Seite 1/5
I N S T A L L A T I O N G U I D E
for the
SB-J-WRUP/10TW1
SKU# 94607 & 94609
2007-2017 Jeep Wrangler Unlimited
Thank you for choosing a JL Audio Stealthbofor your automotive sound system.
With proper installation, your new vehicle-specific enclosed subwoofer system
will deliver years of listening pleasure.
We strongly recommend that you have your new Stealthboinstalled by your
authorized JL Audio dealer. The installation professionals employed by your
dealer have the necessary tools and experience to disassemble and reassemble
your vehicle properly. If you prefer to perform your own installation, please read
this installation guide completely before beginning the process.
If you choose to perform the installation yourself, it is absolutely vital
that the Stealthbox® be properly mounted to the vehicle according to
these instructions. Failure to mount the enclosure properly presents two
problems:
1) The sub-bass performance will suffer due to the movement of the
enclosure caused by the force exerted by the woofer(s).
2) A loose enclosure presents a serious safety hazard in the event of a
collision or sudden deceleration.
INSTALLATION
DIFFICULT Y:
ESTIMATED TIME:
1 HOUR
Enclosure Type: Sealed
Driver Type: 10TW1
Nominal Impedance: 4 ohms
Continuous Power Handling: 300 watts (RMS method)
Continued on Next Page
25
OUT
OF
SB-J-WRUP/10TW1 INSTR_SKU# 011388
I N C LUD E D H A R D W A R E
Continued on Next Page
Page 2 • JL Audio, Inc., 2019
SB-J-WRUP/10TW1 INSTR_SKU# 011388
BOM ID DescriptionQty SKU
1 1 153544 3/8 - 16 x 1” Hex Button Head Cap Screw Black
2 3 153548 3/8” M10 Serrated Spring Washer Black
3 5 153549 3/8” Flat Washer Black
4 1 150730 Front Bracket
5 2 150731 Rear Bracket
6 2 153550 3/8” Nylon Washer Black
7 2 153634 M8 x 30 mm 1.25 Flange Head Bolt Black
8 2 153633 M8 x 45 mm 1.25 Flange Head Bolt Black
9 2 153546 M8 1.25 mm Pitch Hex Flange Lock Nut
10 2 153547 3/8 - 16 x 1” Hex Head Bolt Black
1
2
3
4
5
6
3
7
8
9
3
2
10
P O W E R R E C O M M E N D AT I O N
JL Audio recommends high quality ampliers such as the JL Audio XD300/1v2. The diagram below shows the recommended crossover settings for the XD300/1v2 For a detailed description of the
amplier settings, consult the owner’s manual for the amplier. If another amplier is being used, please reference this illustration and use similar settings on that amplier.
C O N N E C T I O N S
Using quality power, signal, and speaker wire is essential in ensuring the performance of your Stealthbo. JL Audio recommends using a 4 AWG power kit such as the XD-PCS4-1B for your
Stealthboamplier. Other kits are available should you be using more than one amplier. Signal wire such as the JL Audio Premium Audio Interconnect Cables should be used to provide signal for
both channels of the amplier. JL Audio recommends using 12AWG speaker wire for subwoofers such as our XC-BCS12-25.
Continued on Next Page
Page 3 • JL Audio, Inc., 2019
SB-J-WRUP/10TW1 INSTR_SKU# 011388
