Seite 1/24
FOR YOUR SAFETY
READ AND UNDERSTAND THE ENTIRE MANUAL BEFORE OPERATING
MACHINE
Both model number and serial number may be found on the main label.
You should record both of them in a safe place for future use.
Hydraulic Log Splitter
Operator's Manual
Save This Manual for Future Reference
Original Instruction
MODEL NUMBER : 65553 65558 65558-6 65558-7
SERIAL NUMBER :
2
INTRODUCTION
SYMBOLS
TABLE OF CONTENTS
Introduction
Symbols
Safety
Contents Supplied
Know Your Machine
Assembly
Splitter Operation
Freeing a Jammed Log
Transport
Replacing Hydraulic Oil
Delivering Log Splitter to Work Site
Sharpening Wedge
Trouble Shooting
Hydraulic System Diagram
Wiring Diagram
Parts Schematic
Special Warnings & Instructions
Specifications
Safety Warnings & Instructions
2
3
3
3
5
5
6
10
7
12
14
11
15
12
16
17
18
18
19
Your new log splitter will more than
sati s f y you r e x p e c tation s . I t h as
been manufactured under stringent
quality standards to meet superior
performance criteria. You will find your
new unit easy and safe to operate, and
with proper care, it will give you many
years of dependable service.
Carefully read through this
entire operator's manual
before using your new log
splitter. Take special care
to heed the cautions and
warnings.
The rating plate on your machine
may show symbols. These represent
im p ortant inf orma ti on a b ou t the
product or instructions on its use.
Rea d these instru c ti on s
i n f u l l b e f ore u si n g t he
machine.
Do not remove or tamper
w i t h a n y p r o t e c ti o n o r
safety devices.
Wear safety footwear!
Lifting Point.
Wear protective gloves!
Bundling mark.
Wear eye protection!
Wear hearing protection!
Keep your hands away!
RECYCLING AND DISPOSAL
This marking indicates that this
product should not be disposed
with other household wastes.
To prevent possible harm to
the environment or human
health from uncontrolled waste
disposal, recycle it responsibly to
promote the sustainable reuse
of material resources. To return
your used device, please use the
return and collection systems or
check with your local authority
or local stores for advice of
environmental safe recycling.
3
SAFETY
D a n g e r ! K e e p c l e a r o f
moving parts!
Do not remove jammed logs
with your hands.
Dispose of the used oil in an
environment-friendly way.
Before starting any repair
maintenance or cleaning,
always disconnect the power.
Do not use in the rain.
Keep bystanders away from
the working area.
W a r n i n g ! S t a y c l e a r o f
moving parts!
Safety Warnings & Instructions
UNDERSTAND YOUR LOG SPLITTER
DRUGS, ALCOHOL AND MEDICATION
AVOID DANGEROUS CONDITIONS
Read and understand the owner's
manual and labels affixed to the log
splitter. Learn its application and
limitations as well as the specific
potential hazards peculiar to it.
Do not operate the log splitter while
under the influence of drugs, alcohol,
or any medication that could affect
your ability to use it properly.
Put the log splitter on a 72-85 cm high,
stable, flat, and level work bench where
there is plenty of room for handling,
and help the operator stay altert. Bolt
the log splitter to the work surface if it
tends to slip, walk, or slide.
Keep your work area clean and well lit.
Cluttered areas invites injuries.
INSPECT YOUR LOG SPLITTER
Check your log splitter before turning
i t o n . K e ep g u a rd s i n p l a c e a n d
in working order. Form a habit of
checking to see that keys and adjusting
wrenches are removed from tool area
before turning it on. Replace damaged,
missing or failed parts before using it.
DRESS PROPERLY
Do not wear loose clothing, gloves,
neckties or jewelry (rings, wrist watches).
They can be caught in moving parts.
Protective electrically non conductive
gloves and non-skid footwear are
recommended when working. Wear
protective hair covering to contain long
hair, preventing it from get caught in
machinery.
PROTECT YOUR EYES AND FACE
Any log splitter may throw foreign
objects into the eyes. This can cause
permanent eye damage. Always wear
safety goggles. Everyday eyeglasses
have only impact resistant lenses. They
are not safety glasses.
Do not put the log splitter on the ground
for operations. This is awkward operating
position means that the operator has to
bring his face close to the machine, and
thus risks being struck by wood chips or
debris.
Do not use the log splitter in wet or
damp areas or expose it to rain.
Do not use it in areas where fumes
from paint, solvents or flammable
liquids pose a potential hazard.
EXTENSION CORDS
Improper use of extension cords may
cause inefficient operation of the log
splitter which can result in overheating.
Be sure the extension cord is no longer
than 10m and its diameter is no less than
2.5mm
2 to allow sufficient current flow to
the motor.
Avoid use of free and inadequately
insulated connections. Connections must
be made with protected material suitable
for outdoor use.
