1
GB
English,1
GB
WASHER-DRYER
Contents
Installation, 2-3-4-5
Unpacking and levelling
Connecting the electricity and water supplies
The first wash cycle
Technical data
Description of the washer-dryer, 6-7
Control panel
Display
How to run a wash cycle or a drying cycle, 8
Wash cycles and options, 9
Table of programmes and wash cycles
Wash options
Detergents and laundry, 10
Detergent dispenser drawer
Preparing the laundry
Special wash cycles
Precautions and advice, 11
General safety
Disposal
Opening the porthole door manually
Care and maintenance, 12
Cutting off the water and electricity supplies
Cleaning the washer-dryer
Cleaning the detergent dispenser drawer
Cleaning the pump
Checking the water inlet hose
Troubleshooting, 13
Service and Guarantee, 14-15-16
Before calling for Assistance
Guarantee
PWDE 8148 W
Instructions for use
This symbol reminds you to read this instruction manual.
2
GB
Installation
This instruction manual should be kept in a safe place
for future reference. If the washer-dryer is sold,
transferred or moved, make sure that the instruction
manual remains with the machine so that the new
owner is able to familiarise himself/herself with its
operation and features.
Read these instructions carefully: they contain vital
information relating to the safe installation and operation
of the appliance.
Unpacking and levelling
Unpacking
1. Remove the washer-dryer from its packaging.
2. Make sure that the washer-dryer has not been
damaged during the transportation process. If it has
been damaged, contact the retailer and do not proceed
any further with the installation process.
3. Remove the 4
protective screws (used
during transportation) and
the rubber washer with
the corresponding spacer,
located on the rear part of
the appliance (see figure).
4. Close off the holes using the plastic plugs provided.
5. Keep all the parts in a safe place: you will need them
again if the washer-dryer needs to be moved to another
location.
Packaging materials should not be used as toys for
children.
Levelling
1. Install the washer-dryer on a flat sturdy floor, without
resting it up against walls, furniture cabinets or anything
else.
2. If the floor is not
perfectly level,
compensate for any
unevenness by tightening
or loosening the adjustable
front feet (see figure); the
angle of inclination,
measured in relation to the
worktop, must not exceed
2°.
Levelling the machine correctly will provide it with
stability, help to avoid vibrations and excessive noise and
prevent it from shifting while it is operating. If it is placed
on carpet or a rug, adjust the feet in such a way as to
allow a sufficient ventilation space underneath the
washer-dryer.
Connecting the electricity and water
supplies
Connecting the water inlet hose
1. Connect the inlet hose
by screwing it to a cold
water tab using a 3/4 gas
threaded connection (see
figure).
Before performing the
connection, allow the
water to run freely until it is
perfectly clear.
2. Connect the inlet hose
to the washer-dryer by
screwing it onto the
corresponding water inlet
of the appliance, which is
situated on the top right-
hand side of the rear part
of the appliance (see
figure).
3. Make sure that the hose is not folded over or bent.
The water pressure at the tap must fall within the
range of values indicated in the Technical data table (see
next page).
If the inlet hose is not long enough, contact a
specialised shop or an authorised technician.
Never use second-hand hoses.
Use the ones supplied with the machine.
3
GB
Connecting the drain hose
Connect the drain hose,
without bending it, to a
draining duct or a wall
drain situated between
65 and 100 cm from
the floor;
The drain hose may be
connected to an
under-sink trap. Before
connecting the drain
hose from the machine
ensure that any blanks
or removable ends
have been taken off
the spigot.
If it is place over the
edge of a basin or sink
be sure the free end of
the hose should not be
underwater.
We advise against the use of hose extensions; in
case of absolute need, the extension must have the
same diameter as the original hose and must not
exceed 150 cm in length.
Ensure that if the drain hose is pushed into a
standpipe, that the end does not go down more
than 15cms (6 inches). If the hose is pushed down
too far, this may cause the machine to self -syphon
ie. continuously empty as it is filling.
Electric connection
Before plugging the appliance into the mains
socket, make sure that:
the socket is earthed and in compliance with the
applicable law;
the socket is able to sustain the appliance's
maximum power load indicated in the Technical
details table (see page 5);
the supply voltage is included within the values i
ndicated on the Technical details table
(see page 5);
the socket is compatible with the washing
machine's plug. If this is not the case, replace
the socket or the plug.
Your appliance is now supplied with a 13 amp fused
plug it can be plugged into a 13 amp socket for
immediate use. Before using the appliance please
read the instructions below.
WARNING - THIS APPLIANCE MUST BE EARTHED.
THE FOLLOWING OPERATIONS SHOULD BE
CARRIED OUT BY A QUALIFIED ELECTRICIAN.
Replacing the fuse:
When replacing a faulty fuse, a 13 amp ASTA
approved fuse to BS 1362 should always be used,
and the fuse cover re-fitted. If the fuse cover is lost,
the plug must not be used until a replacement is
obtained.
Replacement fuse covers:
If a replacement fuse cover is fitted, it must be of the
correct colour as indicated by the coloured marking
or the colour that is embossed in words on the base
of the plug. Replacements can be obtained directly
from your nearest Service Depot.
Removing the plug:
If your appliance has a non-rewireable moulded plug
and you should wish to re-route the mains cable
through partitions, units etc., please ensure that
either:
the plug is replaced by a fused 13 ampere re-
wearable plug bearing the BSI mark of approval.
or:
the mains cable is wired directly into a 13 amp cable
outlet, controlled by a switch, (in compliance with BS
5733) which is accessible without moving the
appliance.
Disposing of the plug:
Ensure that before disposing of the plug itself, you
make the pins unusable so that it cannot be
accidentally inserted into a socket.
Instructions for connecting cable to an alternative plug:
Important: the wires in the mains lead are coloured in
accordance with the following code:
Green & Yellow Earth
Blue Neutral
Brown Live
65 - 100 cm
Where it connects to
the waste water pipe
cut end off spigot or
remove the blanking cap
4
GB
GREEN &
YELLOW
BROWN
BLUE
13 ampere fuse
CROSS-BAR
CORD GRIP
As the colours of the wires in the lead may not
correspond with the coloured markings identifyng
the terminals in your plug, proceed as follows:
Connect Green & Yellow wire to terminal marked E
or or coloured Green or Green & Yellow.
Connect Brown wire to terminal marked L or
coloured Red.
Connect Blue wire to terminal marked N or coloured
Black.
If a 13 amp plug (BS 1363) is used it must be fitted
with a
13 amp fuse, either in the plug or adaptor or at the
distribution board.
If you are in any doubt the electrical supply to your
machine, consult a qualified electrician before use.
How to connect an alternative plug:
The wires in this mains lead are coloured in
accordance with the following code:
BLUE NEUTRAL (N)
BROWN LIVE (L)
GREEN & YELLOW EARTH (E)
Disposing of the appliance:
When disposing of the appliance please remove the
plug by cutting the mains cable as close as possible
to the plug body and dispose of it as described
above.
The washing machine should not be installed in an
outdoor environment, not even when the area is
sheltered, because it may be very dangerous to
leave it exposed to rain and thunderstorms.
When the washing machine is installed, the mains
socket must be within easy reach.
Do not use extensions or multiple sockets.
The power supply cable must never be bent or
dangerously compressed.
The power supply cable must only be replaced by
an authorised serviceman.
Warning! The company denies all liability if and when
these norms are not respected.
The first wash cycle
Once the appliance has been installed, and before
you use it for the first time, run a wash cycle with
detergent and no laundry, setting the 90°C
programme without a pre-wash cycle.
5
GB
Technical data
Model PWDE 8148 W
Dimensions
width 59,5 cm
height 85 cm
depth 62 cm
Capacity from 1to 8 kg for wash programme
from 1 to 6 kg for the drying programme
Electrical
connections
please refer to the technical data
plate fixed to the machine
Water connections
maximum pressure 1 MPa (10 bar)
minimum pressure 0.05 MPa (0.5 bar)
drum capacity 62 litres
Spin speed up to 1400 rotations per minute
Energy rated
programmes
according to
regulation
EN 50229
Wash: programme 1; temperature
60°C; using a load of 8 kg.
Drying:
first drying cycle performed
with a 2 kg load, by selecting the
drying level "A1" (IRON);
Second drying cycle performed with a
6 kg load, selecting the maximum
drying level "A4" (EXTRA).
This appliance conforms to the
following EC Directives:
- 89/336/EEC dated 03/05/89
(Electromagnetic Compatibility) and
subsequent modifications
- 2006/95/EC (Low Voltage)
- 2002/96/EC
6
GB
Description of the washer-dryer
Control panel
TEMPERATURE
button
WASH
CYCLE
SELECTOR
KNOB
Detergent dispenser drawer
ON/OFF
button
SPIN
button
START/PAUSE
button and indicator
light
DISPLAY
DRYING
button
OPTION
buttons and
indicator lights
DOOR
LOCKED
indicator light
Detergent dispenser drawer: used to dispense
detergents and washing additives ( see Detergents
and laundry).
ON/OFF button: press this briefly to switch the
machine on or off. The START/PAUSE indicator light
which flashes slowly in a blue colour shows that the
machine is switched on. To switch off the washer-
dryer during the wash cycle, press and hold the
button for approximately 3 seconds; if the button is
pressed briefly or accidentally the machine will not
switch off.
If the machine is switched off during a wash cycle,
this wash cycle will be cancelled.
WASH CYCLE SELECTOR KNOB: used to set the
desired wash cycle (see Table of programmes and
wash cycles).
OPTION buttons and indicator lights: press to
select the available options. The indicator light
corresponding to the selected option will remain lit.
SPIN button: press to reduce or completely
exclude the spin cycle; the value appears on the
display.
TEMPERATURE button: press to reduce or
completely exclude the temperature; the value
appears on the display.
DRYING button : press to decrease or exclude
drying; the selected drying level or time will appear on
the display (see "How to run a wash cycle or a drying
cycle").
START/PAUSE button and indicator light: when
the blue indicator light flashes slowly, press the button
to start a wash cycle. Once the cycle has begun the
indicator light will remain lit in a fixed manner. To
pause the wash cycle, press the button again; the
indicator light will flash in an amber colour. If the
symbol is not illuminated, the door may be opened. To
start the wash cycle from the point at which it was
interrupted, press the button again.
DOOR LOCKED indicator light:
The lit symbol indicates that the door is locked. To
prevent any damage, wait until the symbol turns off
before opening the door.
To open the door while a cycle is in progress, press
the START/PAUSE button; if the DOOR LOCKED
symbol is switched off the door may be opened.
Standby mode
This washer-dryer, in compliance with new energy
saving regulations, is fitted with an automatic standby
system which is enabled after a few minutes if no
activity is detected. Press the ON-OFF button briefly
and wait for the machine to start up again.
Produktspezifikationen
| Marke: | Indesit |
| Kategorie: | Wasch-Trockner-Kombinationen |
| Modell: | PWDE 8148 S (UK) |
Brauchst du Hilfe?
Wenn Sie Hilfe mit Indesit PWDE 8148 S (UK) benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten
Bedienungsanleitung Wasch-Trockner-Kombinationen Indesit
12 Oktober 2024
12 Oktober 2024
11 Oktober 2024
7 Oktober 2024
13 Juli 2024
13 Juli 2024
10 Juli 2024
8 Juli 2024
8 Juli 2024
8 Juli 2024
Bedienungsanleitung Wasch-Trockner-Kombinationen
- Wasch-Trockner-Kombinationen Samsung
- Wasch-Trockner-Kombinationen Infiniton
- Wasch-Trockner-Kombinationen Sanyo
- Wasch-Trockner-Kombinationen LG
- Wasch-Trockner-Kombinationen Bosch
- Wasch-Trockner-Kombinationen Siemens
- Wasch-Trockner-Kombinationen Electrolux
- Wasch-Trockner-Kombinationen Miele
- Wasch-Trockner-Kombinationen Whirlpool
- Wasch-Trockner-Kombinationen BEKO
- Wasch-Trockner-Kombinationen Hotpoint
- Wasch-Trockner-Kombinationen Blomberg
- Wasch-Trockner-Kombinationen Brandt
- Wasch-Trockner-Kombinationen Candy
- Wasch-Trockner-Kombinationen Haier
- Wasch-Trockner-Kombinationen Hoover
- Wasch-Trockner-Kombinationen Hotpoint-Ariston
- Wasch-Trockner-Kombinationen Zanussi
- Wasch-Trockner-Kombinationen Zanussi-Electrolux
- Wasch-Trockner-Kombinationen Philco
- Wasch-Trockner-Kombinationen Rosières
- Wasch-Trockner-Kombinationen Frilec
- Wasch-Trockner-Kombinationen Elba
- Wasch-Trockner-Kombinationen Euromaid
- Wasch-Trockner-Kombinationen Lamona
- Wasch-Trockner-Kombinationen Tricity Bendix
- Wasch-Trockner-Kombinationen Nordland
- Wasch-Trockner-Kombinationen Creda
- Wasch-Trockner-Kombinationen Belling
- Wasch-Trockner-Kombinationen Summit
- Wasch-Trockner-Kombinationen Servis
- Wasch-Trockner-Kombinationen Voltas BEKO
Neueste Bedienungsanleitung für -Kategorien-
14 Oktober 2024
13 Oktober 2024
13 Oktober 2024
13 Oktober 2024
12 Oktober 2024
11 Oktober 2024
10 Oktober 2024
9 Oktober 2024
29 September 2024
7 August 2024
