Seite 1/3
Installation Instructions
Inductive sensor with
optical setting aid
701227 / 03 07 / 2007
UK
UK
UK
UK
UK
2
Function and features1
This inductive sensor detects metals without contact and indicates their presence
by providing a switched signal.
The nominal sensing range (Sn) can be seen in the type designation on the type
label on the unit; operating distance (Sa) 0...0,81 x Sn; (values based on standard
measurement with mild steel; a shorter sensing range for other metals).
Electrical connection2
Disconnect power before connecting the sensor. Connection strictly to the
indications on the type label. The unit can be used as normally open ( ) or as
normally closed ( ).
Installation3
Mounting by means of a mounting de-
vice.Adjust the unit. Adjustment is correct
when the red LED does not light. Secure
by means of the nuts provided so that it
cannot work loose.
Flush installation.
1 2
LED yellow / red 1: Target2:
Open space around the sensing face
when mounted in metal:
3 x Sn
3
UK
Minimum distance when several sensors of the same type are mounted:
D DD 8 x Sn
Operation4
Check the safe functioning of the sensor. Display by LEDs:
The yellow LED is lit when the output is switched.•
The red LED is lit in case of faulty adjustment.•
output function
LED yellow
No object in the detection range.
LED red
LED yellow
Safe detection of the object.
LED red
LED yellow Unsafe detection of the object
(readjust the unit).
LED red
The operation of the sensor is maintenance-free.
For perfect functioning make sure that:
the sensing face and the open space are kept free of metal deposits and fo-•
reign bodies, particularly for installation with the sensing face facing upwards;
EMC: The unit conforms to the requirements of EN 60947-5-2.•
