Seite 1/126
MANUAL (p. 2)
PURE SINE INVERTER
MODE D’EMPLOI (p. 17)
ONDULEUR PURE SINE
MANUALE (p. 32)
INVERTER AD ONDA SINUSOIDALE
PURA
BRUKSANVISNING (s. 61)
PURE SINE INVERTERS
MANUAL DE UTILIZARE (p. 76)
INVERTOARE CU UN SINUSOIDALĂ
PURĂ
BRUGERVEJLEDNING (p. 91)
ÆGTE SINUSVEKSELRETTER
HASZNÁLATI ÚTMUTATÓ (o. 47.)
PURE SZINUSZ INVERTEREK
YTTÖOHJE (s. 54)
PUHDAS SINIAALTOINVERTTERI
GEBRUIKSAANWIJZING (p. 24)
PURE SINUSOMVORMER
ANLEITUNG (s. 9)
SINUS-WECHSELRICHTER
MANUAL DE USO (p. 39)
INVERSORES SINUSOIDALES PUROS
VOD K POUŽITÍ (s. 69)
SINUSOVÉ MĚNIČE NATÍ S ČISTOU
SINUSOVKOU
ΕΓΧΕΙΡΙΔΙΟ XPHΣHΣ (σελ. 84)
PURE SINE INVERTERS
VEILEDNING (p. 98)
RENE SINUSINVERTERE
HQ-PURE120-12 HQ-PURE150-12
HQ-PURE300-12 HQ-PURE600-12
HQ-PURE600-24 HQ-PURE1KW-12
HQ-PURE1KW-24 HQ-PURE1500-12
HQ-PURE1500-24 HQ-PURE2KW-12
HQ-PURE2KW-24
2
ENGLISH
Inverter layout
Front 150/300 W
1. = AC 230 V outputs
2. = LED (green = power on)
(orange = abnormal)
3. = Power switch
Front 600/1000/1500/2000 W
1. = AC 230 V output(s)
2. = LED (over temperature)
3. = LED (over load)
4. = LED (power output)
5. = Power switch
6. = Jack for remote controller
Back (except 120/150 W)
1. = Mounting hole
2. = Cooling fan
3. = Ground terminal
4. = DC input terminals
Notes on using the instruction manual
Caution!
Safety instruction, failure to observe this instruction can cause material damage and impair the
function of the device. Supplementary information for operating the device.
Caution!
Safety instruction relating to danger from electrical current or voltage. Failure to observe this
instruction can cause material damage and personal injury and impair the function of the device.
3
General safety instructions
• Usethedeviceonlyasintended.
• Donotoperatethedeviceinadamporwetenvironment.
• Donotoperatethedeviceinareasthatarepotentiallyexplosive.
• Maintenanceandrepairworkmustonlybecarriedoutbyqualiedpersonnelwhoarefamiliarwith
the risks involved and the relevant regulations
Safety when installing the device
• Ensurethatthedevicehasarmfoundation.Thedevicemustbesetupandfastenedinsucha
way that it cannot tip over or fall down.
• Taketheprecautionsnecessarytoensurethatchildrencannotinterferewithoperation.Dangerous
situations may occur which cannot be recognized by children!
• Donotexposethedevicetoaheatsource(suchasdirectsunlightorheating).Avoidadditional
heating of the device in this way.
For installation on boats
• Ifelectricaldevicesareincorrectlyinstalledonboats,corrosiondamagemightoccur.Havethe
inverter installed by a specialist.
Electrical cables
• Ifcableshavetobefedthroughmetalwallsorotherwallswithsharpedges,useductsorwire
bushings to prevent damage to the cable.
• Donotlaycableswhicharelooseorbentnexttoelectricallyconductivematerial(metal).
• Donotpullonthecables.
• Donotlaythe230Vmainscableandthe12/24VDCcableinthesameduct.
• Fastenthecableswell.
• Laythecablessothattheycannotbetrippedoverordamaged.
• Operatethedeviceonlyifyouarecertainthatthehousingandthecablesareundamaged.
• Makesuretheairinletsandoutletsofthedevicearenotcovered.
• Ensureagoodventilation.
• Donotconnectthe230Voutputoftheinvertertoadifferent230Vsource.
• Evenafterthefusetriggers,partsoftheinverterremainlive.
• Alwaysdisconnectthepowersupplywhenworkingonthedevice.
Proper use
Thepuresinewaveinvertersconvert12Vor24Vdirectcurrenttoa230Valternatingcurrentata
frequencyof50Hz.
Warning!
Reverse polarity connection of the battery wires can damage the inverter. Do not use the inverter with
electrical systems using positive ground.
Withitslowweightandcompactdesigntheinvertercanbeeasilyinstalledintocampingmobiles,
commercial vehicles or motor and sailing yachts.
Theoutputvoltagecorrespondstothesocketstandard(puresinus-voltage)
Pleaseobservethevaluesforconstantoutputpowerandpeakoutputpower(foramaximumof10
minutes)asindicatedinthe“Technicaldata”section.
Neverconnectdevicesthathaveahigherpowerrequirement.
Note
Notewhenconnectingdeviceswithanelectricaldrive(suchaspowerdrillsandrefrigerators),thatthey
often need more power than is stated on the type plate.
