Seite 1/9
Thank you for choosing a JL Audio Stealthbofor your automotive sound system.
With proper installation, your new vehicle-specific enclosed subwoofer system
will deliver years of listening pleasure.
We strongly recommend that you have your new Stealthbox® installed by your
authorized JL Audio dealer. The installation professionals employed by your
dealer have the necessary tools and experience to disassemble and reassemble
your vehicle properly. If you prefer to perform your own installation, please read
this installation guide completely before beginning the process.
If you choose to perform the installation yourself, it is absolutely
vital that the Stealthbox® be properly mounted to the vehicle
according to these instructions. Failure to mount the enclosure
properly presents two problems:
1) The sub-bass performance will suffer due to the movement of the
enclosure caused by the force exerted by the woofer(s).
2) A loose enclosure presents a serious safety hazard in the event of a
collision or sudden deceleration.
INSTALLATION
DIFFICULT Y:
ESTIMAT ED TIME:
2-3 HOURS
Enclosure Type: Sealed
Driver Type: 10TW1
Nominal Impedance: 2 or 4 ohms
Continuous Power Handling: 300 watts (RMS method)
Continued on Next Page
45
OUT
OF
SB-J-JL4DDRV/10TW1 & SB-J-JL4DPAS/10TW1 INSTR_SKU# 011510
I N S T A L L A T I O N G U I D E
for the
SB-J-JL4DDRV/10TW1-2
SB-J-JL4DDRV/10TW1-4
SKU# 94664 (2 W) & 94665 (4 W)
SB-J-JL4DPAS/10TW1-2
SB-J-JL4DPAS/10TW1-4
SKU# 94666 (2 W) & 94667 (4 W)
2018-Up Jeep Wrangler (JL) 4-Door
I N C LU D E D H AR D WA R E
123
1
2
3
9
6
11
5
10
8
65
7
4
3
2
1
Continued on Next Page
Page 2 • JL Audio, Inc., 2019
BOM ID DescriptionQty SKU
1 5 153998 5/16 - 18 Hex Nut
2 5 150929 5/16” Split Lock Washer
3 5 153997 5/16” Oversized Flat Washer
4 2 153991 5/16” Rubber Sealing Washer
5 3 153994 5/16 - 18 x 1” Hex Head Bolt
6 3 153995 5/16” Flat Washer
7 4 153996 M6 x 45mm Socket Flanged Button Screw
8 2 153992 5/16” Retaining Washer
9 1 153776 1/4” Aluminum Spacer
10 1 153976 Mounting Bracket
11 2 153990 5/16 - 18 x 1-1/4” Square Neck Carriage Bolt
- 8 154000 Fender Shield Retainer Clip (not shown)
- 8 153999 1/4” x 2-3/16” Nylon Expansion Rivet (not shown)
SB-J-JL4DDRV/10TW1 & SB-J-JL4DPAS/10TW1 INSTR_SKU# 011510
P O W E R R E C O M M E N D AT I O N
JL Audio recommends high quality ampliers such as the JL Audio XD300/1v2. The diagram below shows the recommended crossover settings for the XD300/1v2. For a detailed description of the
amplier settings, consult the owner’s manual for the amplier. If another amplier is being used, please reference this illustration and use similar settings on that amplier.
Rem. |
Oset | Signal
Input Voltage
Low | High
Turn-On Mode
Monoblock Subwoofer Amplifier
C O N N E C T I O N S
Using quality power, signal, and speaker wire is essential in ensuring the performance of your Stealthbo. JL Audio recommends using a 4 AWG power kit such as the XD-PCS4-1B for your
Stealthbox® amplier. Other kits are available should you be using more than one amplier. Signal wire such as the JL Audio Premium Audio Interconnect Cables should be used to provide signal for
both channels of the amplier. JL Audio recommends using 12 AWG speaker wire for subwoofers such as our XC-BCS12-25.
Continued on Next Page
Page 3 • JL Audio, Inc., 2019
SB-J-JL4DDRV/10TW1 & SB-J-JL4DPAS/10TW1 INSTR_SKU# 011510
