BACK PANEL
FEATURES & FUNCTIONS
© 2019 SDI Technologies, Inc. All rights reserved
Questions? Visit www.ihome.com
LIMITED ONE YEAR WARRANTY
QUESTIONS? visit www.ihome.com
Model: iWBTW200
Quick Start Guide
GETTING STARTED
Before use, remove the battery pull tab
from the bottom of the unit. Connect the
included AC adapter to the DC jack
located on the back of the unit and
connect the other end to a working wall
outlet.
Connecting the Unit
Step One
SETTING THE ALARM
Each step must be completed while display is flashing or setting will time-out
without any changes saved.
1. Press and hold the for 2 seconds until the alarm time display and Alarm Button
alarm icon flash.
2. Press the to adjust the alarm time to the desired time (hold for – or + Buttons
rapid setting).
Make sure you set the correct AM/PM alarm time. The PM indicator
appears to the left of the display.
3. Press the Alarm Button to confirm the alarm time setting. The alarm schedule
will flash: 7 (every day), 5 (weekdays) or 2 (weekend only). Press the – or +
Buttons to select the desired alarm schedule.
4. Press the to confirm the alarm schedule. Now use the Alarm Button – or +
Buttons to set the wake to source:
Tones: Wake to built-in tones. Press the or– + Buttons to cycle through tones.
Bluetooth: Wake to audio from a connected Bluetooth device.
Beep: Wake to beeping sound.
5. Press the to confirm. Now use the Alarm Button – or + Buttons to control the
alarm volume and press the Alarm Button once more to confirm all settings. 2
beeps will confirm alarm setting is complete. The alarm icon will remain on the
display, indicating the alarm is armed.
6. To turn o a sounding alarm and reset it to come on the next day at the same
time, press the to reset alarm.Alarm Button
Press and release the as needed to preview the alarm and to Alarm Button
toggle the alarm ON (indicated by the alarm icon) or OFF (no alarm icon).
PREVIEWING THE ALARM
PROGRAMMABLE SNOOZE
WIRELESS CHARGING
Check the Wireless Charging LED under the iHome badge for
charging status:
Slow blinking LED: Device is charging properly.
Solid LED: Device is charged.
Rapid blinking LED: Device is not charging properly. Reposition
device.
(LED may continue to blink slowly when iOS devices are fully charged.)
CAUTION: Remove metal protective or magnetic case from phone
before charging. When charging phone, do not place
magnetic-striped or other metal objects on the charger. Doing so
could damage the object or this unit. Qi compatible phones with
metallic looking finishes will charge normally.
APPLE WATCH CHARGING
BATTERY BACK-UP
The unit comes with a CR-2450 back-up battery installed to
provide continuous alarm operation and clock settings in the event
of a temporary power failure. Remove the battery pull tab before
use. When the battery icon on the clock display is flashing, it is time
to replace the back-up battery. The battery compartment is
located on the bottom of the unit.
1. Make sure the AC adapter is
connected, or you will lose your time
and alarm settings during battery
replacement.
2. Use a Phillips screwdriver to open
the battery compartment door.
3. Remove the exhausted battery from
the compartment and insert 1
CR-2450 battery, checking that the
+ side is facing you. Replace the
compartment door. Do not
overtighten.
WARNING: Lithium batteries can explode or cause burns if disassembled,
shorted, recharged, exposed to water, fire, or high temperatures. Do not
place loose batteries in a pocket, purse, or other container containing metal
objects, mix with used or other battery types, or store with hazardous or
combustible materials. Store in cool, dry, ventilated area. Follow applicable
laws and regulations for transport and disposal.
• Do not ingest the battery, Chemical Burn Hazard. This product contains a
coin/button cell battery. If the coin/button cell battery is swallowed, it can
cause severe internal burns in just 2 hours and can lead to death.
• Keep new and used batteries away from children. If the battery
compartment does not close securely, stop using the product and keep it
away from children. If you think batteries might have been swallowed or
placed inside any part of the body, seek immediate medical attention.
• Attention should be drawn to the environmental aspects of battery
disposal.
Supports:
• Qi compatible phones (also works with plastic cases up to 3mm thick*)
Place Qi compatible device face up on the charging rest as pictured below:
The Apple Watch Magnetic Charging Module
works with Apple Watch, Apple Watch Sport
and Apple Watch Edition. Place your watch on
the charger with the watch face turned upward
until the battery indicator on the watch shows
it is charged.
(You can deactivate ‘Nightstand Mode’ in the
settings of your Apple Watch to eliminate a
duplicate time display.)
Bluetooth Speaker + Triple Charging
TIMEBASE PRO+
DST Switch (Daylight Savings)
USB Charging (5V/1A)
DC Jack for power supply
(12V/2.7A)
-1 +1 Auto
-1 +1 Auto
-1 +1 Auto
-1 +1 Auto
-1 +1 Auto
DST
DST
DST
DST
DSTusb cha rgi ng
usb cha rgi ng
usb cha rgi ng
usb cha rgi ng
usb cha rgi ngDC 12V, 2.7A
DC 12V, 2.7A
DC 12V, 2.7A
DC 12V, 2.7A
DC 12V, 2.7A
Bluetooth Pairing Button/LED
Connecting to Bluetooth
Step Two
• Turn on your Bluetooth device and make it
‘discoverable’ by turning on Bluetooth mode.
• Press and hold the Bluetooth Pairing
Button on the TIMEBASE PRO+ to enter
pairing mode.
• Select ‘iHome iWBTW200’ on your device’s
Bluetooth menu to connect!
iHome
iWBTW200
Battery Backup
Compartment
(for clock accuracy)
*Before use, remove battery pull tab
from bottom panel.
Alarm
Indicator
Low Backup
Battery
Indicator
PM Indicator
DISPLAY ICONS
-1 +1 Au to
-1 +1 Au to
-1 +1 Au to
-1 +1 Au to
-1 +1 Au to
D S T
D S T
D S T
D S T
D S Tus b c h a r g i n g
us b c h a r g i n g
us b c h a r g i n g
us b c h a r g i n g
us b c h a r g i n gDC 12V, 2.7A
D C 12V, 2. 7A
D C 12V, 2. 7A
D C 12V, 2. 7A
D C 12V, 2. 7A
RESET
RESET
RESET
RESET
RESET
RESET
RESET
RESET
RESET
RESET
TEST
TEST
TEST
TEST
TEST
TEST
TEST
TEST
TEST
TEST
Setting the Time
Step Three
• Press and hold the until the Time Button
clock display begins to flash.
• Use the +/- Buttons to adjust the time.
• Press the Time Button to confirm the time.
• The year will flash on the display. Use the
+/- Buttons to adjust the year, and press the
Time Button again to confirm.
• The month will flash on the display. Use the
+/- Buttons to adjust the month, and press
the again to confirm. Time Button
• The date will flash on the display. Use the
+/- Buttons to adjust the date, and press the
Time Button again to confirm all settings.
0QVG Make sure to set the
correct AM/PM time. The
PM indicator will appear
on the left side of the
display. There is no AM
indicator.
BOTTOM PANELFRONT PANEL
1. To program Snooze, press and hold the ZZZ Button during normal
operation (when no alarm is sounding).
2. Press the to select a snooze time between 1-29 minutes.+ or - Buttons
3. Press the ZZZ Button to confirm Snooze setting. When the alarm is
sounding, press down on the ZZZ Button to temporarily silence the
alarm (9 minutes is the default).
When set to Auto, clock will
automatically update twice a year.
To manually adjust, switch to -1 to
lose an hour and + 1 to gain an hour.
When used in the directed manner, this unit has been designed and manufactured to ensure your
personal safety. H use can result in potential electrical shock or fire hazards. owever, improper
Please read and follow all safety and operating instructions carefully before installation and use, and
keep these instructions handy for future reference. Take special note of all warnings listed in these
instructions and on the unit.
1. Water and Moisture – The unit should not be used near water. For example: near a bathtub,
washbowl, kitchen sink, laundry tub, swimming pool or in a wet basement.
2. Ventilation – The unit should be situated so that its location or position does not interfere with
its proper ventilation. For example, it should not be situated on a bed, sofa, rug or similar
surface that may block ventilation openings. Also, it should not be placed in a built-in
installation, such as a bookcase or cabinet, which may impede the flow of air through the
ventilation openings.
3. Heat – The unit should be situated away from heat sources such as radiators, heat registers,
stoves or other appliances (including amplifiers) that produce heat.
4. Power Sources – The unit should be connected to a power supply only of the type described in
the operating instructions or as marked on the appliance. Only use the AC adapter that came
with the unit.
5. Power-Cable Protection – Power supply cables should be routed so that they are not likely to
be walked on or pinched by items placed upon or against them. It is always best to have a clear
area from where the cable exits the unit to where it is plugged into an AC socket.
6. Cleaning – Clean only with dry cloth.
7. Objects and Liquid Entry – Care should be taken so that objects do not fall and liquids are not
spilled into any openings or vents located on the product.
8. Attachments – Do not use attachments not recommended by the product manufacturer.
9. Lightning and Power Surge Protection – Unplug the unit from the wall socket and disconnect
the antenna or cable system during a lightning storm or when it is left unattended and unused
for long periods of time. This will prevent damage to the product due to lightning and
power-line surges.
10. Overloading – Do not overload wall sockets, extension cords, or integral convenience
receptacles as this can result in a risk of fire or electric shock.
11. Damage Requiring Service – The unit should be serviced by qualified service personnel when:
A. the power supply cable or plug has been damaged.
B. objects have fallen into or liquid has been spilled into the enclosure.
C. the unit has been exposed to rain.
D. the unit has been dropped or the enclosure damaged.
E. the unit exhibits a marked change in performance or does not operate normally.
12. Periods of Nonuse – If the unit is to be left unused for an extended period of time, such as a
month or longer, remove batteries before storage
13. Servicing – The user should not attempt to service the unit beyond those methods described
in the user manual. Service methods not covered in the operating instructions should be
referred to qualified service personnel.
14. Magnetic Interference: This product’s speakers contain powerful magnets which could cause
interference or damage to sensitive equipment such as hard drives, CRT televisions and
monitors, as well as medical, scientific, and navigational devices. Keep this unit away from these
products at all times.
15. Only use attachments/accessories specified by the manufacturer. This product is suitable for
use in tropical and/or moderate climates.
16. The unit should be serviced by qualified service personnel when the enclosure damaged or
does not operate normally.
17. No naked flame sources, such as lighted candles, should be placed on the apparatus.
18.
WARNING: To reduce the risk of fire or electric shock, do not expose this product to rain or moisture.
19. CAUTION – Danger of explosion if battery is incorrectly replaced. Replace only with the same
or equivalent type.
20. Do not dispose of batteries in the household trash or fire
21. The mains plug of power adaptor is used as the disconnect device, it shall remain readily
operable.
IMPORTANT SAFETY INSTRUCTIONS
iHome Products, a division of SDI Technologies Inc. (hereafter referred to as SDI),
warrants this product to be free from defects in workmanship and materials, under
normal use and conditions, for a period of one (1) year from the date of original
purchase. Should this product fail to function in a satisfactory manner, it is best to first
return it to the store where it was originally purchased. Should this fail to resolve the
matter and service still be required by reason of any defect or malfunction during the
warranty period, SDI will repair or, at its discretion, replace this product without charge.
This decision is subject to verification of the defect or malfunction upon delivery of this
product to the Factory Service Center authorized by Customer Service.
If service is required, please visit ihome.com/support/contact to obtain a Return
Authorization Number. A copy of the sales receipt is required to validate in-warranty
coverage.
Disclaimer of Warranty
NOTE: This warranty is valid only if the product is used for the purpose for which it was
designed. It does not cover (i) products which have been damaged by negligence or
willful actions, misuse or accident, or which have been modified or repaired by
unauthorized persons; (ii) cracked or broken cabinets, or units damaged by excessive
heat; (iii) damage to digital media players, CD’s or tape cassettes (if applicable); (iv) the
cost of shipping this product to the Factory Service Center and its return to the owner.
This warranty is valid only in the United States of America and does not extend to
owners of the product other than to the original purchaser. In no event will SDI or any of
its aliates, contractors, resellers, their ocers, directors, shareholders, members or
agents be liable to you or any third party for any consequential or incidental damages,
any lost profits, actual, exemplary or punitive damages. (Some states do not allow
limitations on implied warranties or exclusion of consequential damages, so these
restrictions may not apply to you.) This warranty gives you specific legal rights, and you
may also have other rights which vary from state to state. Your acknowledgment and
agreement to fully and completely abide by the above mentioned disclaimer of warranty
is contractually binding to you upon your transfer of currency (money order, cashier's
check, or credit card) for purchase of your SDI product.
Wireless Charging Status LED
Wireless Charging Area
POWER
WIRELESS CHARGING REST
- Press to Turn ON/OFF
PLAY/PAUSE
- Press to Play/Pause audio or
answer calls
- Press & Hold to end/ignore calls
- Press & Hold to activate
Google/Siri on paired device
ZZZ (SNOOZE/DI MMER)
APPLE WATCH CHARGER
- Press to stop sounding alarm/
reset for the next day
TIME SET
ALARM SET
- Press to Preview
- Press Again to Arm/Disarm
- To set alarm, press & hold
until display starts to flash
(adjust with and press+ - /
alarm to confirm)
- To set clock, press &
hold until display starts
to flash (adjust with + -/
and press time to confirm)
- Repeat for year, month,
and date
PLUS | MINUS
- Press to adjust volume and settings
Connect a standard USB cable
(not included) to charge devices.
The unit must be c onnected to DC
power in order to c harge devices.
- Press to snooze a sounding alarm
- Press repeatedly to adjust display
brightness
WIRELESS CHARGING
STATUS LED
Apple Watch
Charger
-Press and hold to enter
pairing mode
-Press and release to cancel
pairing

Produktspezifikationen

Marke: IHome
Kategorie: Lautsprecher
Modell: Timebase Pro+ iWBTW200

Brauchst du Hilfe?

Wenn Sie Hilfe mit IHome Timebase Pro+ iWBTW200 benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten


Bedienungsanleitung Lautsprecher IHome

IHome

IHome iBT16 Bedienungsanleitung

5 Oktober 2024
IHome

IHome iBN27 Bedienungsanleitung

5 Oktober 2024
IHome

IHome iDM8 Bedienungsanleitung

23 September 2024
IHome

IHome iBT297 Bedienungsanleitung

16 September 2024
IHome

IHome Zenergy Sunrise Bedienungsanleitung

3 September 2024
IHome

IHome Playglow+ iBT820 Bedienungsanleitung

3 September 2024
IHome

IHome Playpro iBT700 Bedienungsanleitung

3 September 2024
IHome

IHome PlayGlow Mini IBT800 Bedienungsanleitung

3 September 2024
IHome

IHome iHM46 Bedienungsanleitung

30 August 2024
IHome

IHome iW2 Bedienungsanleitung

30 August 2024

Bedienungsanleitung Lautsprecher

Neueste Bedienungsanleitung für -Kategorien-

Sonance

Sonance Visual Performance VP65 SST Bedienungsanleitung

16 Oktober 2024
Bowers And Wilkins

Bowers And Wilkins CWM664 Bedienungsanleitung

16 Oktober 2024
Focal

Focal Chorus 826 V Bedienungsanleitung

16 Oktober 2024
KEF

KEF Ci200ER Bedienungsanleitung

16 Oktober 2024
Steren

Steren SPK-1100BL Bedienungsanleitung

16 Oktober 2024
Aiwa

Aiwa SP-A100 Bedienungsanleitung

16 Oktober 2024
Trust

Trust GXT 628 Bedienungsanleitung

15 Oktober 2024
Pyle

Pyle PBMSPG6 Bedienungsanleitung

15 Oktober 2024
Marshall

Marshall Tufton Bedienungsanleitung

15 Oktober 2024
Sunstech

Sunstech SPUBT780 Bedienungsanleitung

15 Oktober 2024
