computer radio control system EN
extended serie
Jeti are designated for use with the DUPLEX Receivers DC/DS
transmitters JETI transmitter modules or the in the 2,4 GHz
frequency band. DUPLEX receivers are offered in a wide range of
size and features to suit the numerous demands of our
customers. The DUPLEX receivers range from the tiny DUPLEX
R4-R7 receivers R8-R12 for small and medium model sizes to the
receivers for larger models. Last but not least, the R14 and R18
receivers are available for giant or really complex models. The
receiver selection can be expanded through the use of auxiliary
receivers ( outside the RSat 2 US or Duplex EX R5-R11 in the US
and Canada) to increase safety and peace of mind.
Receivers
1 Introduction ENGLISH
FW. ver. 3.10
computer radio control system EN
The legacy DUPLEX system was designed to give maximum
dependability, a property which has proven itself through many
successful years of use. Based on user input, the system is
continuously improved. Thanks to online updates the
improvements are easily accessible to users from any part of the
world. From the very beginning bidirectional transmission has
been a distinctive feature of the DUPLEX system, this not only
handles telemetry data, but it also help to ensure secure primarily
transmission safety between the transmitter and receiver.
The system uses an open protocol. This DUPLEX EX telemetry
gives the advantage of compatibility with a large number of
telemetry sensors from both JETI Model and third party
producers. For the display of telemetry data you can use
purposely designed equipment like the JETIBOX profi and
DC/DS transmitters or you can display the data with the onPCs
free Flight Monitor program.
Although our development of the DUPLEX system seems to be
very fast, we make the extra effort to keep backward
compatibility with earlier DUPLEX versions. By design, users are
not forced to continually buy new equipment to take advantage
of the latest improvements.
The JETI Model company portfolio contains a diverse offering of
electronic modelling equipment like voltage regulators, motor
speed controllers, telemetry data display equipment, telemetry
sensors and, last but not least, DC/DS transmitters. The JETI
Model product manfacturing policy is to constantly produce the
highest quality product possible.
computer radio control system EN
Basic Data
R4
R4C
(R4C
mini)
R5
(R5
indoor)
R5L
(R5L
indoor)
R6
(R6
EPC*)
R7
(R7
indoor)
R8
(R8
EPC*)
Dimensions [mm]
35x 20x7
30x23x13
44x20x7
47x20x7
45x24x12
44x20x7
50x30x12
Weight [g]
4,8
8 (7)
5,2 (4,8)
5,4 (5)
11 (14)
5,5
15 (18)
Antenna Length [mm]
2x100
1x200
(internal)
2x100
(2x45)
2x100
(2x45)
2x100
2x100
(2x45)
2x200
# of Channel Outputs
4
4
5
5
6
7
8
Temperature Range
[°C]
-10 to
+85
-10 to
+85
-10 to
+85
-10 to
+85
-10 to
+85
-10 to
+85
-10 to
+85
Supply Voltage [V]
3.2 – 8.4
3.2 – 8.4
3.2 – 8.4
3.2 – 8.4
3.2 – 8.4
3.2 – 8.4
3.2 – 8.4
Average Current [mA]
40
40
40
30
45
40
30
Real Time
Transmission of
Telemetric Data
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Programming
JETIBOX
JETIBOX
JETIBOX
JETIBOX
JETIBOX
JETIBOX
JETIBOX
Support Satellite
Receiver Rsat
no
no
no
no
no
no
no
Power Output [dBm]
6
6
6
15
15
6
15
Receiver Sensitivity
[dBm]
-98
-98
-98
-106
-106
-98
-106
2.1 Technical data receivers outside the U.S. part 1
2 Technical data
* xternal ower onnector E P C
