i-CAN S490
Technical
Requirements
Summary
Author C.Clementi
File name TRS_Tivusat HD Zapper _i-CAN_S490_v0.5.doc
Version 0.5
Date 2019-11-18
Located on Docserver
Classification CONFIDENTIAL
This document contains confidential information. By accepting this material, the recipient
agrees that this material and the information contained therein will be held in confidence
and in trust. The reproduction of any part of the document is strictly prohibited without
the prior written consent of ADB SA.
Any company’s or product name(s) found in this document may be the trademarks or
registered trademarks of their respective companies.
![](https://manualstech.ams3.cdn.digitaloceanspaces.com/html/de/i-can/s490/html/bg2.png)
i-CAN S490 Technical Requirements Summary Version
0.5
Confidential 2 / 10
Table of Contents
1 INTRODUCTION ...................................................................................................... 3
2 PRODUCT SPECIFICATION ................................................................................. 3
2.1
GENERAL ...................................................................................................................... 3
2.2
DECODER ...................................................................................................................... 5
2.3
INTERFACES ................................................................................................................. 6
2.4
ENCLOSURE ................................................................................................................. 7
2.5
CERTIFICATIONS & COMPLIANCE ............................................................................. 7
3 STANDARD ACCESSORIES & PACKAGING ..................................................... 8
4 STANDARD ROYALTIES & LICENSES ............................................................... 9
5 DOCUMENT APPROVAL ...................................................................................... 10
![](https://manualstech.ams3.cdn.digitaloceanspaces.com/html/de/i-can/s490/html/bg3.png)
i-CAN S490 Technical Requirements Summary Version
0.5
Confidential 3 / 10
1 INTRODUCTION
i-CAN S490 HD HEVC DVB-S2 Set-Top-Box (STB) is a new generation product in
form factor that is dedicated for the Italian TivĂąsat retail market. It is compatible with
Italian UHD Book 1.0.1 and Tivusat market and technical requirements. This product will
complement the existing portfolio of FTA zappers and TivĂąsat decoders.
2 PRODUCT SPECIFICATION
2.1 General
ID Item Description
A.
Chipset Vendor: Ali
Model:
M3528
B.
RAM Memory 256MB DDR3
C.
Flash Memory Flash 128MB Nand
D.
Mass Storage External via USB (2.0 500 mA)
E.
Front-End
Single DVB-S2
- Compliant with UHD-BOOK 1.0.1 front end requirements (HD
SAT receiver only, DVB-S2X not required)
DiSEqC 1.2 support
Unicable v1 (SCR) and v2 (DCSS) support
F.
Connectivity for basic applications: Weather forecast Ethernet
G.
CAS & DRM,
Security
Nagra Merlin
- NASC 3.0 Tier 3
- CAK7 DLK-Merlin 2.13.1 - (
CAK_ICME 2.13.1
)
- DALAPI 7.17.1
No DRM support
H.
Software Stack
SW featuring:
- First time automatic installation (needs modification to be in
line with HD Book : LCN, Parental PIN selection)
- HD Zapper profile, TivĂąsat STB specification 2019, version 1.0,
compliant (mostly related specific EPG protocol through the
DSMCC, Nagra messaging, relevant chapters highlighted)
- UHD-BOOK 1.0.1 compliant (excluding HbbTV and any HbbTV
Connected features, relevant chapters highlighted)
- Italian and English languages
- TivĂąsat LCN ordering
- OTA update
Produktspezifikationen
Marke: | I-CAN |
Kategorie: | Digital-Decoder |
Modell: | S490 |
WLAN: | Nein |
Breite: | 180 mm |
Tiefe: | 110 mm |
AC-Netzadapter: | Ja |
Produktfarbe: | Schwarz |
Höhe: | 42 mm |
Tunertyp: | Analog & Digital |
Anzahl USB 2.0 AnschlĂĽsse: | 2 |
Gleichstrom-Anschluss (DC): | Ja |
On-Screen-Display (OSD): | Ja |
Fernbedienung enthalten: | Ja |
Anzahl Ethernet-LAN-AnschlĂĽsse (RJ-45): | 1 |
Betriebsanleitung: | Ja |
HD-Typ: | HD |
Digitales Signalformatsystem: | DVB-S, DVB-S2 |
Anzahl HDMI-AnschlĂĽsse: | 1 |
Audio Kanäle: | - Kanäle |
Verbesserung des Videotexts: | Ja |
Elektronischer ProgrammfĂĽhrer (EPG): | Ja |
Anzahl SCART-AnschlĂĽsse: | 1 |
UnterstĂĽtzte Video-Modi: | 720p |
Optischer Audio-Digitalausgang: | 1 |
Anzahl RF AnschlĂĽsse: | 1 |
UnterstĂĽtzte Videoformate: | H.264, MPEG2 |
Zeitverschiebung: | Ja |
Integrierter Kartenleser: | Nein |
Videokompressionsformate: | HEVC |
Kontrolle durch Eltern: | Ja |
S/PDIF-Ausgang: | Ja |
Eingebaute HDD: | Nein |
Anzahl der Tuners: | - Signalempfänger |
Signalquelle: | Cable, Ethernet (RJ-45), Satellite |
Ethernet/LAN: | Ja |
SmartCard Tivusat enthalten: | Ja |
