iBT295 - QSG (English)

Size: 700 x 160 mm (unfold), 140 x 160 mm (folded)

Color: Black (1C + 1C)

Material: 85gsm, WF paper

May 19, 2020 Front Cover

Quick Start Guide

What’s

Included:

AC adapter

iBT295 unit

Quick Set-Up:

The Display

• Remove the battery pull tab from the bottom

of the unit before use.

• Connect the included AC adapter to the DC

jack located on the back of the unit, and

connect the other end to a working wall

outlet.

Connecting the Unit

Ste p One

Set ting Your Clock

Ste p Two

Connecting to Bluetooth

Ste p Three

• Press and hold the Time Set Button until the

display ﬂashes.

• Press the to adjust selections – or + Buttons

and tap to conﬁrm (make sure you Time Set

set the correct AM/PM time).

• Do this for time, year, month and date.

• All done!

Daylight Savings Time:

By default, the DST Switch on the bottom of

the unit is set to Auto and will automatically

adjust the time in March and November.

FM Radio + Presets

Extend the radio antenna for best reception. Press a FM Preset Button (1-4) to turn on the

radio and use the to select a frequency.– or + Buttons

The unit allows you to store up to 4 FM radio station presets.

1. Press the – + or Buttons to tune the radio to the desired station (hold to scan for the next

clear station).

2. Press and hold a FM Preset Button (1-4). 2 beeps will sound to conﬁrm the prese t has

been assigned. Repeat steps 1-2 until you have set up to 4 preset stations.

3. Press an FM Preset Button (1-4) to l isten to a preset FM station at any time.

Charging Devices Via USB Port

1. Connect the standard size e nd of a USB cable (not

included) to the USB port on the back of the unit and

connect the other e nd to the charging port on your

device.

2. Monitor the charging on your device. Some devices use

a proprietary charging method and will not charge using

the USB port. If this happens, you must charge your

device using the charger that came with it.

Battery Back-Up

The unit uses a CR-2450 back-up battery to provide continuous alarm operation and clock

settings in the event of a temporary power failure. Remove the battery pull tab before use.

When the battery icon on the clock display is ﬂashing, it is time to replace the back-up

battery. The battery compartment is located on the bottom of the unit.

1. Make sure the AC adapter is connected, or you will l ose

your time and alarm settings during battery replacement.

2. Use a Phillips screwdriver to open the battery compartment

door.

3. Insert a fresh CR-2450 battery, checking that the polarity

match the markings on the unit. Replace the compartment

door. Do not overtighten.

FCC INFORMATION

This e quipment complies with FCC RF radiation e xposure limits se t forth for an unco ntrolled e nvironm ent.

This d evice complies with Part 15 of the FCC Rules, operation is subjec t to the follo wing two co nditions :

(1) This device may no t caus e harm ful interferenc e, and (2) this d evice must acc ept any interference received ,

including interferenc e that m ay c ause undes ired operation.

• Warning: Changes or m odiﬁcations to this unit not expressly ap prov ed b y the party responsible for com pliance

could void the user’s autho rity to op erate the equipm ent.

• NOTE: This equipment has been tested and found to comply with the limits for a Class B digital dev ice, purs uant

to Pa rt 15 of the FCC Rules.

Thes e limits are designed to pro vide reaso nable protectio n against harmful interference in a residential insta llation.

This equipment generates , uses and can radiate radio frequenc y energy and, if not installed and used in accordance

with the instructions , ma y ca use ha rmful interference to radio com munications.

However, there is no guarantee tha t interference will no t o ccur in a p articular installation. If this equipm ent d oes

caus e harm ful interference to radio or television recep tion, which c an be determ ined by turning the equipment o 

and o n, the us er is enc ouraged to try to c orrect the interference b y one or more o f the following me asures:

• Reorient or relocate the receiving antenna.

• Increa se the separation b etween the equipm ent and rece iver.

• Connec t the equipment into an outlet on a c ircuit dierent from that to which the rece iver is c onnec ted.

• Consult the d ealer o r an experienced radio /TV technician for help.

This e quipment should be ins talled and op erated with minimum distanc e 20 cm between the radiator & your bo dy.

IC Statement

This e quipment complies with IC RSS-102 radiation expos ure limits set forth for an uncontrolled environm ent.

This device co ntains licenc e-exem pt transmitter(s)/receiver(s) that comply with Innova tion, Science and Econo mic

Develo pme nt Cana da’s licence -exempt RSS(s ). Ope ration is s ubject to the following two co nditions:

(1) This device may no t caus e interference .

(2) This device must accept any interference, including interference that may cause undesired operation of the device.

The device m eets the exemption from the routine evaluation limits in section 2.5 o f RSS 102 a nd c ompliance with

RSS-102 RF exposure, users can o btain C anad ian information on RF expo sure a nd co mpliance.

This eq uipm ent sho uld be insta lled and o pera ted with a minimum dista nce o f 20 c m betwe en the radia tor and

your body.

Any Changes or modiﬁcations not expressly approv ed by the party responsible for com pliance could void the user’s

authority to operate the equipm ent.

Cet é quipem ent e st conforme aux limites d'expos ition aux radiations IC C NR-102 établies p our un environnement

non c ontrôlé.

L’éme tteur/récepteur exempt de licence contenu da ns le présent ap pareil est conform e aux CNR d’Innov ation,

Scie nces et Développement économique Canada app licables aux appa reils radio exempts de licence. L’exploitation

est autorisée aux deux c onditions suiva ntes :

(1) L’ap pareil ne doit pa s pro duire de brouillag e;

(2) L’a ppa reil doit ac cep ter tout bro uillage radioélec trique subi, mêm e si le brouillage est s usce ptible d’en

com promettre le fonc tionnem ent.

Le disp ositif rencontre l'exemptio n des limites co urantes d'éva luation da ns la se ction 2.5 de RSS 102 et la

conformité à l'exposition de RSS-102 rf, utilisateurs peut obtenir l'information canadienne sur l'exposition et la

conformité de rf.

Cet éq uipement doit être installé et utilisé ave c une distanc e minimale de 20 c m entre le radia teur et vo tre co rps.

Tout c hange ment ou mod iﬁcation non expressém ent approuvé par la pa rtie respo nsable de la co nformité pe ut

annuler l'autorité de l'utilisateur à utiliser l'éq uipement.

CAN ICES-3 (B) / NMB-3(B)

iBT295_QSG_051920_A

Printed in China

IMPORTANT SAFETY INSTRUCTIONS

Please heed al l warnings, read and fol low all instructions and keep these instructions handy

for future reference.

1. Do not use this product near water, and clean only with dry cloth.

2. Do not block any ventilation openings. Instal l in accordance with the manufacturer’s

instructions.

3. Heat – This product should be situated away from heat sources such as radiators, heat

registers, stoves or other appliances (including ampliﬁers) that produce heat.

4. Only use attachments/accessories speciﬁed by the manufacturer.

5. Unplug this product during lightning storms or when unused for long periods of time.

6. Damage Requiring Service – This product should be serviced by qualiﬁed service personnel

when:

- Plug has been damaged.

- Obje cts have fal len into or liquid has been spille d into the enclosure.

- The unit has been exposed to rain. The unit has been dropped or the enclosure damaged.

- The unit exhibits a marked change in performance or does not operate normally.

7. No naked ﬂame sources, such as lighted candles, should be placed on this product.

8. Attention should be drawn to the environmental aspects of battery disposal.

9. This product is suitable for use in tropical and/or moderate climates.

10. WARNING: To reduce the risk of ﬁre or electric shock, do not expose this product to rain

or moisture.

11. Do not dispose of batteries in the household trash or ﬁre.

12. The mains plug of power adaptor is used as the disconnect device, it shall remain readily

operable.

Maintenance

• Place the unit on a level surface away from sources of direct sunlight or excessive heat.

• Remove the plastic protective ﬁlm from the clock display.

• Protect your furniture when placing your unit on a natural wood and lacquered ﬁnish.

A cloth or other protective material should be placed between it and the furniture.

• Clean your unit with a soft cloth moistened only with mil d soap and water. Stronger cleaning

agents such as thinner or similar materials can damage the surface of the unit.

Setting A Sound Alarm

1. P ress and hold the for 2 seconds until the alarm time display and alarm Sound Alarm Button

icon ﬂash. A beep sounds.

2. Press the – + or Buttons to adjust the alarm time to the desired time (hold for rapid setting).

Make sure you set the correct AM/PM alarm time. The PM indicator appears to the left of the display.

3. Press the Sound Alarm Button to conﬁrm the alarm time setting. The alarm schedule will ﬂash:

7 (every day), 5 (weekdays) or 2 (weekend only). Press the – or + Buttons to select the desired

alarm schedule.

4. Press the to conﬁrm the alarm schedule. The wake-to source will ﬂash.Sound Alarm Button

5. Press the or– + Buttons to select a wake-to alarm source: Bluetooth, FM Radio, or Tone:

Wake to Bluetooth: Press the Sound Alarm Button to conﬁrm.

Wake to FM Radio: Press the to conﬁrm. Press the or the Sound Alarm Button – or + Buttons

FM Presets Buttons to select the desired FM frequency to wake to.

Wake to Tone: Press the to conﬁrm. Press the to sel ect a Sound Alarm Button – or + Buttons

tone (T1-T4).

6. Press the Sound Alarm Button to conﬁrm wake-to source. The alarm volume will ﬂash.

7. Press the or– + Buttons to adjust the alarm volume.

8. Press the Sound Alarm Button to conﬁrm alarm volume and exit alarm setting mode.

2 beeps will conﬁrm alarm setting is complete. The alarm icon on the display indicates alarm is armed.

Setting A Light Alarm

1. P ress and hold the Light Alarm Button for 2 seconds until the alarm time display and alarm icon

ﬂash. A beep sounds.

2. Press the – + or Buttons to adjust the alarm time to the desired time (hold for rapid setting).

Make sure you set the correct AM/PM alarm time. The PM indicator appears to the left of the display.

3. Press the to conﬁrm the alarm time setting. The alarm schedule will ﬂash:Light Alarm Button

7 (every day), 5 (weekdays) or 2 (weekend only). Press the – or + Buttons to select the desired

alarm schedule.

4. Press the to conﬁrm the alarm schedule. The wake-to source will ﬂash.Light Alarm Button

5. Press – +or Buttons to select a wake-to light mode: Dawn, Fade, Fast, Stop, Beat, Sky, or Nite.

6. Press the to conﬁrm alarm settings and exit alarm setting mode. 2 beeps will Light Alarm Button

conﬁrm alarm setting is complete. The alarm icon on the display indicates alarm is armed.

DC 5V 2A

Model: iBT295

Previewing the Alarm

Press and release the to view the current Light Alarm Button or Sound Alarm Button

alarm set tings.

Programmable Snooze and Dimmer

Adjust the snooze duration and set a schedule for your clock backlight to automatically

dim and brighten at certain times of the day.

1. Press and hold the Snooze/Dimmer Button until the display starts to ﬂash.

2. Use the + or - Buttons to adjust the snooze duration from 1-29 minutes. Press the

Snooze/Dimmer Button again to conﬁrm.

Now it’s time to set the display dimmer schedule:

3. Use the + or - Buttons to set the AUTO dimmer to ON or OFF. Press Snooze/Dimmer

Button to conﬁrm. (Note: Choosing OFF will simply exit the setting.)

4. Use the + or - Buttons to choose the BRIGHTNESS level for daytime hours. Press

Snooze/Dimmer Button again to conﬁrm.

5. Use the +/- Buttons to set the TIM E you want the daytime dimmer to take ee ct.

Press Snooze/Dimmer Button again to conﬁrm.

6. Use the +/- Buttons to choose the BRI GHTNESS le vel for nighttime hours. Press

Snooze/Dimmer Button again to conﬁrm.

7. Use the +/- Buttons to set the TIM E you want the nighttime dimmer to take eect.

Press Snooze/Dimmer Button again to conﬁrm.

8. Done! The icon will appear on the display when Dimmer Schedule is active.

Snooze: When the alarm is sounding, press the Snooze/Dimmer Button to snooze for 9

minutes.

Dimmer: Press the Snooze/Dimmer Button (when alarm is NOT sounding) to adjust

display brightness.

ONE YEAR LIMITED WARRANTY

iHome Products, a division of SDI Technologies Inc. (hereafter referred to as SDI), warrants

this product to be free from defects in workmanship and materials, under normal use and

conditions, for a period of 90 days from the date of original purchase. Should this product

fail to function in a satisfactory manner, it is best to ﬁrst return it to the store where it was

originally purchased. Should this fail to resolve the matter and service still be required by

reason of any defect or mal function during the warranty period, SDI will repair or, at its

discretion, replace this product without charge. This decision is subje ct to veriﬁcation of

the defect or malfunction upon del ivery of this product to the Factory Service Center

authorized by Customer Service.

If service is required, please contact Customer Service at ihomeaudio.com/support/con-

tact to obtain a Return Authorization Number and shipping instructions. A copy of the

sales receipt is required to validate in-warranty coverage. If proof of purchase cannot be

produced, the product will be deemed out-of-warranty. The date of purchase, vendor,

product model number, and purchase price must be legible and veriﬁable.

Disclaimer of Warranty

NOTE: This warranty is valid only if the product is used for the purpose for which it was

designed. It does not cover (i) products which have been damaged by negligence or

willful actions, misuse or accident, or which have bee n modiﬁed or repaired by unautho-

rized persons; (ii) cracked or broken cabinets, or units damaged by excessive heat; (iii)

damage to digital media players, CD’s or tape cassettes (if applicable); (iv) the cost of

shipping this product to the Factory Service Center and its return t o the owner. This

warranty is val id only in the United States of America and does not extend to owners of

the product other than to the original purchaser. In no event will SDI or any of its aliates,

contractors, resellers, their ocers, directors, shareholders, members or agents be l iable

to you or any third party for any consequential or incidental damages, any lost proﬁts,

actual, exemplary or punitive damages.

(Some states do not allow limitations on implied warranties or exclusion of consequential

damages, so these restrictions may not apply to you.) This warranty gives you speciﬁc

legal rights, and you may also have other rights which vary from state to st ate. Your

acknowledgment and agreement to fully and completely abide by the above mentioned

disclaimer of warranty is contractuall y binding to you upon your transfer of currency

(money order, cashier's check, or credit card) for purchase of your SDI product.

Quest ions? Visit www.ihome .com

Questions? Visit ihome.com

POWERCLOCK GLOW

Bluetooth Speaker + USB Charging

PM Indicator

Programm able Dimmer

Bluetooth Status Light Alarm

Sound Alarm

• Press the Power Button.

• Press and hold the Play/Bluetooth Pairing

Button until the display ﬂashes.

• Select ‘iHome iBT295’ from your Bluetooth

device’s menu to connect.

Low Backup Battery

FM Radio Sleep Mode

Backup Battery

Compartm ent

Note: Unit must be plugged into working

outlet in order to charge devices.

WARNING

• Do not ingest the battery, Chemical Burn Hazard. This product contains a coin/button cell

battery. If the coin/button cell battery is swallowe d, it can cause severe internal burns in just

2 hours and can lead to death.

• Keep new and used batte ries away from children. I f the battery compartment does not

close securely, stop using the product and keep it away from children. If you think batteries

mtight have been swall owed or placed inside any part of the body, seek immediate medical

attention.”

• CAUTION - RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN I NCORRECT TYPE.

DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS.

Sleep Mode

To set a sleep timer:

1. Press the Sleep Button as needed to cycle to the desired sle ep timer duration: 120, 90,

60, 30, 15 minutes, or OFF.

2. Press and rel ease the during Slee p Mode to review the remaining sleep Sleep Button

time.

Snooze/Display Dimmer

Bluetooth Mode

Controls Overview

DC Jack

(5V/2A)

Rear Controls Light Modes

Use to adjust the brightness.DIM Butt ons

Press Light Mode to cycle through colo rs.

Time Set Button

USB Charging Port

(5V/1A)

FM Antenna

(exten d for best

recepti on)

Turning the Alarm On/O

1. Press and rel ease the corresponding Alarm Button (Light or Sound) twice within 5

seconds to toggle the alarm ON and OFF, indicated by the rel ated white alarm indicator

2. When the alarm sounds, press the corresponding Alarm Button (Light or Sound) or the

Power Button to disable the al arm and reset it to come on at the same time the next

day.

Using Light Modes

Press the Light Mode Button repeatedly to cycle through 6 dierent modes:

• Fade

• Fast

• Stop

• Be at*

• Sky

• Nightlight

• OFF

Use DIM Buttons to adjust the brightness.

*Beat Light M ode will pulse to music only when the unit is in Bluetooth mode.

Produktspezifikationen

Marke:	IHome
Kategorie:	Radio
Modell:	Powerclock Glow IBT295

Brauchst du Hilfe?

Wenn Sie Hilfe mit IHome Powerclock Glow IBT295 benötigen, stellen Sie unten eine Frage und andere Benutzer werden Ihnen antworten

Ihren Namen*

Deine E-Mail*

Schreiben Sie hier Ihre Frage

Bedienungsanleitung Radio IHome

IHome IBTW281B Bedienungsanleitung

30 August 2024

IHome ID50BZC Bedienungsanleitung

30 August 2024

IHome IW18 Bedienungsanleitung

30 August 2024

IHome iA100 Bedienungsanleitung

30 August 2024

IHome IC50B Bedienungsanleitung

30 August 2024

IHome iP97 Bedienungsanleitung

30 August 2024

IHome IBTW39G Bedienungsanleitung

30 August 2024

IHome iD83 Bedienungsanleitung

30 August 2024

IHome IDL45B Bedienungsanleitung

30 August 2024

IHome Powerclock Glow IBT295 Bedienungsanleitung

30 August 2024

Bedienungsanleitung Radio

Neueste Bedienungsanleitung für -Kategorien-

Ruarkaudio Rseven Bedienungsanleitung

16 Oktober 2024

Ruarkaudio MR1 Bedienungsanleitung

16 Oktober 2024

Denver TWE-55B Bedienungsanleitung

15 Oktober 2024

AudioSonic CL-1486 Bedienungsanleitung

14 Oktober 2024

Sangean DPR-39 Bedienungsanleitung

14 Oktober 2024

Sangean RCR-9 Bedienungsanleitung

14 Oktober 2024

PerfectPro Dabbox Bedienungsanleitung

13 Oktober 2024

Uniden UH45CP Bedienungsanleitung

12 Oktober 2024

Sencor SIR 5000WDB Bedienungsanleitung

11 Oktober 2024

AEG KRC 4350 BT Bedienungsanleitung

10 Oktober 2024
