I N S T A L L A T I O N G U I D E
for the
SB-GM-COEXT2G/10TW3
SKU# 94660
2015-2022 Chevrolet Colorado & GMC Canyon Extended Cab
Thank you for choosing a JL Audio Stealthbox® for your automotive sound system.
With proper installation, your new vehicle-specific enclosed subwoofer system
will deliver years of listening pleasure.
We strongly recommend that you have your new Stealthbox® installed by your
authorized JL Audio dealer. The installation professionals employed by your
dealer have the necessary tools and experience to disassemble and reassemble
your vehicle properly. If you prefer to perform your own installation, please read
this installation guide completely before beginning the process.
If you choose to perform the installation yourself, it is absolutely
vital that the Stealthbox® be properly mounted to the vehicle
according to these instructions. Failure to mount the enclosure
properly presents two problems:
1) The sub-bass performance will suffer due to the movement of the
enclosure caused by the force exerted by the woofer(s).
2) A loose enclosure presents a serious safety hazard in the event of a
collision or sudden deceleration.
INSTALLATION
DIFFICULTY:
ESTIMATED TIME:
1 HOUR
Enclosure Type: Sealed
Driver Type: 10TW3-D4
Nominal Impedance: 2 ohms
Continuous Power Handling: 400 watts (RMS method)
Continued on Next Page
15
OUT
OF
SB-GM-COEXT2G/10TW3 INSTR_SKU# 011505
I N C LUD E D H A R D W A R E
Continued on Next Page
Page 2 • JL Audio, Inc., 2023
SB-GM-COEXT2G/10TW3 INSTR_SKU# 011505
BOM ID DescriptionQty SKU
1 2 153960 Bracket
2 2 151096 3/8” Flat Washer
3 2 151081 3/8” Split Lock Washer
4 2 151079 3/8 - 16 x 1-1/4” Hex Bolt
P O W E R R E C O M M E N D AT I O N
JL Audio recommends high quality ampliers such as the JL Audio XD300/1v2. The diagram below shows the recommended crossover settings for the XD300/1v2. For a detailed description of the
amplier settings, consult the owner’s manual for the amplier. If another amplier is being used, please reference this illustration and use similar settings on that amplier.
Rem. |
Oset | Signal
Input Voltage
Low | High
Turn-On Mode
Monoblock Subwoofer Amplifier
C O N N E C T I O N S
Using quality power, signal, and speaker wire is essential in ensuring the performance of your Stealthbox®. JL Audio recommends using a 4 AWG power kit such as the XD-PCS4-1B for your
Stealthboamplier. Other kits are available should you be using more than one amplier. Signal wire such as the JL Audio Premium Audio Interconnect Cables should be used to provide signal for
both channels of the amplier. JL Audio recommends using 12 AWG speaker wire for subwoofers such as our XC-BCS12-25.
Continued on Next Page
Page 3 • JL Audio, Inc., 2023
SB-GM-COEXT2G/10TW3 INSTR_SKU# 011505
