Installation instructions
Mounting bracket for DIN rail mounting
E30575
11612747 / 0006 / 2024
GB
E30575 Mounting bracket for DIN rail mounting
2
1 Safety instructions
• The product described is a subcomponent for integration into a system.
– The system architect is responsible for the safety of the system.
– The system architect undertakes to perform a risk assessment and to create documentation in
accordance with legal and normative requirements to be provided to the operator and user of
the system. This documentation must contain all necessary information and safety instructions
for the operator, the user and, if applicable, for any service personnel authorised by the
architect of the system.
• Read this document before setting up the product and keep it during the entire service life.
• The product must be suitable for the corresponding applications and environmental conditions
without any restrictions.
• Only use the product for its intended purpose ( Intended use).Ò
• If the operating instructions or the technical data are not adhered to, personal injury and/or damage
to property may occur.
• The manufacturer assumes no liability or warranty for any consequences caused by tampering with
the product or incorrect use by the operator.
• Installation, set-up, operation and maintenance of the product must be carried out by qualified
personnel authorised by the machine operator.
• Protect the product against damage.
• Store the product in its original packaging.
2 Intended use
The mounting bracket makes it possbile to install ifm sensors of types PQSxxx and PQCxxx on a 35
mm DIN rail.
Mounting bracket for DIN rail mounting E30575
3
3 Installation
uHook the device into a 35 mm DIN rail and clip it into place.
uPlace the device onto the attachment pins (1) of the mounting bracket and push it downwards until
it locks into place.
Fig.1: DIN rail mounting with mounting bracket
Removal
uPress the upper lever of the mounting bracket (2) in the direction of the arrow and pull the device
upwards.
uPress the lower lever of the mounting bracket (3) upwards and remove the mounting bracket from
the DIN rail.
Fig.2: Removal
