assembly. See pages 24-25.
๎˜Ÿ๎˜ž๎˜๎˜œ๎˜›๎˜š๎˜™๎˜˜๎˜ž๎˜—๎˜—๎˜–๎˜œ๎˜—
๎˜•๎˜ž๎˜”๎˜“๎˜œ๎˜—๎˜™๎˜Ÿ๎˜’๎˜‘๎˜›๎˜
๎˜Ÿ๎˜๎˜—๎˜—๎˜‘๎˜๎˜”๎˜Ž
๎˜๎˜ž๎˜”๎˜œ๎˜’
๎˜•๎˜ž๎˜”๎˜“๎˜œ๎˜—
๎˜Ÿ๎˜’๎˜‘๎˜›๎˜
Figure 1. Pull each Spring Latch out and
down to disengage it from the Glass Frame.
Battery Box
