Installation instructions
Mounting set for panel mounting
E30574
11594462 / 0006 / 2024
GB
E30574 Mounting set for panel mounting
2
1 Safety instructions
• The product described is a subcomponent for integration into a system.
– The system architect is responsible for the safety of the system.
– The system architect undertakes to perform a risk assessment and to create documentation in
accordance with legal and normative requirements to be provided to the operator and user of
the system. This documentation must contain all necessary information and safety instructions
for the operator, the user and, if applicable, for any service personnel authorised by the
architect of the system.
• Read this document before setting up the product and keep it during the entire service life.
• The product must be suitable for the corresponding applications and environmental conditions
without any restrictions.
• Only use the product for its intended purpose ( Intended use).Ò
• If the operating instructions or the technical data are not adhered to, personal injury and/or damage
to property may occur.
• The manufacturer assumes no liability or warranty for any consequences caused by tampering with
the product or incorrect use by the operator.
• Installation, set-up, operation and maintenance of the product must be carried out by qualified
personnel authorised by the machine operator.
• Protect the product against damage.
• Store the product in its original packaging.
2 Intended use
The mounting set makes it possible to install ifm sensors of types PQSxxx and PQCxxx in a panel.
Mounting set for panel mounting E30574
3
3 Installation
uIn a panel with a maximum thickness of 6 mm, make a 31 mm x 31 mm cutout (-0.4 mm tolerance
each).
Fig.1: Panel mounting using a fixing clamp (panel cutout; front view; rear view)
uInsert the device into the cutout in the panel from the back.
uSlide the frame of the mounting set (1) over the device from the front and attach it by engaging the
two lateral protruding sections (2) into the recesses (3) on both sides of the device.
uSlide the fixing clamp of the mounting set onto the device from behind. The locating lugs of the
fixing clamp (4) will latch in the jagged recesses on both sides of the device (5). Push until the
device is firmly in place.
Fig.2: Panel mounting with mounting set
