Installation Instructions
Airflow monitor
SL0106
704565 / 00 02 / 2009
UK
2
Function and features 1
The airflow monitor monitors airflows. It senses whether there is a preset airflow
(= green LED lights, output relay energised for NO function, de-energised for NC
function).
If the flow is below the preset value, the red LED lights. The output relay is de-
energised for NO function and energised for NC function.
Setting range 1 m/s to 10 m/s.•
Start-up delay of 3 s ... 60 s (to suppress short-time fluctuations), depending on •
the preset value
Mounting2
Mount the airflow monitor by means of the mounting clamp provided. Diameter of
the mounting hole for the unit: 24 mm. If mounting is to be airtight, use the gasket
provided. The sensing head must be completely immersed into the airflow and
should be in the range of the highest flow velocity, if possible. Installation depth:
min. 32 mm, max. 120 mm.
min. 32 mm max. 120 mm
Align the unit in the airflow; the arrow on the cap must point in the direction of flow.
arrow
(must be at the top)
Poti
Poti
LEDs
LEDs
arrow
3
UK
To avoid malfunction a minimum
distance between the air flow moni-
tor and bends, valves or such like
must be observed.
min.
5 x D
min.
3 x D
D
Electrical connection3
The unit must only be connected by an electrician.
The national and international regulations for the installation of electrical
equipment must be observed.
Insert a miniature fuse according to the technical data sheet.
Disconnect power. â–º
Connect the unit according to the indications on the type label. â–º
Justieren4
setting potentiometer
sensitivity
LEDs
1
Apply the operating voltage. â–º
Switch on the flow (preset value) and keep it constant. â–º
In case of a cold start wait until the stabilisation time of approx. 60 s is over. â–º
2
If the red LED lights:
turn the pot slowly clockwise until the â–º
red LED goes off and the green LED
comes on.
If the green LED lights:
turn the pot slowly anticlockwise until â–º
the green LED goes off and the red
LED comes on.
Turn the pot again slowly clockwise â–º
until the green LED comes on.
3
If fluctuations as a result of the operating conditions are to be compensated for:
turn the pot further clockwise after the green LED has lit. â–º
