Version: 7.3
Updated: April 2019
Abstract:
This guide contains instrucī»ons and system limitaī»ons for adding expansion
enclosures to Infortrend storage system without aī
ecī»ng its existing storage
operaī»ons.
Expansion Enclosure Guide
Infortrend Expansion Guide
Copyright Ā© 2019 Infortrend Technology, Inc. All rights reserved.
Page 2 / 15
Contents
Contents ........................................................................................................................ 2
Introducī³on ................................................................................................................... 3
Overview of Maximum Drives ............................................................................................................... 3
Hybrid Expansion Enclosures ................................................................................................................. 4
Expansion Enclosure Number ................................................................................................................ 4
Expansion Enclosure Connecī³ons .................................................................................. 6
SAS 12 Gb/s Storage System .................................................................................................................. 6
SAS 6 Gb/s Storage System .................................................................................................................... 8
Model Classiī
caī¶on (Single and Redundant) ........................................................................................ 9
Expansion Enclosure On-line Expanding ....................................................................... 10
1. Seīng the expansion enclosure ID ................................................................................................. 10
2. Installing the newly-added expansion enclosure ............................................................................ 10
3. Reconnecī¶ng the redundant SAS path (for redundant models only) .......................................... 11
4. Connecī¶ng new SAS cable ............................................................................................................... 11
5. Turning on the newly-added expansion enclosure .......................................................................... 11
6. Installing the newly added drives .................................................................................................... 12
EonStor DS 1000/2000/3000 & GS/GSe 1000 SAS 6Gb/s Model Expansion Table ......... 13
Previous G7/G7i Model Expansion Table ...................................................................... 14
Previous G6 Model Expansion Table ............................................................................. 15
Infortrend Expansion Guide
Copyright Ā© 2019 Infortrend Technology, Inc. All rights reserved.
Page 3 / 15
Introducīµon
Infortrend storage systems are made of high quality and durable components based on a high-scalable hardware design,
providing support in terms of scalability and upgradeability. You also have the opī¼on to expand your storage system's
capacity with Infortrend's expansion enclosures in diī
erent form factors, allowing you more storage and provide quicker and
more eī
¢cient storage services without downī¼me.
The secī¼ons in this chapter list the expansion rules that you must follow when conī
guring the expansion enclosures with SAS
12 Gb/s drive-side models.
Overview of Maximum Drives
Infortrend provides various form factors that you can select for storage systems and expansion enclosures. The maximum
number of drives can be calculated based on the diī
erent models. Infortrend always uses SAS expansion technology to
implement massive drive scalability. Most of the products have onboard SAS ports to connect expansion enclosures and
some models support SAS expansion board to connect more expansion systems.
Take a look at the table below for Infortrend s products, the maximum number of drives, and their supported interfaces: ā
Hybrid SAS Interface
Storage System Drives
On-board SAS Ports
SAS Expansion Board
Maximum Drives
EonStor DS Family
(SAS 12Gb/s)
448 within 15 mixed expansion enclosures
N/A
448
EonStor GS 1000 Gen2
EonStor GSe 1000 Gen2
448 within 15 mixed expansion enclosures
N/A
448
EonStor GS 2000/3000/4000
EonStor GSe 2000/3000
EonStor GSc 2000/3000
448 within 15 mixed expansion enclosures
448 within 15 mixed expansion enclosures
896 (448 + 448)
EonStor GS 5000
EonStor GSc 5000
N/A
N/A
[896 within 15 mixed expansion enclosures]
x 2 expansion boards
1792 (896 + 896)
Hybrid SATA Interface
Storage System Drives
On-board SAS Ports
SAS Expansion Board
Maximum Drives
EonStor GSe Pro 100/ 200
5 bay, 8 bay
N/A
32 with 4 expansion enclosures
37 40 (5+32), (8+32)
EonStor GSe Pro 1000
4 bay, 8 bay
N/A
N/A
8
EonStor GSe Pro 3000
8 bay, 12 bay, 16 bay
N/A
448 within 15 mixed expansion enclosures
448
All Flash SAS Interface
Storage System Drives
On-board SAS Ports
SAS Expansion Board
Maximum Drives
EonStor GSa 2000
24 bay
360 with 15 x JB3024
360 with 15 x JB3024
744 (24 + 360 + 360)
EonStor GSa 3000
25 bay
375 with 15 x JB3025
375 with 15 x JB3025
775 (25 + 375 + 375)
EonStor GSa 5000
N/A
N/A
[375 with 15 x JB3025]
x 2 expansion boards
750 (375 + 375)
AI Appliance
Storage System Drives
On-board SAS Ports
SAS Expansion Board
Maximum Drives
EonStor GSi 3016
16 bay
224 with 14 x JB 3016
or 300 with 5 x JB 3060
N/A
316 (16 + 300)
EonStor GSi 5016
16 bay
224 with 14 x JB 3016
or 420 with 7 x JB 3060
N/A
436 (16 + 420)
Storage Server
Storage System Drives
On-board SAS Ports
SAS Expansion Board
Maximum Drives
EonServ 4012
12 bay
N/A
168 with 14 x JB 312
or 300 with 5 x JB 360
312 (12 + 300)
EonServ 4016
16 bay
N/A
224 with 14 x JB 316
or 300 with 5 x JB 360
316 (16 + 300)
EonServ 5012
12 bay
168 with 14 x JB 312
or 300 with 5 x JB 360
N/A
312 (12 + 300)
EonServ 5016
16 bay
224 with 14 x JB 316
or 300 with 5 x JB 360
N/A
316 (16 + 300)
EonServ 7012
12 bay
168 with 14 x JB 312
or 420 with 7 x JB 360
N/A
432 (12 + 420)
EonServ 7016
16 bay
224 with 14 x JB 316
or 420 with 7 x JB 360
N/A
436 (16 + 420)
Table 1: Maximum Drives of Current Models
