Seite 1/12
User Manu al
i-t PCI external + 2 internal USB 3.0 Adapter ec e to 2x x
Introducing:
PCI ise to USB 3.0 adapter PCIe p1-x1 card with 2 external and 2 internal USB 3.0 ports
(all of them are back compatible with USB 2.0 and USB 1.1). It is Fully compliant with
PCI Express Base Specification Revision 2.0. Adapter supports simultaneous
operation of multiple USB 3.0, USB 2.0 and USB 1.1 devices with up to 5 Gbps
speed data rate. Built-in 4-pin power slot for receiving extra power supply from
system.
Package contens:
- 1 x e to external + 2x internal USB 3.0 er PCI 2x adapt
- 1 x Low Profile Backplate
- 1 x Driver CD
- 1 x User Manual
Specification:
- Fully compliant with PCI Express Base Specification Revision 2.0
- Compliant with Universal Serial Bus 3.0 specification Revision 1.0
- Single-lane (x1) PCI Express throughput rates up to 5 Gbps
- Supports simultaneous operation of multiple USB 3.0, USB 2.0 and USB 1.1
devices
- Supports the following speed data rates as follows:
Low 80-speed (1.5 Mbps) / Full-speed (12 Mbps) / High-speed (4 Mbps) /
Super-speed (5 Gbps)
- Built-in 4-pin power slot for receiving extra power supply from system
- Hot-swapping feature allows you to connect/disconnect devices without
powering down the system
- Support Windows XP/Vista/7/8 (32/64 bit)
System requirements:
- Installed Windows XP/Vista (32/64bit) /7/ 8
- One available PCI Express slot (Recommend PCI Express 2.0)
- One available Molex connector on PSU
Hardware Description:
Hardware installation:
Attention!
The adapter can install skilled person or authorized service department only.
ComDis, s. r. o. is not responsible for damages caused by unauthorized assembling
and installation of this device.
- Turn Off the power to your computer.
- Unplug the power cord and remove your computer s cove ’r.
- Remove the slot bracket from an available PCIe slot.
- install the card, carefully align the card s bus connector with the selected PCIe To ’
slot on the motherboard. Push the board down firmly.
- Replace the slot bracket s holding screw to secure the card. ’
- Connect available 4-pin power connector from PSU to 4-pin power slot (Molex) on
the PCIe adapter.
Attention: PCIe adapter will be functionless without this connection.
- Replace the computer cover, reconnect the power cord and power on your PC.
Driver installation for Windows XP/Vista/7 (32/64bit) /8
- Please insert the CD driver bound with USB 3.0 PCI Express Card into your CD-
ROM Drive and begin istallation
- At the Windows desktop, click Start, Run
- Type , click OK. (Change D: to match your CD-ROM drive D:\PCE22U3\Setup.exe
letter)
- Follow the on-screen instructions to complete the installation
- After connection of USB device can be necessary to use drivers delivered with that
device
Handbuch
für i-tec PCIe to 2x external + 2x internal USB 3.0 Adapter
Einleitung:
PCIe to USB 3.0 Adapter ist eine PCIe x1 Karte mit zwei externen und zwei internen
Porten der USB 3.0 Schnittstelle (alle Porte sind mit USB 2.0 sowie USB 1.1
rückwertig kompatibel). Sie ist im Einklang mit der für PCI Express 2.0 definierten
Spezifikation hergestellt. Der Adapter an den Porten unterstützt die Kommunikation
mit Anlagen mit Schnittstelle USB 3.0, USB 2.0 sowie USB 1.1 auf die
Geschwindigkeit bis zu 5 Gb/s mit bidirektionalem Datenfluss. Die Unterstützung der
Zusatzversorgung mittels eines eingebauten 4-Pins-Portes.
Lieferumfang:
- PCIe to 2x external + 2x internal USB 3.0 Adapter
- Low Profile Schild
- mit Treibern und Handbuch CD
- Benutzerhandbuch
Spezifikation:
- Voll kompatibel mit der Spezifikation PCI Express 2.0
- Unte rstützung der Spezifikation USB 3.0 Revision 1.0
- Durchlauf der einfachen Linie (x1) am PCI Express-Hauptweg: bis zu 5 Gbps
- etriebes der Anlage mit USB 3.0, USB 2.0 sowie Unterstützung des Simultanb
USB 1.1 Schnittstelle
- hwindigkeiten an allen USB 3.0 Porten: Unterstützung der Übertragungsgesc
Low-speed (1.5 Mb/s) / Full-speed (12 Mb/s) / High-speed (480 Mb/s) / Super-
speed (5 Gb/s)
- Eingebauter 4-Pins-Port -(Typ Molex) für externe Hilfsversorgung aus der PC
Quelle
- -Swapping-Funktion (die USB-Unterstützung der Hot Anlage während des
Systemlaufs anschließen und ausschalten)
- / 8 32/64bit Unterstützung für Windows XP / Vista / 7
Systemanforderungen:
- mit installiertem Windows XP / Vista / 7 32/64bit PC / 8
- Ein freier PCI Express-Slotter ( Ie 2.0 empfohlen mit Unterstützung PC )
- 1x freies Molex-Konnektor auf dem PC-Netzteil
