Seite 1/8
Operating instructions
Switching amplifiers
N0537A
N0538A
N0539A
80299364 / 0002 / 2021
GB
Contents
1 Preliminary note ............................................................................................. 3
2 Safety instructions.......................................................................................... 3
3 Intended use .................................................................................................. 3
3.1 Classification........................................................................................... 4
3.2 ATEX certificate ...................................................................................... 4
3.3 IECEx certificate ..................................................................................... 4
3.4 Identification............................................................................................ 4
4 Installation...................................................................................................... 4
4.1 Requirements for cables and connection cables .................................... 5
4.2 Requirements in case of use as associated equipment.......................... 5
4.3 Requirements for use with equipment protection level Gc...................... 6
5 Electrical connection ...................................................................................... 6
6 Operating and display elements .................................................................... 7
7 Maintenance, repair and disposal .................................................................. 8
3
1 Preliminary note
You will find instructions, technical data, approvals and further information using
the QR code on the unit / packaging or at .www.ifm.com
2 Safety instructions
•
The unit described is a subcomponent for integration into a system.
–
The system architect is responsible for the safety of the system.
–
The system architect undertakes to perform a risk assessment and to create
documentation in accordance with legal and normative requirements to be
provided to the operator and user of the system. This documentation must
contain all necessary information and safety instructions for the operator,
the user and, if applicable, for any service personnel authorised by the
architect of the system.
•
Read this document before setting up the product and keep it during the entire
service life.
•
The product must be suitable for the corresponding applications and
environmental conditions without any restrictions.
•
Only use the product for its intended purpose ( Intended use).Ò
•
If the operating instructions or the technical data are not adhered to, personal
injury and/or damage to property may occur.
•
The manufacturer assumes no liability or warranty for any consequences
caused by tampering with the product or incorrect use by the operator.
•
Installation, electrical connection, set-up, operation and maintenance of the
product must be carried out by qualified personnel authorised by the machine
operator.
•
Protect units and cables against damage.
3 Intended use
The unit is used in instrumentation and control engineering (ICE) for galvanic
isolation of signals, such as 20mA and 10V standard signals, or in addition for
adapting and standardising signals. The unit features intrinsically safe circuits that
are used to operate intrinsically safe field units within hazardous areas.
The unit is intended for installation on a 35 mm DIN rail according to EN 60715.
GB
